Double shaft shredder machine D

paperplastic

The Liantai Machinery Small Double Shaft Shredder uses two counter-rotating cutting shafts to shear and tear solid materials into smaller pieces. Its compact design makes it suitable for primary shredding of small-sized materials in light-duty industrial and recycling applications.
Key Features
- Dual-shaft cutting system for efficient shearing and tearing.
- Compact design for space-saving installation.
- Wide material range for wood, plastics, paper and packaging waste.
- Flexible configuration of cutters, drive system and feeding arrangement.
- Customized solutions based on material type, capacity and output requirements.
Applications
Suitable for wood, plastic products, plastic offcuts, paper, cardboard, packaging waste, small industrial scrap and other suitable solid materials.
Specification:
Item Model DM1640 DM2050 DM2560 DM2880
Dimension L/W/H(mm) 1790*680*1300 2490*725*1500 2578*800*1500 2950*1000*1800
Cutting Chamber size (mm) 336*406 435*516 540*712 580*808
Center Distancemm 130 165 200 230
Rotor Blade Diameter(mm) 160 200 250 280
Rotor Blade Thickness(mm) 20 17 30 40
Rotor Blade Quantity (PCS) 20 30 20 20
Main Motor Power(KW) 2.2+2.2/3+3 3+3/4+4 5.5+5.5/7.5+7.5 11+11/15+15
Net Weight(KG) 680 1400 2000 3000

Q1: What materrials can this shredder process?
It can process wood, plastics, paper, cardboard, packaging waste and other suitable small solid materials.
Q2: How does a double shaft shredder work?
Two rotating cutter shafts work together to shear and tear materials into smaller pieces.
Q3: How do I select the right model?
Selection depends on material type, feed size, required capacity, target output size and operating hours.
Q4: Can the machine be customized?
Yes. The cutter configuration, drive system and feeding arrangement can be selected according to the application.
Q5: How can I get product details and a suitable recommendation?
Contact Liantai Machinery for detailed product information and a solution recommendation based on your material and processing requirements.
