Sorting grab MD series

hydraulicfor excavators

Product description
The Digging Grapple is engineered for efficient digging and cleaning of narrow canals, delivering precise excavation with enhanced safety and durability. It features a patented A-synchronous grip and precision-engineered jaws to ensure secure material handling. A fully enclosed drive unit reduces risk of injury and simplifies operation. The grapple's balanced design increases gripping power while minimizing weight, and a closed housing reduces environmental impact. The product is covered by a 3-year warranty.

Key features

• Patented A-synchronous grip for reliable, safe operation
• Precision-engineered jaws to minimize material slippage
• Fully enclosed drive unit to prevent injuries and simplify maintenance
• Balanced design to enhance gripping power while reducing weight
• Closed housing to limit environmental impact
• 3-year warranty

Tool functions

• Digging and cleaning narrow canals; precise excavation tasks

Smart Modular Concept
The Digging Grapple is compatible with the manufacturer's modular concept to extend functionality. More than 100 additional functions are available to adapt the tool to different tasks and optimize machine performance.

Technical specifications

• MD 3.0 / 45 — Machine operating weight: 3–6 t; Volume: 45 l / 0.06 cy; Width (A): 250 mm / 9.8 in; Arms weight: 95 kg / 210 lbs; Total grapple weight*: 270 kg / 595 lbs. (*Total grapple weight does not include the connection plate.)
• MD 3.0 / 55 — Machine operating weight: 3–6 t; Volume: 55 l / 0.07 cy; Width (A): 300 mm / 11.8 in; Arms weight: 100 kg / 220 lbs; Total grapple weight*: 275 kg / 606 lbs. (*Total grapple weight does not include the connection plate.)
• MD 3.0 / 65 — Machine operating weight: 3–6 t; Volume: 65 l / 0.09 cy; Width (A): 350 mm / 13.8 in; Arms weight: 105 kg / 232 lbs; Total grapple weight*: 280 kg / 617 lbs. (*Total grapple weight does not include the connection plate.)
• MD 6.0 / 60 — Machine operating weight: 5–9 t; Volume: 60 l / 0.08 cy; Width (A): 250 mm / 9.8 in; Arms weight: 133 kg / 293 lbs; Total grapple weight*: 368 kg / 811 lbs. (*Total grapple weight does not include the connection plate.)
• MD 6.0 / 72 — Machine operating weight: 5–9 t; Volume: 72 l / 0.09 cy; Width (A): 300 mm / 11.8 in; Arms weight: 140 kg / 309 lbs; Total grapple weight*: 375 kg / 827 lbs. (*Total grapple weight does not include the connection plate.)
• MD 6.0 / 85 — Machine operating weight: 5–9 t; Volume: 85 l / 0.11 cy; Width (A): 350 mm / 13.8 in; Arms weight: 147 kg / 324 lbs; Total grapple weight*: 382 kg / 842 lbs. (*Total grapple weight does not include the connection plate.)
• MD 9.0 / 95 — Machine operating weight: 8–14 t; Volume: 95 l / 0.12 cy; Width (A): 300 mm / 11.8 in; Arms weight: 170 kg / 375 lbs; Total grapple weight*: 430 kg / 948 lbs. (*Total grapple weight does not include the connection plate.)
• MD 9.0 / 110 — Machine operating weight: 8–14 t; Volume: 110 l / 0.14 cy; Width (A): 350 mm / 13.8 in; Arms weight: 177 kg / 390 lbs; Total grapple weight*: 437 kg / 963 lbs. (*Total grapple weight does not include the connection plate.)
• MD 9.0 / 125 — Machine operating weight: 8–14 t; Volume: 125 l / 0.16 cy; Width (A): 400 mm / 15.7 in; Arms weight: 185 kg / 408 lbs; Total grapple weight*: 445 kg / 981 lbs. (*Total grapple weight does not include the connection plate.)
