Sorting grab MD series

hydraulic

Product description
The Rail Grapple is designed for safe and precise handling, positioning and adjustment of railway tracks in construction and maintenance operations. It integrates patented A-synchronous grip technology, precision-engineered jaws and a fully enclosed base drive to reduce operational risk and ensure repeatable performance. The product is supplied with a 3-year warranty and is suitable for industrial use on excavators within the recommended operating weight ranges.

Smart Modular Concept
The Rail Grapple supports a modular upgrade path. More than 100 optional functions and accessories can be added to adapt the tool for specific tasks, increasing functionality without requiring a complete replacement of the unit.

Diagrams and visual information

• High-resolution product photos and technical illustrations show grip geometry and assembly interfaces.
• Specification diagrams provide machine compatibility, dimensional and weight data across multiple machine classes.

Characteristics / Technical specifications

• Warranty: 3 years
• Core technologies: patented A-synchronous grip technology; precision-engineered jaws; fully enclosed base drive for reduced operational risk
• Application: handling, positioning and adjusting railway tracks; intended for railway construction and maintenance
• Smart modular upgrades: compatible with a modular concept offering 100+ additional functions
• Variants and weights:
  • MD 3.0: Recommended machine operating weight 3–6 t; Arms weight: 130 kg / 287 lbs; Total Grapple weight: 305 kg / 672 lbs (excludes connection plate)
  • MD 6.0: Recommended machine operating weight 5–9 t; Arms weight: 170 kg / 375 lbs; Total Grapple weight: 405 kg / 893 lbs (excludes connection plate)
  • MD 9.0: Recommended machine operating weight 8–14 t; Arms weight: 235 kg / 518 lbs; Total Grapple weight: 495 kg / 1091 lbs (excludes connection plate)
• Machine compatibility: primarily designed for excavators within the specified operating weight ranges
