Push-in terminal block TP6-2-PE
DIN rail-mountedspringgrounding

Push-in terminal block - TP6-2-PE - Ningbo SUPU Electronics Co., Ltd. - DIN rail-mounted / spring / grounding
Push-in terminal block - TP6-2-PE - Ningbo SUPU Electronics Co., Ltd. - DIN rail-mounted / spring / grounding
Push-in terminal block - TP6-2-PE - Ningbo SUPU Electronics Co., Ltd. - DIN rail-mounted / spring / grounding - image - 2
Add to favorites
Compare this product

Characteristics

Mounting
DIN rail-mounted
Connection
push-in, spring
Other characteristics
IEC, copper, grounding
Cross-section

Max.: 10 mm²
(0.02 in²)

Min.: 0.5 mm²
(0 in²)

Description

Connection method:Push-in connection,Number of connections:2,Number of levels：1,Cross section:20-8AWG Parameters Width 8.2mm Number of levels 1 Number of connections 2 Connection method Push-in connection Protection Level IP20 Insulation material PA66 Insulation material group Ⅰ Contact material Copper alloy Contact plating Sn,Plated Ambient temperature (operation) -40℃～105℃ Ambient temperature (assembly) -5℃～70℃ Ambient temperature (storage) -25℃～60℃ Permissible humidity (storage/transport) 30%～70% Technical data IEC Rated Current / IEC Rated Voltage / Overvoltage category Ⅲ Degree of pollution 3 Rated impulse voltage 8KV UL Rated Current / UL Rated Voltage / Stripping length 10-12mm Use group / Rated cross section 20-8AWG
