Circular saw PERRIS 350 AP

for non-ferrous metalsfor aluminumfor pipes

Product
Automatic circular saw IBP PEDRAZZOLI PERRIS 350 AP for cutting light alloys.

FEATURES

• One-speed three-phase drive (230V 50Hz or 400V 50Hz).
• Head-block rotation mechanism for angled cuts up to 45° left, 45° right and 45° off the vertical.
• Two pneumatic vices adjustable lengthwise and laterally.
• Pneumatic cylinder for head movement with brake for speed adjustment.
• Two blade rotation speeds obtainable by changing pulleys.
• Perfectly balanced tilting head on shielded ball bearings.
• 600 mm step feeder controlled by pneumatic cylinder; repeater up to 9 steps (max reach 5400 mm).
• Maximum feeder collet opening 177 mm.
• Programmable piece counter and feeder speed adjustment valve.
• Minimum scrap on final cut 360 mm.
• Ammeter, emergency push button with key and lockable switch on control panel, and nebulizer.
• Complete protection guard with rapid blade change system.
• Instruction book and set of maintenance keys included.
• Blade not supplied with machine.

Cutting capacity
Round tubes:
45° left: 95 mm
0°: 100 mm
45° right: 95 mm
60° left: 55 mm

Square sections:
45° left: 95 mm
0°: 95 mm
45° right: 90 mm
60° left: 50 mm

Rectangular sections:
45° left: 130 x 55 mm
0°: 155 x 90 mm
45° right: 130 x 55 mm
60° left: 150 x 40 mm

Accessories on request

• Copper cutting kit.
• Widia blade.
• Antiburr assembly.

Technical specifications

• Model: PERRIS 350 AP
• Dimensions (L x W x H): 600 x 1100 x 1300 mm
• Work plane height: 790 mm
• Weight: 400 kg
• Power supply: one-speed three-phase (230V 50Hz or 400V 50Hz)
• Blade speeds: two speeds obtainable by changing pulleys
• Head rotation for angled cuts: up to ±45° and 45° vertical
• Pneumatic features: two pneumatic vices adjustable lengthwise and laterally; pneumatic cylinder for head movement with brake; 600 mm step feeder controlled by pneumatic cylinder
• Repeater: up to 9 steps (max reach 5400 mm)
• Maximum feeder collet opening: 177 mm
• Programmable piece counter
• Minimum scrap on final cut: 360 mm
• Feeder speed adjustment valve
• Ammeter
• Emergency push button with key and lockable switch on control panel
• Nebulizer
• Complete protection guard with rapid blade change system
• Includes instruction book and set of maintenance keys
• Blade not supplied with machine
