Water pump PVDF1/2PTFE-EX
acidfor solventsfor bases

water pump
water pump
Add to favorites
Compare this product


Characteristics

Media
water, acid, for solvents, for bases, oil, for diesel
Operation
pneumatic
Priming
self-priming
Technology
diaphragm
Domain
industrial
Other characteristics
dry, adjustable, ATEX, plastic
Applications
transfer, cooling
Flow

50 l/min (13.2086 us gal/min)

Pressure

7 bar (101.526 psi)

Description

The ATEX pump series has been specially designed for transferring potentially explosive atmospheres of fluids such as water, gasoline, diesel, alcohol, toluene, trichlorethylene, acetone and white spirit. Pumps designed for the transfer of aggressive and/or viscous liquids. Plastic pumps are recommended for strong acids and for bases. Dry self-priming pumps. The priming height varies depending on whether the pump is dry or wet. Adjustable flow rate by adjusting the pressure and flow rate of the air (see the accessories). In case of dry running, the pump continues to run without overheating or wear. If the delivery of liquid is stopped, the pump stops automatically without getting damaged. Characteristics More Information FLUID Acid, Adblue, Water, Petrol, Diesel, Oil, Windscreen fluid / Cooling liquid, Solvent TECHNOLOGY Membrane ATEX Yes PUMP MARKING Ex II2 GD IIB/IIC 95°C PUMP Bare MAX FLOW RATE 50l/min ORIFICE 1/2’’ MATERIALS Conductive PDVF BALLS PTFE SOCKETS PVDF OTHER CONTACT PARTS Hastelloy® C MAX. VISCOSITY 5000 cPo PRESSURE 7 bars DRY MEMBRANE 6 m WET MEMBRANE 8 m AIR CONSUMPTION from 3 to 22 Nm3/h MEMBRANE PTFE PARTICLES 3 mm
