Radar level transmitter RIL400

for solidsfor sludgeRS-485

RIL400 is a two-wire 26 GHz Radar Level Transmitter, for measuring ranges up to 20 m. Suitable for continuous monitoring aggressive liquids in storage tanks, in process tanks with agitators, vaporising liquids, substances with low dielectric constant or suitable for small, tall and narrow vessels. This radar level transmitter has an on-board display with configurable keyboard for programming. With the frequency of 26 GHz a narrow and concentrated radar cone is created which allows the use of small antennas with a reduced sensitivity for fixed obstacles. Benefits The high frequency of 26 GHz allows the use of small antennas and easy monitoring in the nozzles Insensitivity to false echoes due to fixed obstacles Reduced dead zone for an improved minimum measuring range up to 50 mm PRODUCT FEATURES Programming method - From keyboard Viewing Modes and signals - Using display Documentation included - English instructions manual Antenna type - Cylindrical Mounting - From the top Measurement site - Tank Measurement type - Without contact Sensor type - Radar Integrated temperature sensor - None Properties of the fluid - Aggressive, Foamy, Presence of suspended solids REGISTRY FEATURES Display - Yes Display version - Compact version Display technology - LCD B/W Touchscreen - No
