Sliding gate valve 8023
electropneumaticpneumatically-operatedshut-off

Sliding gate valve - 8023 - Schubert & Salzer Control Systems GmbH - electropneumatic / pneumatically-operated / shut-off
Sliding gate valve - 8023 - Schubert & Salzer Control Systems GmbH - electropneumatic / pneumatically-operated / shut-off
Add to favorites
Compare this product

Go to the Schubert & Salzer Control Systems GmbH website for more information

Characteristics

Type
sliding gate
Operation
electropneumatic, pneumatically-operated
Function
shut-off, regulating
Media
for hot water, for cooling water, for gas, for air, for steam, for oxygen, for natural gas, for CO2, propane
Body$
wafer, NAMUR
Applications
for industrial applications, for the food industry, for wafers
Material$
stainless steel
Other characteristics
ANSI, for aggressive media
DN

Max.: 250 mm
(9.843 in)

Min.: 15 mm
(0.591 in)

Pressure

Max.: 100 bar
(1,450.4 psi)

Min.: 10 bar
(145 psi)

Temperature

Max.: 530 °C
(986 °F)

Min.: -60 °C
(-76 °F)

Description

The high temperature sliding gate valve type 8023 in reinforced GS3 design with NAMUR interface for universal positioner assembly is suitable for a wide range of process applications up to 530°C. Media such as steam, liquids, gases, etc. can be precisely controlled even in the high-temperature range. Moreover for high speed and cycling applications this valve is a clear choice. Size: DN 15 - DN 250 Pressure: PN 10/40 ANSI #150, #300 Material: Stainless steel Body 1.4408 Cover 1.4404 Temperature: Media temperature: -60 °C up to 530 °C Special versions available on request. Connection - Wafer type design Positioner - Pneumatic Electro-pneumatic Digital Without positioner for on/off operation Accessories - Metal bellows Limit switch Position feedback Manual override Pilot valve . . .
