Sliding gate valve 8026
electropneumaticpneumatically-operatedshut-off

sliding gate valve
sliding gate valve
Add to favorites
Compare this product


Characteristics

Type
sliding gate
Operation
electropneumatic, pneumatically-operated
Function
shut-off, regulating
Media
for cooling water, for gas, for air, for oxygen, for natural gas, for CO2, propane
Body
wafer, stainless steel
Applications
cryogenic, for wafers
Other characteristics
ANSI, with integrated positioner, for aggressive media
Temperature

-200 °C (-328 °F)

Pressure

Max.: 40 bar (580.2 psi)

Min.: 10 bar (145 psi)

DN

Max.: 100 mm (3.937 in)

Min.: 15 mm (0.591 in)

Description

This low temperature control valve, with its integrated positioner, is suitable for a wide range of cryogenic applications up to - 200°C. •Size: DN 15 - DN 100 •Pressure: PN 10/40, ANSI #150, #300 •Material: Stainless steel 1.4408 •Temperature: Media temperature down to -200 °C Connection: Intermediate flange version Positioner: Digital positioner type 8049 Electro-pneumatic positioner type 8047 Pneumatic positioner Positioner with integrated process controller Positioner with mounting acc. to NAMUR standard (lateral) Accessories: Limit switch Position feedback
