Sliding gate valve 8621 GS3pneumatically-operatedflow controlregulating
Add to favorites
Compare this product
Characteristics
- Type
- sliding gate
- Operation
- pneumatically-operated
- Function
- flow control, regulating
- Media
- for liquefied petroleum gas, for water, for oil, for chemical products, for fuel, for inert gases, biogas, for air, for steam, for liquefied natural gas, for compressed air, for oxygen, propane, for liquified gas, for CO2, for natural gas
- Body
- flange, stainless steel, carbon steel
- Applications
- for the chemical industry, for industrial applications, flange, for steam turbines, for water, for burners, for explosive atmospheres, for water purification systems, for water systems, high-precision, for process applications, for heating, for liquids, for lubrication systems, for pipe, refinery, for the petroleum industry, for the gas industry, for gas turbines, fuel
- Number of channels
- 2/2-way
- Fluid specification
- for aggressive media, for corrosive fluids, for fluids with lubricating properties, for medium-viscosity products
- Other characteristics
- ANSI, normally closed, normally open, pneumatically-operated, for explosive atmospheres, with integrated positioner
- DN
Max.: 200 mm
(7.874 in)Min.: 15 mm
(0.591 in)- Pressure
Max.: 50 bar
(725.2 psi)Min.: 0 bar
(0 psi)- Temperature
Max.: 350 °C
(662 °F)Min.: -60 °C
(-76 °F)
Description
The pneumatic flanged sliding gate control valve type 8621 in GS3 design with integrated positioner designed according to ASME B16.34, API RP 553, API 598, ASME B31.1 and ASME B31.3 incl. flange connection according to ASME B16.5 is suitable for a wide range of process applications. Media such as steam, liquids, gases, etc. can be handled perfectly.
Size:
DN 15 - DN 200
Pressure:
ANSI #150, #300
Material:
Stainless steel 1.4408 / CF8M
Carbon steel 1.0619 / WCC
Temperature:
Media temperature: -60°C up to 350 °C
Connection
Flange design acc. ASME B16.5 RF
Positioner
Digitaler positioner type 8049
- 2-wire, 4-wire
- Ex-Pro explosion-proof
- IO-Link
- Integrated process controller IPC
Pneumatic and electro-pneumatic positioner type 8047
- 2-wire
- Ex version
Positioner with mounting acc. to NAMUR standard
Accessories
Metal bellows
Limit switch
Position feedback
Manual override
Pilot valve
. . .
Versions
NACE MR0175, ASME B31.5 (Refrigeration Piping and Heat Transfer Components)
ASME B31.8 (Transmission and Distribution Piping Systems)
ASME B31.9 (Building Services Piping) on request
