Water pump MU...-MK-PMwith electric motorself-primingcentrifugal
Add to favorites
Compare this product
Characteristics
- Fluid
- water
- Operation
- with electric motor
- Priming
- self-priming
- Technology
- centrifugal
- Mobility
- stationary
- Domain
- industrial
- Material
- cast iron, sheet steel
- Protection level
- maintenance-free
- Other characteristics
- compact, suction, close-coupled, with frequency converter
- Flow
Max.: 24 m³/h
(847.552 ft³/h)Min.: 0 m³/h
(0 ft³/h)- Head
Max.: 100 m
(328'01" )Min.: 0 m
(0'00" )- Power
Max.: 5.3 kW
(7.21 hp)Min.: 1.5 kW
(2.04 hp)- Fluid temperature
Max.: 300 °C
(572 °F)Min.: -100 °C
(-148 °F)- Length
214 mm
(8 in)- Width
245 mm, 305 mm
(9.65 in, 12.01 in)- Height
457 mm, 568 mm
(17.99 in, 22.36 in)- Weight
Max.: 40 kg
(88.18 lb)Min.: 13 kg
(28.66 lb)
Description
Close-coupled pumps with magnetic coupling
Operation with frequency converter only
Within the displayed characteristic curve every operating point can be selected by parameterizing the drive accordingly
Power consumption depending on load and speed
Media
Version spheroidal graphite cast iron:
Material design
Stainless steel
Spheroidal graphite cast iron
Suction connection
G 1 1/2 / SAE 1 1/2
Pressure connection
G 1 / SAE 1
Sealing
Separating can / Magnetic drive
Applications
Advantages
Compact design
Leakage-free and maintenance-free due to magnetic coupling
High motor efficiency
