CO2 laser marking machine TH-CO2LMS series

paperleatherrubber

Product summary
This equipment is especially suitable for marking and engraving on non-metallic materials such as acrylic (plexiglass), bamboo, wood, resin, plastics, rubber, paper, textiles, leather, electrical appliances and IC components.

Features

• CO2 far-infrared RF excitation laser with stable output, long service life and suitable laser mode for continuous industrial operation.
• Low operating and maintenance costs compared with other laser types.
• Full computer control with an intuitive interface; compatible with common design software for easy file input.
• Key components sourced from reputable suppliers in the United States and Germany.
• High-speed galvanometer scanning system optimized for industrial mass production.

Product attributes

• Commodity name: CO2 Laser Marking Machine
• Commodity ID: 1475857205088112640
• Laser power: 10W–100W
• Processing format: 100×100 mm (optional)

Specifications (table)
Device model: TH-CO2LMS10 | TH-CO2LMS30 | TH-CO2LMS50 | TH-CO2LMS60 | TH-CO2LMS100
Wavelength: 10.6 µm
Power: 10W | 30W | 55W | 60W | 100W
Engraving range: 100×100 mm (optional)
Engraving line speed: ≤ 7000 mm/s
Minimum line width: 0.1 mm (dependent on material)
Minimum character size: 0.5 mm (dependent on material)
Repeatability: ±0.005 mm
Protection rating: IP54
Cooling method: Air cooled (standard); water cooling (optional)
Voltage: Two-phase AC 220V
Recommended operating environment: Temperature 15°C–30°C; Humidity 45%–75% RH

Sample display
Marking samples illustrate marking on a range of non-metallic substrates suitable for identification, decorative engraving and industrial labeling.

Technical specifications

• Laser type: CO2 far-infrared RF excitation laser
• Available power range: 10W–100W
• Typical engraving area: 100×100 mm (optional)
• Maximum engraving line speed: ≤ 7000 mm/s
• Minimum achievable line width: 0.1 mm (material dependent)
• Minimum character size: 0.5 mm (material dependent)
• Position repeatability: ±0.005 mm
• Protection rating: IP54
• Cooling: Air cooled (standard); water cooling optional
• Supply voltage: Two-phase AC 220V
• Recommended operating temperature/humidity: 15°C–30°C / 45%–75% RH
