Piston compressor VGK 420-2,2/90A P

airelectrically-poweredstationary

Overview
Cast-iron piston compressor VGK 420-2,2/90A P. Two-cylinder 2/1 configuration in cast iron provides durability and wear resistance for key components. The compressor delivers an intake flow of 420 l/min and an effective delivery of 340 l/min; rotational speed is 1276 rpm for smooth, stable compressed air supply.

Power and working pressure
Motor power: 2.2 kW; maximum working pressure: 10 bar. Designed for stable and even operation under typical industrial loads.

Construction and dimensions
Vertical tank with 90 L capacity provides air reserve. Dimensions: 630 × 540 × 1240 mm. Weight: 100 kg. Robust construction ensures installation stability and easy mounting.

Technical data:
Tank capacity L: 90
Cylinders: 2/1
Intake l/min: 420
Delivery l/min: 340
Pressure bar: 10
Power kW: 2.2
Voltage V: 230
Weight kg: 100
Length mm: 630
Width mm: 540
Height mm: 1240
Speed rpm: 1276

Features / technical specifications

• Tank capacity: 90 L
• Cylinder arrangement: 2/1 (two-cylinder)
• Intake flow: 420 l/min
• Effective delivery: 340 l/min
• Maximum working pressure: 10 bar
• Motor power: 2.2 kW
• Supply voltage: 230 V
• Rotational speed: 1276 rpm
• Dimensions (L × W × H): 630 × 540 × 1240 mm
• Weight: 100 kg
