Plastic film bag agglomerator PNAG-100

Putting the waste into the machine pot body makes the material be quickly cut by the high-speed rotating blade and the fixed blade shear. The material moves along the pot body wall by centrifugal force, while being turned up and down by the paddle, moving towards the center. Friction between the material, pot wall, and blades produces heat, raising the temperature to a half-plastic condition and forming small lumps. Before blocking occurs, quantitative water is sprayed onto the material. The cold water gasifies upon contact with the hot material, quickly cooling the surface and preventing blockage. The rotary and fixed blades then crush the material into irregular particles. Color pigments can be added as needed. - Application Areas: Waste Non-Woven Diapers Sanitary Napkin Agglomerator Machine is used to agglomerate plastic scrap such as wet or dry recycling non woven, diapers, sanitary napkin, plastic films, PET fiber, woven bags, Soft PVC, LDPE, HDPE, PS, PP, foam PS, PET fibers, and other thermoplastics. - Description: This machine is suitable for waste thermoplastic thin film and products with wall thickness less than 2 mm for immediate granulation. It can process waste or thin film of soft PVC, high and low-pressure polyethylene, polypropylene, polystyrene, and other thermoplastics, as well as foaming polystyrene products for granulation. - Working Principle: Waste is placed into the pot body, quickly cut by high-speed rotating and fixed blades, and moved by centrifugal force and paddles. Friction generates heat, raising the temperature to a semi-plastic state, forming small lumps. Water is sprayed to cool the material and prevent blockage, then the material is crushed into particles. Pigments can be added as needed. - Components: - Stainless Steel Material: Material contact parts use 304 stainless steel, finely welded and polished for easy cleaning. - Arc Barrel Bottom: The arc design ensures no dead angle in stirring and no residue in discharging. - External Insulation of Barrel: The barrel is covered with a heat insulation layer to reduce heat loss and protect operator safety. - Motor: Uses Siemens, Wanan, and other domestic brands of pure copper motor, stable and reliable, customizable. - Forced Oil Pump System: For agglomerator bearing, cools and lubricates the bearing (except PNAG-100). - Electronic Control: Frequency conversion control, conforms to CE/CSA standards. - Metal Detector (Optional): Ferrous metal permanent magnetic belt or metal detector prevents metal from entering and protects blades. - Conveyor (Optional): Plastic is conveyed to the agglomerator via belt; speed is automatically adjusted based on fullness and current. - Features: - The agglomerator integrates crushing, mixing, and coloring in one process. - Compact footprint. - Simple mechanical structure, easy operation. - Adjustable blade gap, easy knife change. - High production efficiency, low energy consumption. - No significant damage to the molecular structure or physical properties of raw material. - Technical Specifications: - Model: PNAG-100, PNAG-200, PNAG-300, PNAG-500, PNAG-600, PNAG-800, PNAG-1500 - Spindle Speed (r/min): 1050, 1050, 950, 850, 750, 750, 650 - Output (kg/h): 80-120, 100-150, 150-250, 300-400, 350-450, 500-600, 800-1000 - Motor power (kw): 37, 45, 55, 90, 110, 132, 200 - Voltage (V): 380 - Volume (L): 100, 200, 300, 500, 600, 800, 1500 - Weight (kg): 1000, 1200, 1800, 2500, 2700, 3000, 5000 - Dimension (m): 1.7*0.75*1.5, 1.7*0.85*1.5, 2*0.85*1.6, 2.3*0.95*1.7, 2.3*1.1*1.75, 2.5*1.25*1.8, 3*1.6*2.1 - Rotating Blades Qty (pcs): 2, 2, 2, 4, 4, 4, 4 - Fixed Blades Qty (pcs): 6, 6, 6, 8, 8, 8, 8 - Lubrication Method: Grease lubrication, Pressure lubrication - Related Equipment: - Non Woven Diapers Sanitary Napkin Granulator - Single Screw Plastic Pellet Making Machine - Technical Characteristics / Specifications: - Material contact parts: 304 stainless steel - Arc barrel bottom for efficient mixing and discharge - External insulation for safety and heat retention - Pure copper motor (Siemens, Wanan, etc.) - Forced oil pump system (except PNAG-100) - Frequency conversion electronic control (CE/CSA compliant) - Optional metal detector and conveyor
