Holding solenoid WL4020

linearlockingsorting

Product Overview
The WL4020 tubular push-pull solenoid is an electromechanical linear actuator designed for rapid, repeatable push and pull motions in industrial automation. Typical construction includes a copper coil, steel plunger, return spring and zinc-plated carbon-steel housing. (Note: product page reference WL4020; datasheet/model entry appears as WL4042.)

Key Features

• Compact tubular design suitable for integration in confined assemblies
• Fast response times (millisecond order) and repeatable linear travel
• Stable push/pull output across short strokes
• Available in DC 12 V and 24 V (other voltages customizable) and multiple stroke options
• Low maintenance, energy-efficient coil design
• Options for different mounting types, lead lengths and duty cycles; customization available

How It Works
When DC power is applied, current through the coil windings generates a magnetic field that attracts or repels the steel plunger, producing linear push or pull movement. Removing power allows the return spring to reposition the plunger. Output force depends on coil voltage/current, stroke length, plunger material and magnetic circuit geometry.

Applications

• Industrial automation: ejection, locking, switching, sortation and conveyor interfaces
• Vending machines, smart lockers and electronic locking mechanisms
• Compact linear actuation in medical and diagnostic devices
• Household appliances, packaging and textile machinery
• Automotive actuation for locking, fuel or transmission components
• High-speed mechanisms in robotics and sorting systems

Advantages & Disadvantages

• Advantages: small footprint, rapid response, predictable repeatability, customizable electrical/mechanical parameters
• Disadvantages: coil heating at high duty cycles (may reduce lifetime); force falls with increased stroke; lower peak forces than pneumatic/hydraulic systems for heavy loads

Troubleshooting Summary

• Weak force: verify supply voltage, coil resistance and excessive stroke; check for magnetic interference
• Overheating: reduce duty cycle, verify correct voltage and improve ventilation
• Sticking or slow movement: inspect for dirt, corrosion, lubrication issues or bent/worn parts
• Electrical faults: measure coil resistance for open or shorted windings and inspect leads

Technical Data & Notes (from product datasheet)

• Brand: Weilong Technology
• Model number (datasheet): WL4042
• Page reference / product title: WL4020
• Rated voltage: DC 12 V or 24 V
• Rated power: 20–30 W
• Type: Tubular push-pull solenoid
• Holding force: ~10–20 N (≈1.8 kg noted in table)
• Stroke: 5–10 mm
• Reset time: ~30 ms
• Service life: ~100,000 cycles
• Insulation class: F; Hi-Pot: AC 600 V 50/60 Hz 2 s
• Operating temperature: -10 °C to 100 °C
• Typical working duty: 10%–30% (design may support 1%–100%)
• Material: carbon steel housing with zinc plating
• Lead wire length: 200 mm
• Certifications: CE, RoHS, ISO9001
• Warranty: 1 year; MOQ: 1000 pcs; Supply ability: 5000 pcs/week; Lead time: ~30 days; Port: Shenzhen

Characteristics / Technical Specifications

• Model: WL4020 (page) / WL4042 (datasheet)
• Operating voltage: 12 V DC or 24 V DC (custom options available)
• Rated power: 20–30 W
• Type: tubular push-pull (bidirectional linear actuation)
• Holding force: approx. 10–20 N (reference value 1.8 kg)
• Stroke range: 5 mm, 10 mm (typical)
• Reset/response time: ~30 ms
• Service life: ~100,000 cycles (application dependent)
• Housing material: carbon steel, zinc plated
• Lead length: 200 mm; dimensional tolerance: ±0.1 mm
• Operating temperature: -10 °C to 100 °C; insulation class F
• Duty: design 1–100% (typical use 10%–30%)
