From the idea to the realization, SCHMIDT Technology offers turn-key
systems.
A team of experienced and highly specialised engineers and toolmakers
create solutions from a simple workstation to a fully integrated assembly
line.
Extensive knowledge in press applications leads to efficient
design and manufacturing of press workstations; by integration of other
components such as bowl feeders or ball screw units.
Flexible hardware, sophisticated controls and safety technology are the
fundamentals for machine high efficiency. Avoiding machine
down-times and reducing waste materials (NOK) are the key factors to
economic production.
The pneumatic press EP15 was built for semplifying and automating the hot mounting process. The operator has only to select, from the digital display, the appropriate mounting cycle for the resin type which is going to be used. Preset mounting cycle parameters (temperature and timing of heating and cooling), optimised for each type of resin, are stored in the control panel, and can then be selected for starting the embedding cycle. At the end of each cycle, the cooled sample can be pulled out from the heating chamber and passed onto the grinding/polishing process.
The two twin-channel PME modules (MP85 and MP85DP) from HBM provide the optimum solution for monitoring press-fit and assembly operations.
Almost any commercially available transducer can be connected to the amplifiers which operate synchronously and in parallel. The industrial design and the standardized CANopen and Profibus DP interfaces, or digital I/Os alternatively ensure optimum connectivity to the automation environment.
Features and benefits:
Twin-channel amplifier
Comfortable integration into automation system via field bus interfaces
Intelligent signal conditioning and powerful algorithms for monitoring of the fitting process
Results can be saved directly in SPC format
Industrial design.
Easy to install and resisting to 20 bars of pressure, stainless steel press fitting offers a wide range of use for an excellent installation security and efficiency… Shipbuilding, compressed air, building, industry…
