Voortman has developed five models of band sawing systems especially for sawing structural steel. Four sawing machines are developed for mitre cutting. The fifth is designed for straight cutting of profiles. The sawing machines are equipped with a control system for the selection of the mitre angle and the automatic sawing cycle.
The band speed is frequency controlled and the feed rate is automatically controlled to suit the profile type and size.
The sawing machines can be combined with a length measuring system with stop truck. The sawing machine can also be combined with a drilling system for sawing and drilling in one continuous process.
These sawing machines are available with different cutting capacities. The VB600 for sawing max. 450 x 620 mm, the VB750 for 450 x 750 mm, the VB1050 for 500 x 1.130 mm and the VB1250 for 600 x 1 250 mm. |
|
- Fully automatic sawing system
- 1/2" to 8" thick material
- From 10" to 5' Circles
- Hydraulic Professional turntable and Clamping Ram
- 20 or 30 HP Arbor Motor
- Precision Tolerances to +/-0.007
- Surface Finishes to 12 Micro-inch
- High Production Sawing Rates
- Rapid sawing speeds
- Eliminates Scribing |
|
The SIGMA PRO are electrical workshop band cutting machines for plastic tubes.
The SIGMA PRO were specially designed to perform easy cuts with a
wide range of inclinations (up to 67,5°), therefore becoming the ideal
right-hand device to use with the ALFA professional fittings machines for the
construction of special fittings (bends, wyes, tees and crosses), by
joining pipe segments. |
|
SUPER TRAD 301 SO DIGIT
Semi-automatic band sawing unit for solid and metallic profiles. Also steel, stainless steel, brass, aluminium, copper.
Robust, versatile and handly, for professional duty.
Multi-function digital controller with piece-counter, piece presetting, work timer, diagnosis and alarm messages. adjustable sawframe downfeed speed.
Two ways miter cutting (45° - 0° - 60°)
The digital controller offers three different operating functions:
- SEMI-AUTOMATIC cutting cycle
- MANUAL cutting cycle
- MULTI-MODE cutting cycle |
|
electro-hydraulic and/or electro-pneumatic band saws designed to cut solids and sections up to 330 mm from 45° right to 60° left
|
|
manual, semi-automatic to automatic
Pivot-type Machines
Especially suited for use in job shops. Important characteristics are: small foot print, easy and accurate miter adjustment, excellent cutting performance.
Double Column Machines
For higher demands and materials with tensile strengths up to 1400 N/mm2. The double-column design allows a better application of the needed feed force. Today’s state of technology are bevel spur pinion drives as drive source in connection with a frequency-controlled professional saw motor, maintenance-free supplier of linear guides
Production Sawing machines
Modern control technology with stored cutting data of all current materials. After entry of material-grade and number of pieces, cutting speed and feed rate are adjusted automatically. Machines with carbide blades cut high tensile alloys with tensile strengths up to 1900 N/mm2 economically . Due to a higher blade life and reduced cutting times, an amortization of the higher machine costs is achieved.
Large Bandsawing Machines / Block Bandsawing Machines
To cut plates from large size blocks and plates. Small to very large working ranges and table loads up to 40 tons.
Automatic machines and machines designed for notching available as well.
|
|
Shark 452 CCS, bandsawing machine TO EXECUTE SINGLE CUTS WITHOUT THE NEED OF AN OPERATOR on sections and beams up to 450x330 mm at 0°.
- It is a very versatile machine to cut from 60° left up to 60° right.
- Functioning: after having manually fed the bar and clamped the material, you start the cut which is done using the weight of the head controlled by a spring so as to balance the sawing head. By means of an hydraulic brake with a cock you can regulate the downfeed speed. Once the cut has been finished the sawing head is raised manually so that you can feed the bar again (as OPTIONAL you can have the head which returns to top position by means of an hydraulic unit after each cut).
In the Shark 452 CCS MA model (with an automatic vice) vice opens/closes by means of a button on the control panel.
A FEW FEATURES:
Electric panel (wiring totally identifiable, stand-by, main lockable disconnect switch, pole change switch, emergency stop, motor magneto thermal overload, minimum tension coil, protection against missing phase, low tension safety center 24V).
Mechanical variator to adjust infinetly variable blade speed from 20 to 100 mt/min.
Professional cabinet which can be easily positioned keeping a visual control over the machine.
Manual band tensioning with visualization on LCD by electronic transducer.
Front bandguide with sideways movement on a linear guide with recirculating ballscrews.
Manual clamping system by means of vice screw which professional slides on preloaded linear guides with recirculating ballscrews
Coolant tank inside the steel base and drawer to collect chips which can be replaced with a motorized chip evacuator (OPTIONALS)
Electric pump to lubricate and refrigerate the blade.
Wire chip professional brush for blade cleaning which is driven by the motor pulley.
Adjustable cut to measure device to make cuts of the same length.
Machine predisposed for handling with movement equipment.
Bi-metal band for solids and sections.
Service keys and instructions manual, for maintenance and spare part list.
|
|
Horizontal sawing system to cycle automatic rifle for cut of bars or makes destined onerous intense activities where an elevated productivity is demanded. The sturdier sawing machine to horizontal tape is considered and reliable today in its segment, it guarantees functionality and high productivity.
Besides the installation facility it joins a remarkable precision in the cut thanks to the descent velocity of the variable arc based on the section of the material and to the shear stress. |
|
| Sawing line to fixed table and gantry furnishing devised for the cut of heavy pieces much and great dimensions. It allows the vertical, horizontal and oblique cut in order to operate correctly in the cut of lingotti and forged pieces as also large blocks for steel traders. |
|
Manual bandsawing machines, designed to cut sections and solids materials from 45° right up to 60° left.
|
|
SHARK332 SXI evo
One model only to take place of the two leading models of its class: SHARK332 SXI and SX. Taking after the first one the high performances and from the second...the price !!!
Technical features::
Hydraulic unit equipped with high efficiency electro-valves and high pressure (200 bar) hydraulic pump manufacturers;
Main electronic control of the machine made by new generation of microns and located completely inside the main control box;
Control box positioned on the front side of the steel base with a 180° swivelling which allows the operator to position it wherever needed;
Visualization by digital display of alarms, diagnostic, machine operations (cutting time, piece industrial counter, blade motor amperage, head position, blade speed, blade tensioning);
Predisposed to be connected to SMV3000/3000 PRO;
Manual and semiautomatic-dynamic mode: STANDARD.
|
|
The point of force of this vertical sawing machine to flowing arc is the deep one sbraccio of the arc portalama, this allows to the cross-sectional cut of wide plates using a blade of inferior dimensions regarding the horizontal sawing machines since always comes employed in the cut of the smaller side.
The plan is constituted from sturdy industrial rollers that support the material and of it they facilitate the feeding for the positioning to measure. The machine, available in the semi-automatic or equipped version of automatic feeder, is an indispensable sawing machine for the steel traders. |
|
| 2-column-linear guided automatic metal bandsawing machine for straight cuts. Suitable for high professional production industries and steel stockholders. For fast cutting of tough materials. User friendly NC contol system with clear text message professional display. |
|
* MEBA Profi-Line : Metal-Bandsawing-Machines for straight an mitre cuts in manual, semi automatic or automatic performance.
* MEBA Eco-line : 2 column linear guided Metal-Bandsawing-Machines for straight an mitre cuts in semi automatic or automatic performance |
|
A range of bandsaws which combines accurate cuts and high speeds, adapted to all types of profiles used in steel construction.
Internationally well-known for their robustness, accuracy and speed of execution, Behringer industrial saws allow the straight and mitre cut of all types of profiles.
Being a natural additional equipment to our HD fast drilling machines, the drilling sawing line represents the key element of the performance in steel construction workshops.
|
|
SPARTAN PA10, PA13/3, PA18/2
Also available with the Marvel PCII Controller. |
|
| 2-column guided metal bandsawing machine for straight and mitre cuts in semi automatic or automatic performance with patented mitre system (DG / DGA) |
|
2-column-linear guided metal band- sawing machine for straight and mitre cuts in semi automatic or automatic performance
stepless, manual adjustment of mitre angle to professional scale, from 90° to 30°. |
|
| The MEBA TOP-LINE is the most flexible solution for sawing in structural steel engineering an plant construction as an single machine in connection with the modular MEBa material handling devices or combined with a Peddinghaus-drill line. |
|
STANDARD SPARTAN MODEL Hercules S330 SWIVEL HEAD, HIGH SPEED, HORIZONTAL, METAL CUTTING BANDSAW WITH 2 H.P., AND 60 DEGREE HEAD SWIVEL
Capacity @ 90°: 13" x 18" (330 x 460mm) 13" round (330mm)
Capacity @ 45°: 12" x 12" (300 x 300mm) 12" round (300mm)
Capacity @ 30°: 6" x 11" ( 150 x 280mm) 6" round (150mm)
Blade: 13' 10" x 1" x .035" (4216 x 25 x .9 mm)
Blade Tension: Manual tension (30,000 psi) provides consistent square cutting accuracy. The blade tension devise comes to a positive stop assuring the proper tension after each blade change.
Speed Range: Blade speed is variable through a precision balanced step pulley and heavy-duty worm gear transmission. Blade speeds are 90, 140, 220 and 320 SFPM. The broad speed range allows for optimum cutting of a large spectrum of materials.
Hydraulic Down Feed: Infinitely variable feed rate is hydraulically controlled for fast, accurate cutting. Settings are made at the operator's station.
Motors: Blade Drive: 2 H.P. (1.5kW). Drive motor is dual voltage, 230/460 Volts, 3 Ph, 60 Hz. 208 volt conversion is available for an added charge.
Blade Industrial guides: Carbide Blade Guides provides reduced vibration, heat and blade stress providing longer blade life and accuracies of + .002 per inch of cut material.
Chip Professional brush: Powered from the drive professional wheel of the industrial saw, the brush changes speed with the blade to assure that chips are being removed from each gullet, improving cutting performance and blade life.
Vise Jaw: The Quick Acting vise jaw arrangement makes material clamping fast and easy while always holding the work piece secure. The cast iron vise jaws can be quickly positioned next to the material size, then manually clamped using the dual cam-lock device from either the front or rear of the machine.
Swivel: The saw frame swivels a full 60 degrees for added capabilities for miter cutting. The pivot shaft has sealed bearings supplier for maintenance free operation, while a pointer and angle professional scale make setup fast and easy.
Operators Control Panel: Operation of the machine is made safe and easy from the fixed position control panel. Control Voltage is 110V.
|
|
Series 8 Mark II - Our most popular bandsaw, a truly universal machine capable of making virtually any conceivable straight or miter cut (45° right & left).
|
|
|
|
