The Dunkermotoren BG range of brushless, direct current motors (EC motors) are notable for:
Very long life
High efficiency
Highly dynamic acceleration
Good regulation characteristics
Wide speed range
High power density
Maintenance-free
Robust design
Integral Hall sensors for rotor position
Low moment of inertia
High degree of protection
Winding insulation - Class E or B
Neodymium magnets
These electronically-commutated DC motors can be combined with control electronics, gearboxes, and encoders in a modular system to provide a flexible, adaptable, market-oriented solution.
|
|
ec4more is the name for the BLDC product line of motors - a completely new development - that Bühler Motor presented for the first time to an audience of interested technical professionals at electronica, ComPaMED and SPS/IPC/DRIVES. ec4more stands for more power in the smallest of spaces and for quick and uncomplicated adaptation to special customer requirements. Its design highlight: segmented stators that enable extremely high power density in the ec4more drives.
In terms of their space requirements and exterior design, the new small brushless motors are oriented toward previous package sizes: cylindrical in diameters of 30 to 60mm and lengths of 50 to 110mm. This makes it easy to populate existing solutions with the up to 400 Watt strong new EC motors too.
Their high quality, built-in right from the start (FMEA or APQP), makes the new ec4more product line the first choice wherever maximum reliability and optimal control under extreme environmental conditions are what count.
|
|
Brushless motors are electronically commutated and have extremely long operational lifetimes
Consists of a brushless motor with integrated drive electronics
Simple to integrate 2 wire interface like a standard DC Motor
Feedback output available
No cogging
Dynamically balanced for extremely smooth performance
|
|
Electronically commutated internal rotor motors - Short but highly dynamic.
In automation, many applications are characterised by high dynamism and high torque at the same time. Spatial restrictions also mean that drives must be short, have a long service life and be maintenancefree, as replacing them can often be too expensive and time consuming. The new EC-i motors from maxon motor offer solutions that fit these requirements perfectly.
maxon's EC-i motors are designed as brushless, grooved internal rotor motors, the advantages being the rotor's low inertia, minimal detent, robust bearings and compact construction. The use of high-powered permanent magnets ensures high power density, providing great speed stability under load.
These motors are available in 40 mm diameter and in two lengths, namely
26 mm (50 Watt) and 36 mm (70 Watt). The modular system with gearheads, encoders and controllers from the maxon delivery program offers a large number of possible combinations.
EC-i motors are ideally suited for applications that require maximum dynamism in minimum space. Typical areas of application are robotics, industrial automation and security technology.
|
|
Motors in the BG range are electronically-
commutated direct current
motors (EC motors) with integrated
Hall sensors for rotor-position recognition.
Besides ball bearings, these
motors have no parts that are subject
to wear, and are thus especially suitable
for continuous operation. Their high
power density and compact form,
combined with a favourable
price/performance ratio make these
motors suitable for numerous applications.
|
|
MPP SERIES Motors
Sizes 92, 100, 115, 142, 190, 230, and 270mm
12 to 1295 in-lbs continuous torque
High torque density packaging
Segmented Lamination Design
Brushless Construction
High performance Neodymium magnets
Thermistor Protection
2000 line incremental, Resolver, Single/Multi-turn Absolute, and Serial - "Q" Encoder feedback.
Right Angle "Rotateable" connections
3 - 21 day delivery
Full Customizations available
CE / UL Compliant
|
|
Our compact drive series "encoTRive" offers a great variety of drive configurations. On the basis of the communication and control platform different types of drives can be realized: actuating drive, positioning drive and processing drive.
Our drives consist of the following elements: motor, power electronics, bus interface, position closed-loop controller and a measuring system. To complement the compact drive, you can add further components like a gear, brake or I/Os.
|
|
No cogging or preferred rotor position
No iron losses
Extremely low current consumption
Extremely light and compact
Smooth and accurate speed, position, and torque control
Electronic commutation for extremely long operational lifetime
High precision gearboxes available in all sizes
Control electronics available for all motor series
Available as linear actuator
Custom systems available from design to production
|
|
No cogging or preferred rotor position
No iron losses
Extremely low current consumption
Low audible and electrical noise
Extremely light and compact
Smooth and accurate speed, position, and torque control
Low vibration
Speeds up to 100,000 rpm
Electronic commutation for extremely long operational lifetime
High precision gearboxes available in all sizes
Feedback components available in all sizes
Control electronics available for all motor series
Custom systems available from design to production
|
|
No cogging or preferred rotor position
No hysteresis or eddy current losses
Extremely low current consumption
Ultra flat dimensions
Extremely light and compact
Smooth and accurate speed control
Speeds up to 60,000 rpm
High power rare earth magnets
Electronic commutation for extremely long operational lifetime
High precision gearboxes available
Control electronics available for all motor series
Custom systems available from design to production
Autoclavable and vacuum rated motors available
|
|
Motor Selection ...
is made easy with the wide variety of products available from AMETEK. Motor families are available in standard configurations which include .375" (9.53 mm) to 5.25" (133 mm) diameter motors, with continuous torque which ranges from 0.3 oz. in. (0.42 Ncm) to 1825 oz. in. (1288 Ncm) and wattage outputs of 2.5 to 1808. Voltage options are from 12 VDC to 74 VDC. Click More Specification for a summary of the motor products, operating voltages, speed and torque ranges sorted by motor diameter. Detailed motor information is provided on the individual product sheets.
|
|
|
ElectroCraft's RapidPower, EXC, and E-Series are fast, low vibration BLDC motors. By utilizing M-8 ceramic and rare-earth neodymium magnets, our BLDC motors provide the quick acceleration and consistent speed (up to 15,000 rpm) needed for applications such as centrifuges, fans and pumps. Sealed ball bearings and reduced torque ripple from skewed magetization also ensure a smooth operation at any speed.
|
|
There are new brushless motors with integrated drive available from Ever Elettronica. These high torque low loss motors form part of the SLIM Line, Ever's reply to the increasing market demand for high qualitative motors and drives against a friendly price.
The MT42BL is a brushless motor series with a flange size of 42 mm with integrated drive. It’s main characteristics are a speed of 4000 rpm, 3 phases, a voltage of 24 Vdc and power from 26 to 104 W, insulation class B, analogue input for speed regulation of ± 5 Vdc and digital input for the direction, output with a speed pulse (TTL) of 24 pulses / rev.
The characteristics of the bigger MT57BL brushless motor with a flange size of 57 mm with integrated drive that deviate from those of the MT42BL are a higher voltage of 36 Vdc and power from 46 to 184 W and an output with a speed pulse (TTL) of 12 pulses / rev.
|
|
Johnson Motor Brushless DC (BLDC) motors
Dimensions: Ø 42.5 x 60, shaft Ø 5 mm
Supply nominal: 120 VDC
Torque:
@ rated load 42 mNm
@ max. efficiency 42 mNm
@ max. power 84 mNm
Speed:
@ no load 7200 rpm
@ rated load 5800 rpm
@ max. efficiency 5800 rpm
@ max. power 4600 rpm
Power:
input @ no load 12.6 W
input @ rated load 40 W
input @ max. efficiency 40 W
input @ max. power 62 W
output @ rated load 28 W
output @ max. efficiency 28 W
output @ max. power 38 W
|
|
Features:
• High Torque Motor
• High Speed
• High Efficiencies
• Additional Windings Available
|
|
Key Attributes:
- Frame sizes range from 12.7 mm (0.5 in.) to 58 mm (2.3 in.)
- Speeds up to 100 000 rpm
- Torque range of 3.3 mNm (0.32 oz. in.) to 316 mNm (44.7 oz. in.)
- Speed, direction, current control option are available
- Autoclavable features available
- Versions without hall sensor
- Versions with hall effect sensors
Characteristics:
- Essentially Linear torque/speed curve, with torque proportional to current and speed proportional to voltage
- No mechanical commutation via brushes
- Improved heat dissipation
- No detent torque
- Typically used in application with variations of speed or load
- Typically used in incremental motion
Advantages:
- Ease of speed and position control
- Very long life, high reliability, insensitive to environment (no arcing), motor is dust free with reduced audible and electrical noise levels
- Overload capability
- Excellent velocity smoothness
- Very simple commutation circuitry
- Very precise speed and position control
|
|
|
The 26BC6A features an integrated electronic commutation with a 6 wire lead. The 26BC6A features a no-load speed between 5600 and 14000 rpm. The power of the 26BC6A is rated at 14 Watts at 10 krpm.
|
|
Range from 30 W to 150 W in 3 phases, 4 poles
Integrated temperature sensor
Ball bearings for improved mechanical efficiency
Protection IP54
Lifetime exceeding 20,000 hours
Very low noise level
Rated speed between 2000 and 4000 rpm
Crouzet brushless motors can integrate electronic controls allowing regulation of; the torque, current consumption, emergency stop and brake, maintain of position and speed regulation by analogue entry (0-10V) or PWM.
Crouzet brushless motors can be coupled to:
90 º Gearbox: Designed for applications where the space and noise is critical. Very quiet
Planetary Gearbox : Up to 120 Nm nominal, high efficiency, high reduction ratios, available in 1,2 and 3 stages, a compact design with diameters of 52, 62 and 81 mm.
In addition, Crouzet has developed the Motomate concept which incorporates: a brushless motor, an electronic control card and a logic controller (Millenium) to create programs dedicated to an application.
Specially designed for the following markets:
Medical: Laboratory equipment, CPAP, centrifuge, physiotherapy
Access Control: Automatic doors, gates, lifts
Industrial Machinery: Automated movements, robotics, labeling
Valves : Vacuum pumps, automatic valves
|
|
STALL TORQUE:
0.15 to 75 Nm
POLARITY:
4, 6, 8, 10 poles
RATED SPEED:
1200 - 2000 - 3000 - 4000 - 6000
INSULATION CLASS:
F
DEGREE OF PROTECTION:
IP65
MOUNTING:
IM B5
MAIN FEATURES:
CE certification
cURus certification
OPTIONS:
low inertia motors - high working speed and high acceleration
compact motors - high torque density with respect to their volume
forced ventilation (from size 63 to 100)
|
|
• Fast speed up to 50,000 rpm and up to 30W of continuous output power
• Ultra compact. At 32 mm (1.26”) diameter by 11.7 mm (0.46”) length, the nuvoDisc is over 75% shorter and over 90% lighter than typical competitor motors.
• With a weight of only 26g, applications benefit from being lightweight.
• High efficiency. Reduces power supply requirements by drawing less current,
resulting in less generated heat.
• Low vibration. High speed slotless design provides characteristic smooth operation.
*A slotted design is also available on request when detent torque is needed, for applications such as Damper Control.
|
|
Key Attributes:
- Frame sizes range from 12.7 mm (0.5 in.) to 58 mm (2.3 in.)
- Speeds up to 100 000 rpm
- Torque range of 3.3 mNm (0.32 oz. in.) to 316 mNm (44.7 oz. in.)
- Speed, direction, current control option are available
- Available with or without hall effect sensors
Characteristics:
- Essentially Linear torque/speed curve, with torque proportional to current and speed proportional to voltage
- No mechanical commutation via brushes
- Improved heat dissipation
- No detent torque
- Typically used in applications with variations of speed or load
- Typically used in incremental motion
Advantages:
- Ease of speed and position control
- Very long life, high reliability, insensitive to environment (no arcing), motor is dust free with reduced audible and electrical noise levels
- Overload capability
- Excellent velocity smoothness with no cogging
- Very simple commutation circuitry
- Very precise speed and position control
- 2-wire: on board electronics
|
|
Custom brushless motors and part sets are available using newly developed designs or Thin Gap can configure standard motor designs to achieve a wide range of efficiencies, speed, torque and horsepower. These motors are built to order and availability depends on the amount of customization and quantity.
TG 8260 Common Features
• 100 oz-in. peak torque
• 1910 watts continuous power
• Weight 27 oz
• 77% peak system efficiency
• Smooth, controllable power
• No cogging or hysteresis torque
• 24 Pole, Y Coil
Whether you need a new motor design or modifications to a standard motor, Thin Gap's team of motor specialists will create a solution that meets your application requirements. Their engineering team's toolbox includes the leading CAD and motor simulation software, as well as a fully instrumented test lab. With their full range of engineering design and application services, they have created high quality special purpose products for a wide range of applications.
Chances are, Thin Gap has already built a motor that meets your requirements. If not, their engineering team is available to develop your solution with the exact combination of speed, horsepower, torque and efficiency required without cogging or hysteresis torque.
|
|
Common features of Thin Gap's standard motors and part sets include high power density, smaller package and high efficiency, resulting in reduced power consumption that extends battery life. Standard motors are available for quick delivery with such options as Y or Delta stators, mounting configurations, Kt, Ke and HP.
TG 2340 Features
High power - .68 H.P. at 48v
600 oz-in. peak torque
85% peak system efficiency
No cogging or hysteresis
3 mounting configurations available
8 Pole, Y Coil
Typically, standard brushless motors and part sets have short delivery times with initial and small orders built in Thin Gap's Ventura, California facility and volume production transferred to Asia.
|
|
Key Attributes:
- Frame sizes range from 12.7 mm (0.5 in.) to 58 mm (2.3 in.)
- Speeds up to 100 000 rpm
- Torque range of 3.3 mNm (0.32 oz. in.) to 316 mNm (44.7 oz. in.)
- Speed, direction, current control option are available
- Sterilizable option available
- Available with or without hall effect sensors
- Customization available
Characteristics:
- Essentially Linear torque/speed curve, with torque proportional to current and speed proportional to voltage
- No mechanical commutation via brushes
- Improved heat dissipation
- No detent torque
- Typically used in applications with variations of speed or load, such as surgical or dental hand tools
- Typically used in incremental motion
Advantages:
- Ease of speed and position control
- Very long life, high reliability, insensitive to environment (no arcing), motor is dust free with reduced audible and electrical noise levels
- Overload capability
- Excellent velocity smoothness
- Very simple commutation circuitry
- Very precise speed and position control
|
|
FAST-BACK 75 ® (& size 100) (New)
Brushless drive+motor, all-in-one fully digital. Torque range from 1.1 to 7.5 Nm. 220 VAC power supply. Motion controller with CAN BUS fieldbus interface.
Integrated motor in a fashionable design. The decentralized structure gives you much more freedom in designing your machine’s installation layout. Commissioning and service are much simpler. Many advantages such as cables and control cabinet space reduction. EMC line filter suppression and dumping circuit are integrated.
|
|
* Considerable longer life (no brush wear)
* Higher efficiency, reliability and controllability
* Reduced audible noise
* Reduction of EMI & RF emissions
* Higher power to size ratio
* Perfect for installation in restricted areas, such as:
o Environments sensitive to interference
o Battery powered equipment
o Clean room environments
|
|
new series of brushless DC motor with six poles in NeFeBo magnets.
The main feature is the absence of the brushes and so improved performance:
- reduced maintenance and high reliability
- high overload capacity in all speed range
- high torque with reduced size
- high efficiency
- low inertia and high acceleration
- low noise level
- high protection
|
|
ASTRO brushless direct current motor AEM
Electronically regular direct current motor
Compact building method
3 sizes
Combinably with spur wheel, planet and flat transmissions
24V engine interpretation
0/10 V control voltage
Speed range 800 - 4500 Upm
High stable torque process
Brushless
Sturdily, maintenance-free
Enclosure IP 54 or 65
Customized adjustment naturally
LARVA IN GERMANY
|
|
Compact High Torque Brushless motors to 300 watts+, new innovative compact design giving high performance in a small footprint.
CTM1 FEATURES:
* Voltage Range: 12 or 24 VDC
* Continuous Output Power: 250 Watts
* Maximum Output Torque: 1Nm
* Speed Range: 3790 RPM
* Size Diameter: 87mm
* Size Length: 66mm
* Weight: 1.16Kg
* Enclosure Rating: up to IP54
* Insulation: Class F
* Connection: Flying Leads
* Brake Option: Yes
CTM2 FEATURES:
* Voltage Range: 12 or 24 VDC
* Continuous Output Power: 350 Watts
* Maximum Output Torque: 1.5Nm
* Speed Range: 3700 RPM
* Size Diameter: 87mm
* Size Length: 72mm
* Weight: 1.92Kg
* Enclosure Rating: up to IP54
* Insulation: Class F
* Connection: Flying Leads
* Brake Option: Yes
minimum order quantity: 100 units per annum
|
|
|
|
