Advantech provides two different types of controllers with respective I/O modules for versatile applications, PC-based Controllers and Programmable Automation Controllers (PAC). The PC-based controllers are open development environment interface; the PACs are a single platform with multi-disciplined controller functionalities.
|
|
AIO160802AY-USB is an analog I/O terminal for USB 2.0 that can be connected to the USB bus.
This product has analog input (16bit, 8ch), analog output (16bit, 2ch), digital input (LVTTL x 4), digital output (LVTTL x 4).
AIO-160802AY-USB includes "C-LOGGER", a data logging software of Windows version. "C-LOGGER" is an easy-to-use yet very flexible tool specifically designed for user's data logging applications.
Users can also use the included driver library "API-USBP(WDM)" to configure the application software for Windows using the programming languages that support Win32AP functions.
|
|
SCM5B MODULES
Dataforth Corporation offers cost-effective, isolated industrial signal conditioning modules. The SCM5B analog modules are form, fit, and functional equivalents to similar products from other manufacturers. The product line includes a complete selection of backpanel options, interface cables, racks, fuses, jumpers, power supplies, and other accessory items.
|
|
|
|
|
|
JetI/O 6510 is a Block I/O module equipped with one Ethernet port and 8 channels Analog Input connectors. JetI/O 6510 provides 16 bit resolution and high accuracy for I/O data collecting. The analog input range can support from 150mV to 10V and 20mA. The values are most adopted in the industrial environment.
The JetI/O 6510 supports advanced peer-to-peer I/O function. The logic result of IO channels from one device can be sent to more than one peer JetIO devices without additional intermediate controller and thus modify their channel status.
With the peer-to-peer I/O function JetI/O 6510 can configure with up to 8 Unicast IP addresses of the peers reducing network traffic, saving all devices’ computing power, as well as making peer-to-peer activity across a LAN segment easily.
JetI/O 6510 provides Windows Utilities, SNMP and Web for configuration. Industrial Modbus/TCP protocol and OPC Server driver for integrating JetI/O with existed HMI/SCADA. Robust aluminum case is with good heat dispersing and IP31 protection. With JetI/O users can easily perform status monitoring and control the remote I/O devices.
Major features include:
* Ethernet Block I/O with 8 Channel Analog Input from 150mV to 10V, 20mA
* 16 bits resolution and high accuracy
* High/Low Voltage/Current active alarm
* Flexible peer-to-peer I/O through one-to-one, one-to-many, many-to-one, and many-to-many communication
* Unicast for network efficiency and true remote I/O
* Free OPC server and support Modbus/TCP
* Built-in watchdog timer and real-time clock
* SNMP / Web for easy configuration and management
* Operating temperature -25~70℃
* IP31 case protection
|
|
ISOLATED SCMD DIGITAL I/O MODULES
Dataforth offers a broad line of digital input and output modules and accessories providing safe, reliable interfacing to industrial measurement and control applications. When installed near individual field loads, our SCMD series I/O modules create a rugged protective isolation barrier, effective to 4kV, between the field and computer system. Use of these modules can also reduce field wiring costs while establishing an economical, manageable approach for system expansion and repair.
|
|
The intelligent Ethernet I/O modules MSX-Exxxx are especially suited for industrial measurement, control and regulation tasks very close to the test item.
- ARM9 technology: intelligent system
- All modules can be cascaded and synchronized in the ìs range
- Degree of protection IP 65 or IP 40
- Extented temperature range: 40 °C / + 85 °C
Functions:
- Digital I/O module
- Multifunction counter modules for incremental or sin/cos signal generator
- Analog I/O module
- Module for length measurement
- Module for synchronous length measurement
Easy connection to PLC:
The intelligent modules can be connected fast and easily to PLCs without any programming skills.
|
|
|
|
|
|
With the IS1 R. STAHL present the second generation of Remote I/O Systems with intrinsically safe inputs and outputs.
IS1 is extremely simple to use: A CPU & Power Module and several input/output modules are snapped on to the BusRail (35 mm DIN rail). The unique PowerBus power supply concept, developed especially for use in hazardous areas, makes system planning as simple as for normal industrial I/O systems.
IS1 is particularly flexible: It can be used for small and large signal quantities with the possibility of installing field stations in Zone 1 / Division 1 or Zone 2 / Division 2. Installation in control rooms is also possible. An intrinsically safe fieldbus using copper-wire or fibre-optic technology connects field stations in Zone 1 with the automation devices.
IS1 is extremely economical: Modules with 8 or 16 inputs lower the price per signal. The optional ServiceBus in connection with the "I.S. Wizard" software or a HART-Management System cuts down the time for commissioning, trouble shooting and maintenance.
The new I/O modules for Zone 2 applications can be mixed with the Zone 1 modules on the same BusRail. With this it is possible to design very cost effective field stations. IS1 is now available with Industrial Ethernet / Modbus TCP interface.
Modular Remote I/O System for 35 mm DIN rail mounting:
Installation in Zone 1 / Division 1 or Zone 2 / Division 2, Zone 21 and Zone 22, safe areas
Fieldbus communication: Modbus RTU, Profibus DP V0 and P V1 HART, Industrial Ethernet
Hot swap for all modules
Redundant internal system bus
Full redundancy (many control systems) or line redundancy (all control systems)
Field enclosures in many versions
|
|
|
Our modular Remote I/O systems - RPI, LB and FB - are the cost-effective connection of your field signals in the hazardous and the safe areas to your process control system via the fieldbus. A variety of gateways are available for the connection to different fieldbusses. Free combinable I/O modules and high modularity offers cost-saving installations. The systems are characterized by high functionality and simple handling.
|
|
The ISbus fieldbus system product series includes components and systems for use on Profibus PA and FOUNDATION fieldbus H1
Installation in Zone 1, Zone 2, Zone 21, Zone 22 and Division 2
Different field device couplers to connect intrinsically safe and non-intrinsically safe fieldbus
Integration of simple, binary signals in the fieldbus via intelligent digital I/O couplers
Redundant fieldbus power supply with galvanic isolation of fieldbus segments for FOUNDATION fieldbus H1
Field housings of different sizes and materials, such as plastic, stainless steel and aluminium
System solutions for field installations and integrated solutions in combination with remote I/O
|
|
|
Advantech provides two different types of controllers with respective I/O modules for versatile applications, PC-based Controllers and Programmable Automation Controllers (PAC). The PC-based controllers are open development environment interface; the PACs are a single platform with multi-disciplined controller functionalities.
|
|
Data Acquisition modules/ Distributed IO modules for SCADA / PLC/HMI
Good features:
- Portable
- Modbus connectivity
- Simple setup and easy handling
- Upto 128 Modules on RS485 network
- Isolated modules available for special applications
- Low-cost IO modules addition to existing PLC system
- Standard software for module configuration and trouble shooting
- Data acquisition software for data storage and Real-time analysis on PC
- IO modules used with the third party softwares via Modbus RTU Protocol
- Interface with field devices to provide real-time data for SCADA/PLC/HMI
- LEDs on every module for digital IO status, communication and power supply
- Different types of IO Modules AI, AO, DI, DO, RTD, Thermocouples all available
- Direct reading of temperature without scaling by using RTD and Thermocouple Modules
|
|
|
|
|
|
PROFIBUS DP Master/Slave Module for CompactRIO™
The COMSOFT cRIO PB module connects the CompactRIO chassis directly and for the first time to PROFIBUS DP networks.
The cRIO PB module features cyclic DPV0 Master class 1 services for the fast exchange of I/O data as well as acyclic DPV1 Master class 2 services for configuration and diagnosis purposes. The module additionally supports DP Slave mode for the integration in existing PROFIBUS DP networks, e.g. in combination with a PLC.
The small sized and rugged platform CompactRIO from National Instruments is a control and acquisition system designed for applications that require high performance and reliability. Using FPGA technology (Field Programmable Gate Arrays) the implementation of hard real-time-enabled systems is also possible. cRIO is a modular system and there is a wide range of industrial I/O modules available. This results in combination with the cRIO PB module in an extremely attractive solution for the realisation of PAC systems implementing high-complex data acquisition and control functions at the same time.
A direct LabVIEW™ VI interface for a seamless integration of the module and a full graphical Windows based PROFIBUS DP configuration tool are available.
The easy-to-use VI interface provides detailed examples incl. source code for DP Master and DP Slave.
|
|
I/O modules for field applications
The ifm field modules are available in different versions for different applications. The ProcessLine for food and process automation with the protection rating IP69K, the CompactLine for robust applications and the ClassicLine for standard applications, both in IP67. Illuminated pushbutton modules complement the product range.
|
|
|
|
|
|
Really independent I/O modules with embedded microprocessor
Sigmadue is a system of standalone remote I/O modules designed by Ascon for fieldbus applications, in other words, fully distributed automation. No back planes nor common modules are necessary, also, wiring can be directly connected to the modules thus eliminating termination units. I/O modules have a lot of built-in intelligence. Embedded microprocessors allow them to scale data, linearise them, do signal conditioning, perform diagnostics and take care of alarms. These I/O modules can unburden the PLC memory. Valuable PLC memory can be dedicated only to the digital processing, thereby improving the PLC’s scan times. PLC processor can be downsized. The modules use CANbus or Modbus as bus, and are easily networked together. There are numerous CANbased or Modbus intelligent devices that can be networked together with the modules and brought into the system: PCs, PLCs, motor drives, valves, transmitters for pressures, temperatures. CANbus has the advantage in that the modules can be separated at great lengths from one another; so the I/O system can span large distances. Network adaptors will connect an entire Sigmadue system into Profibus or Ethernet. Ascon can also offer SigmaPAC, the programmable automation controller designed to be the host controller for the Sigmadue system of I/O and suitable to obtain completely open and configurable distributed automation systems.
|
|
|
|
|
|
The V450 is a VME 16-channel isolated analog-to-digital converter module which can acquire a wide range of DC voltages, including thermocouple temperatures. Each channel is independent with an isolated DC power supply, optoisolated interface, A/D converter, signal conditioning, input protection circuits, and test relay.
An internal microprocessor manages all data I/O and communicates with the VME bus via a transparent, VMEbus-speed dual-port memory.
Each channel may be user programmed to operate in voltage-input or thermocouple acquisition mode. In each mode, channel operating parameters, acquired measurements, and status flags are accessible in dedicated VME registers. Data rate/filtering options are provided. Data acquisition is managed autonomously by the processor, so VME masters may set channel parameters or read acquired measurements at any time at full VMEbus speed. Any channel can be associated with any of the reference junction sensors located in the external field-wiring termination panels, or can use the on-board sensor. Cold-junction compensation is via table lookup of thermocouple potential for the type currently selected. Reference junction temperatures are readable.
The V470 Analog Output Module is also available.
|
|
|
|
|
|
The V470 is 6UVME module that provides sixteen independent, isolated analog outputs that may be user-programmed to operate as voltage outputs or thermocouple simulators. Users may write temperature or voltage values at VMEbus speed, and the uP will transparently do all necessary calculations and update the channel electronics.
In thermocouple simulation mode, theV470's lookup tables for all common thermocouple types allow users to write desired temperature directly to VME registers. Any channel can be associated with any of the reference junction sensors located in the external field-wiring termination panels, or can use the on-board sensor. Cold-junction compensation is via table lookup of thermocouple potential for the type currently selected. Reference junction temperatures are readable.
Two front-panel D-25 connectors interface to external analog devices. Each connector provides eight differential outputs and connections for two 4-wire RTDs. A D9 connector provides in-crate calibration check. Each isolated channel incorporates a software controlled DPDT relay that allows the channel output to be diverted to the test connector.
Up to four output channels may be series-connected to provide outputs up to ±50 volts.
An optional built-in-self-test (BIST) subsystem adds additional switching and an on- board ADC and firmware that allows the invocation of a full closed-loop test of all ranges of all 16 channels.
The V450 analog input module is also available.
|
|
|
|
|
|
Analog interfaces
CANOpen protocol
Modbus protocol
ADCOM is a versatile interface which provides up to 2 analog inputs and 4 digital I/O.
ADCOM can be used in distributed automation systems based on the Modbus protocol or on the CANopen standard.
It is also possible to communicate with ADCOM by using a simple
2 wire digital interface wich make it an ideal expansion for any PLC, even the most simple.
Based on the selected model, ADCOM can directly read the temperature from NTC, PTC, PT100 or PT1000 probes and also from
J, K or S termocouples.
Alternatively, it is possible to read general sensor like 0-10V, 0-1V,
4-20mA or a load cell.
ADCOM can also be expanded with our TRH10 interface for temperature and relative humidity reading.
Compact size DIN mounting
Compatible with any commercial PLC
No need for PLC analog inputs
RS485 Serial interface with Modbus protocol
CAN interface with CANOpen protocol
Digital 2 wire interface
4 digital outputs, optocupled, for loads
up to 700mA at 24V
4 optocoupled inputs protected by ESD
2 analog inputs with 24 bit resolution available for temperature sensors, load cell, general 0:10V,
4:20 mA signals.
Compatible with TRH10 temperature and humidity sensors
|
|
Introduction
Better I/O Matrix for Monitoring
Moxa's ioLogik E2242 is tailormade for use with remote monitoring and alarm systems. This Active Ethernet I/O product provides 4 analog inputs and 12 configurable DIOs for a 1:3 ratio of analog IOs to digital IOs perfectly adapted to water tank monitoring and environmental monitoring applications, in which 1 analog input is used to trigger 3 digital outputs as High-High, High, and Low alarms. Moxa’s ioLogik E2242 lets you set up your monitoring system without the need for a local PC or RTU.
Features
• 4 fixed differential analog input channels
• 12 configurable digital input/output channels
• DI counter saved automatically when power shuts off
• Instant event messaging by TCP/UDP/email/SNMP-Trap
• PC-based configuration utility and web console
• Easy-to-use Click&Go™ Logic for local output control
• Windows/WinCE VB/VC.NET and Linux C APIs
• I/O control over Modbus/TCP and SNMP protocol
•NIST traceable calibration
|
|
|
|
|
|
SmartStix I/O is a terminal-block style I/O that connects to CsCAN, Profibus or Devicenet Networks.
DIN-rail Mounted, with Removable Terminal Strip - SmartStix I/O is extremely compact, providing 16 and 32 point digital I/O in a package only 39mm deep and a footprint of 50 x 110 mm or 50 x 177mm .
With its small footprint, SmartStix I/O takes up very little panel space whether located in the main control panel or tucked away in a remote location.
The terminal Strip is removable leaving the wiring intact for easy field servicing.
It can also be used to expand the I/O capacity of our range of Operator Intefaces and Operator Control Stations(OCS) and is very cost effective as remote digital and analogue I/O.
Because SmartStix I/O connects to any OCS CsCAN network port, it can be combined with our Modular SmartStack I/O to provide the best I/O selection for the application.
Designed to be very Cost Effective - Profibus and Devicenet Versions also comes complete with Connection Plugs. Often a forgotten and costly item.
Smartstix also connects to CsCAN versions of our powerfull Operator Interface - the TIU range. This allows you to control
the smartsix via the TIU's Script Language without the need for a PLC thus creating a even more cost effective system.
~ Cscape™: All Units are programmable with a Free Software ~
|
|
Each product is galvanically isolated up 6 ways with 1,5 KVac. The most important features are its incredible speed, 1 ms for the digital modules and 20 ms for the analog ones, and its high accuracy, around 0,01%. Easily configurable through EDS sheets that you can download from the website www.seneca.it
Suitable for the Automotive field and all the applications where is required the best speed and accuracy for a perfect control of your machine.
Seneca offer a Wide range of Canopen Modules & Control Unit:
- 16 CH digital input / 8 CH digital output CANopen
- 24 CH digital input CANopen
- 24 CH digital output CANopen
- 3 CH analog output (mA, V) CANopen module
- 4 Ch RTD (P100, Ni100, Pt500, Pt1000) input CANopen module
- 8 CH analog input (mA, V) CANopen module
- 8 CH Thermocouple (J,K,E,N,S,R,B,T) CANopen module
- 1 CH strain gauge CANopen module
- Multi-function control unit. CAN, Ethernet, RS232/RS485, ModBUS RTU integrated ports
|
|
On-Machine control is the placement of automation components directly on a machine rather than housing them in a remote, central cabinet. This is possible with the emergence of more modular, compact devices, plug-and-play connectivity, flexible communication networks, intelligent devices, and a wide array of products with improved environmental ratings. On-Machine components can include everything from programmable controllers, motor starters, drives, sensors, contactors, network media, distribution boxes, and I/O, as well as HMI devices. On-Machine solutions provide reduced wiring and system costs, improved Mean Time to Repair (MTTR), enhanced control system reliability, increased productivity, and greater flexibility.
|
|
Semaphore offers a new range of affordable Ethernet Remote Modules of compact size and monoblock construction that can be fixed easily on DIN rail.
The modules connect a wide variety of electrical, electronic, and mechanical devices and sensors -- such as pumps, temperature and pressure transmitters, motors, and more — to computers and applications over standard Ethernet networks (Modbus/TCP), RS485 (Modbus RTU), or other controllers and PLCs.
Each remote I/O module has its own Ethernet Modbus TCP/IP port making it easy to connect the modules to each other with up to 100 meters of CAT5 cable, or even longer distances using fiber optic switches.
There are several types of Ethernet remote I/O modules available with different I/O formats.
|
|
|
|
|
|
ALTO RANGE
1/ HARDWARE PRESENTATION
Sturdy aluminium case.
Compact product : Width x Height x Depth = 128 x 145 x 72 mm
IP30
Disconnectable connectors.
A descriptive label and a LED per input/ouput.
Voltage : 24Vdc; 12Vdc (some models on demand) ; 85-264Vac (some models on demand)
Electromagnetic immunity EN50081-2
Operating temperature : -20°C +70°C
MTBF : 12 years min according to UTE2000 45°C
Quick anchoring clip on DIN symmetrical rail.
Communications
* 1 Ethernet 10 base T Channel
* 1 RS232/RS485 channnel
* 1 RS232 channel
* Digital inputs with sensor wire control : 4 informations per input : Normal open, normal close, open failure, short circuit.
* Digital static output : Type P, 500mA, redundant command
* Digital relay output : 1 contact single pole normally open; Coil 24V; 3A on resistive load, 2A on inductive load
* Tension analog input : +-100mV , +-1V , +-10V
* Current analog input : +-20mA ; 4-20mA
* PT100, PT1000
* Thermo couple : B C E J K N R S T
* Analog outputs : 0-20mA or 0-10V , 12 bits
2/ SOFTWARE USES : 2 possibilities
ALTO WEBIO
Alto webIO is a smart remote input output module. It needn't workbench for start up. It a Modbus TCP slave with a embedded HTTP server.
The menu allows
* to configure the products (server adresses, email wording, passwords, ...)
* to display input states on line
* to force outputs for test
* to configure filtering of inputs, blinking of outputs
* to configure withdrawn output positions if ethernet communication failure
ALTO ISAGRAF : IEC113163 programming
With the Isagraf workbench, ALTO Isagraf becomes a microPLC
It uses the IEC61131-3 languages.
|
|
|
|
|
|
Daisy-chained Ethernet I/O Connection
A new daisy-chained Ethernet I/O paradigm is now available. The ioLogik E1200 series industrial remote Ethernet I/O has two embedded Ethernet switch ports that allow information to flow to another local Ethernet device or connect to the next ioLogik in the daisy-chain. Applications such as factory automation, security and surveillance systems, and tunnel monitoring, can make use of daisy-chained Ethernet for building multi-drop I/O networks over standard Ethernet cables. Many industrial automation users are familiar with the multi-drop configuration typically used in fieldbus applications. The daisy-chain function on the remote Ethernet I/O ioLogik E1200 not only increases the connection between machines and panels, but also lowers the cost of buying separate Ethernet switches, and at the same time reduces labor fees and cabling by a large percentage.
Features:
•Built-in 2-port Ethernet switch for daisy-chain topologies
•Free support of Moxa’s push-based Active OPC Server Lite
- Seamlessly connect to any SCADA system
- Save 80% on network bandwidth
- I/O response that’s seven times faster
•User-defined Modbus/TCP addressing
•MXIO programming library for Windows and WinCE VB/VC.NET and Linux C APIs
•Web configuration with Import/Export function
|
|
Field Bus System - Zone 1 mounting
Plug-in modules installed in field housing IP66 certified
Intelligent combination of hazardous area protection methods
Encapsulated modules for rough environment
Installation in zone 1 in polyester or stainless steel housing
Binary, analogue, RTD100, TC, voltage, frequency signals
24 Vdc, 110 Vac and 230 Vac power supplies
Modules 2 to 8 channels for binary signals (single or multichannels modules)
Modules 1 to 4 channels for analogue signals
Up to 96 analogue signals and 192 digital signals on the same remote I/O station
Interfaces for Eex d devices
Eex i et Eex e can be mixed on the same unit
No hot work permit required for maintenance
|
|
|
|
|
|
The Ascon’s deltadue offers several modules for I/Os, control and acquisition. Connectivity is guaranteed by MODBUS RTU serial comms and by gateways, line adapters, line converters, WebSCADA and Managers which allow to realize different architectures by connecting the modules to:
o A PLC or SCADA with MODBUS TCP via an Ethernet network or the web
o Any web browser for the configuration of HTML management pages and to MODBUS TCP SCADAs via an Ethernet network
o A MODBUS TCP SCADA (via an Ethernet network) and to a PLC (PROFIBUS DP or MODBUS RTU or DeviceNet) simultaneously
o CANopen, PROFIBUS DP, DeviceNet networks
o MODBUS RTU networks with different baud rate, parity and stop bits
o Two masters, such as Operator Panels, SCADA, PACs, simultaneously
The series include: universal analogical inputs (Pt100, T/C, mA, mV), digital inputs; universal control outputs (mA, relay, SSR), PID algorithm with overshoot control; heat/cool PID. The Manager provides: automatic learning and back-up of the configuration data of the modules; Hot Swapping to maximize process uptime; automatic configuration of replaced modules; the other modules work while replacing the failed module to reduce machine downtime; offline configuration to simplify start-up, when the modules are inserted, they are recognised, configured and parameters are downloaded; diagnostic, scanning of the connected modules to verify if they are the correct ones and if they work properly, actions can be taken quickly. Modules work as independent units; no backplanes or common modules are necessary. The Manager and the Gateways are needed only when their functions are necessary
|
|
|
|
|
|
Multifunctional I/O interface suitable for industrial process control,
building automation and complex domotic system
Featuring a standard Modbus protocol, the MXC700 module can be remotely controlled by any Modbus master, like operator terminals or PLC and it is compatible with the most famous HMI/SCADA software available on the market .
MXC700BIO is the easiest way to implement reliable but economical distributed systems for control and acquisition of plant data.
Also, up to 31 MXC700BIO modules can be connected on the same bus allowing to build even larger systems with more I/O as needed.
Each of the 48 digital outputs is capable of sourcing up to 0.7 Amps and all outputs are short circuit and overtemperature protected.
The inputs may be used to read dry contacts and push buttons (a debounce filter is present) or for counting applications, up to 100 pulses/second.
A dedicated input for fast counting applications
(up to 10 kHz) is also present.
The two D/A outputs and the two A/D inputs for 0-10V signals with 12 bit resolutions complete the features of this versatile I/O module.
* RS485 Serial interface with Modbus protocol
* 48 digital outputs, optocoupled,
* for loads up to 0.7A at 24Vdc
* 24 optocoupled inputs, ESD protected
* 2 analog inputs, 0-10V with 12 bit resolution
* 2 analog outputs, 0-10V with 12 bit resolution
* 1 input for encoder fast counting, up to 10 kHz
* 2 analog inputs with resolution up to 24 bit for load cells, 4 : 20 mA or 0 -10 V sensors (optional)
|
|
Modular, Scalable I/O System in IP20
This I/O system offers complete scalability, easy wiring and powerful diagnostics. Choose from the following interfaces: PROFIBUS-DP, INTERBUS, DeviceNet or SERCOS. For the sensor/actuator connection, digital and analog I/O and corresponding infeed modules are available.
|
|
High-performance distributed I/O system
Gateway for GDNET network
Gateway for main field Busses
Entirely configurable via software
Completely remote from the field
Modular
Simple for cabling
Sturdy
|
|
|
|
