DF30 Display Facia is available in four different window sizes, extra small, small, medium and large as listed below.
Any combination of these window sizes can be supplied in any format, mixed as required in a single display to make up the appropriate matrix required.
Extra Small (30x15mm)
Small (30x3Omm)
Medium (60x3Ornm)
Large (60x6Omm)
|
|
General description:
Gill Wind Speed Indicators are compatible with WindSonic and WindObserver anemometers, enabling the display of wind speed and direction using high visibility LED technology.
Gill Wind Speed Indicators are available in two display formats (standard and marine) and 110 or 240 V ac operation with RS422 or NMEA inputs.
|
|
J1805
Format DIN 96x96.
Indicator panel to 8 Multicolor LED 5x10mm high brightness.
7 choice of color display, selectable from the front by switch.
Identical in appearance to J1800 and mechanics.
- 8 multicolored LEDs "high brightness", color possible: White, Green, Yellow, Red, Blue, Magenta, Cyan.
- Button "test LEDs" in front.
- Relay "synthesis" report of distance integrated, selectable per-channel. No acknoledge.
- Voltage range of 10Vac/dc to 60Vac/dc. (Models 24Vac/dc and 48Vac/dc are grouped).
- Lighting by closing contact entry.
- Easy to create labels (PC).
- Economic and durable.
|
|
DF30 is available in four different window sizes, extra small, small, medium and large as listed below.
Any combination of these window sizes can be supplied in any format, mixed as required in a single display to make up the appropriate matrix required.
Extra Small (30x15mm)
Small (30x3Omm)
Medium (60x3Ornm)
Large (60x6Omm)
|
|
PAN3V
Format DIN 48x48
The PAN3V is a small economic panel especially studied for the starting cupboards or the electric control panels.
It makes it possible to announce :
- 3 gathered information.
- "Start, stop, default".
- "presence of the 3 three-phase tensions" of an electric departure.
Supply :
- Low voltage (12Vac/dc, 24Vac/dc, 48Vac/dc).
- Hight voltage (130Vdc, 220Vac, 380Vac).
Equipped with 3 removable indicators LED "high luminosity" (possible colors: green, yellow, red, blue, white), of its connector scewless removable, its test lamp optional outside, it is very easy to install and will save to you an precious time.
Option :
Lamp test output.
|
|
LED display
Mounting vertical
Segment height: 10 m
|
|
Series S302/SX302
Numeric and alphanumeric large size displays
Character heights 57, 100, 160, and 250 mm
Displays with brilliant red LEDs (optional blue, green, white)
Light reflecting display elements in LRD®-technology
Interfaces Profibus, Modbus, serial, parallel, analog; further interfaces on request
Single- or double-sided displays
Displays with dimension symbols
Set-up menu for setting parametersand operating modes
Equipment packages for outdoor applications
Protection type IP54 and IP65
|
|
|
|
|
|
When size matter ! Discover the economical new range of Red Lion Large Displays : the LD series, to visualize your main production datas from a distance.
LD
Large Display Counter and Rate Indicator
- 2.25" & 4" High Red LED Digits
- Available in 4 or 6 Digit Versions
- Single or Dual Counter with Rate Indicator
- Programmable Scaling and Decimal Points
- Programmable User Input
- AC or DC Powered
- 5 AMP Form C Relay
- Aluminum NEMA 4X Case Construction
LDT
Large Display Timer and Cycle Counter
- 2.25" or 4" High Red LED Digits
- 6-Digit Bi-directional Timing Capability
- 5-Digit Cycle Counting Capability
- Selectable Timer Ranges and Operating Modes
- Elapsed Timer and Preset Timer Functionality
- Serial Communications (Selectable RS232 or RS485)
- Programmable User Input
- AC or DC Powered
- 5 AMP Form C Relay Output
- Aluminum NEMA 4X Case Construction item
LDA
Large DC Volt/Current/Process Display
- 2.25" & 4" High Red LED Digits
- Programmable Scaling and Decimal Points
- Programmable User Input
- Dual 5 Amp Form C Relay
-Aluminum NEMA 4X Case Construction
-RS232/RS485 Serial Communications
- Universally Powered
LDSS
Large Serial Slave Display
- 2.25" or 4" High Red LED Digits
- Displays up to 6 Digits of Serial ASCII Data
- Dual Display Buffer Allows Alternating Displays
- Selectable RS232 or RS485 Serial Interface
- Connects Directly to Red Lion Products with Serial
- Programmable User Input
- AC or DC Powered
- Aluminum NEMA 4X/IP65 Case Construction
|
|
| ... products without technical information |
| |
APEM, a comprehensive range of professional LED indicators
- LED indicators for panel mounting
- Seven different diameters: 6, 8, 12, 14, 16, 19 and 22 mm
- Three different bezel shapes: prominent, recessed and flush
- Bezel materials plated in bright chrome, black chrome and satin chrome
- Solder lug, quick-connect, pin or wire terminals
- Standard diffused red, green, yellow, blue and white LEDs, plus bi-colour, tri-colour and flashing LEDs
- Complementary range of super bright, water clear LEDs also available (sunlight visible)
- Optional panel sealing to IP67
Integral resistors permit direct connection to 12V, 24V,110V and 230V.
APEM, the broadest offering in the switch market: miniature switches, industrial switches, LED indicators, professional switch panels and professional joysticks.
|
|
The P861 LED Lamp provides visual on/off indication of process conditions in both safe and hazardous areas. Available in a choice of six super-bright colours (red, orange, yellow, green, blue and white), they are ideally suited as part of a panel mounting indicator or illuminated pushbutton assembly.
The P861 itself is a standard BA9s intrinsically safe LED lamp which can be supplied as part of a pilot light or illuminated pushbutton or alternatively supplied separately to be used in any standard switch or lamp assembly.
With the LED lamp being current limited to take a maximum of only 20 mA, it is possible to drive two lamps from a single IIC interface without any affect on the brightness.
With the LED's low power consumption, low heat dissipation and long life expectancy, the P861 is an ideal indicator for safe and hazardous areas alike.
|
|
• Filament lamp or neon illumination
• LED illumination, dc or ac ratings (mains 125/250V dual rating)
• Red, yellow, green, clear or blue colours (as standard)
• Panel mounting holes from 5.8mm to 25mm diameter
• Front of panel sealing to IP54
• Wide choice of profiles
• Circular and rectangular formats
• RoHS compliant
|
|
|
|
|
|
VCC's CMS 322 lens is designed to provide a means of protecting equipment from both drip or splash conditions while displaying panel or circuit board mounted LEDs.
The traditional methods of moisture sealing have been the use of bulky military style indicator lights requiring o-rings, nuts and washers. While these units are effective, they do not provide aesthetics desired in today's modern equipment designs. As a result, engineers faced with the problem of moisture sealing are forced to design elaborate display panel windows with special gaskets. When limited by design funds, engineers have attempted to seal standard panel lenses or indicator lights with adhesives such as RTV. These methods are very expensive in component hardware, extremely labor intensive and lack required aesthetics.
VCC's CMS 322 low-profile lens is equipped with a moisture sealing gasket. Tests by an independent environmental testing laboratory have shown that the lens provides an effective seal against splash and drip conditions. In addition to the water tests, the lens and retaining systems were tested up to 6Gs of shock and from 0 to 2000Hz of vibration. An operating temperature test from -40°C to +85°C and a UV test were also performed. The conclusions attained upon completion of these tests were that the CMS Series lens and the retaining systems used exceeded all test criteria.
|
|
FLASHING DEVICES
The electronic lighting fixtures for electrical panels provide an efficient, easy-to –install, technologically advanced tool. The product created as a result of this project has a modern compact design and makes lamps extremely versatile, with different possibilities of positioning and rapid installation speed.
Models from 8w to 21w with 24CC/AC, 125V AC and 240V AC power supply
Installation of the flashing safety device prevents accidents, warning the operator of the presence of voltage in the electrical system by means of flashing. The DSL flashing devices are installed in highly visible positions upon opening of the electrical panel doors, and connected directly downstream to the main switch. The flashing of the three red lamps highlights hazardous conditions. The DSL devices can be connected to both three-phase and single phase lines.
|
|
EM20-FPSI 1010
- Red/Green SMART Indicator
- 0 to 30Vd.c. Range
- 2 User Prog. Thresholds
- 1 Control Output
- IP67/NEMA 4X Metal Bezel
The EM20-FPSI 1010 is a ready-to-use panel mounted SMART indicator. This compact LED module indicates green when the input voltage is between two easily programmable levels and red when the input voltage is higher or lower. The levels are easily set and stored in Flash memory. They can be changed as often as desired. This unit can be used in countless applications where a GO / NO GO indicator is required. The module incorporates one output, allowing the user to drive an external alarm or to control the process being monitored. The module uses a metal bezel providing IP67/NEMA 4X protection and screw terminal connectors for easy installation. A 20.5mm (0.81?) diameter panel cut-out is required to mount the unit. For a list of compatible sensors click here. This is a popular part, normally stocked in high quantity and suitable for new designs.
|
|
