The Electromagnetic Digital Load Cells (EM-DLC) of the AD-4212C Series are A&D’s latest weighing sensing technology for maximizing the efficiency of production line systems.
The EM-DLC is a high precision electromagnetic weighing sensor with an integrated analog-to-digital converter. It outputs digital signals directly to a panel computer, PLC, or PC via RS-232C while realizing a minimum weighing value of as small as 1 mg.
The stabilization speed is extremely fast. It takes less than 0.5 seconds for one weighing (up to 30 g + the receptacle weight). In addition, the high-speed, continuous data transmission (selectable from approx. 10 times/second up to 50 times/second) ensures real-time data processing.
The weighing sensor is highly compact. In particular, its width is only 59 mm, which makes the pitch distance between sensors short when multiple sensors are to be lined up. If necessary, the weighing sensor can be directly fixed onto the mounting base by removing its leveling feet.
Free WinCT-4212C software is provided for displaying weighing results, performing calibration, and making settings from your PC. Moreover, there is a display unit (AD-8922A) available as an option, which enables analog, comparator, and BCD outputs with its optional interfaces.
Finally, the weighing sensor is IP65 dust and waterproof. It has also a shock absorber under the weighing pan and can cope with movement in all directions, protecting the weighing unit from an actuator malfunction.
There are currently two models in the AD-4212C Series, the AD-4212C-300 (320 g × 1 mg) and the AD-4212C-3000 (3200 g × 10 mg).
Please see the AD-4212C catalog for detailed specifications.
|
|
The OIML certified beam load cells SD are used for general weighing in tough environments, in bench- and platform scales, belt scales and in production equipment.
* Accuracy classes C1, C2, C3, C6 (MI10) to OIML R60
* High overload and sideload capacity 250 to 1.000 %
* Uncomplicated mechanical installation without protecting devices
* Patented high reliability sensor - stainless steel, laser welded to IP68
* Uncomplicated electrical installation - coax cable only
* RS485, Profibus DP, DeviceNet, Modbus to PLC's, PC's, etc. and OIML certified weighing displays
* Withstands welding voltages and ESD to IEC 1000-4-4
* ATEX approved version available (type SDE)
|
|
|
|
|
|
-Robust technology and design
-High tolerance of up to 1.000 % overload
-Plug-and-play installation
-High accuracy, High resolution
-Hermetically sealed to IP68
-Interfaces: RS485, Profibus DP, DeviceNet, 4-20 mA, 0-10 V
-Digital filters
-ATEX certified
-3 years warranty
-Patented worldwide
The shockproof digital load cell is based on a capacitive measurement principle where a non-contacting ceramic sensor is mounted inside the load cell body. As the load cell contains no moving parts and the sensor is not in contact with the load cell body, the load cell tolerates shocks, torsion, and very high overloads and sideloads. Therefore, the mechanical installation of the load cell can be done without expensive and complicated mounting kits and overload protection devices.
The electrical installation of the digital load cell is pure plug-and-play as the signal from the non-contacting sensor is directly converted, compensated and calibrated by a microprocessor to a digital load cell output in grams, kilograms, or Newton. Measurements and status codes are transmitted as RS485 data on a single wire coaxial cable (RG-58) which may be up to 100 meters long.
The technology and mechanical design of the Eilersen load cells is covered worldwide by a number of patents.
|
|
|
|
|
|
-Robust technology and design
-High tolerance of up to 1.000 % overload
-Plug-and-play installation
-High accuracy, High resolution
-Hermetically sealed to IP68
-Interfaces: RS485, Profibus DP, DeviceNet, 4-20 mA, 0-10 V
-Digital filters
-ATEX certified
-3 years warranty
-Patented worldwide
The shockproof digital load cell is based on a capacitive measurement principle where a non-contacting ceramic sensor is mounted inside the load cell body. As the load cell contains no moving parts and the sensor is not in contact with the load cell body, the load cell tolerates shocks, torsion, and very high overloads and sideloads. Therefore, the mechanical installation of the load cell can be done without expensive and complicated mounting kits and overload protection devices.
The electrical installation of the digital load cell is pure plug-and-play as the signal from the non-contacting sensor is directly converted, compensated and calibrated by a microprocessor to a digital load cell output in grams, kilograms, or Newton. Measurements and status codes are transmitted as RS485 data on a single wire coaxial cable (RG-58) which may be up to 100 meters long.
The technology and mechanical design of the Eilersen load cells is covered worldwide by a number of patents.
|
|
T95 LA (2 t - 20 t)
The T95 LA consists of both stainless steel and alloy steel load cells complete with toughened auto-phoretic finish loading assembly. Although the assembly is used in compression, the cell is mounted in a pendulum and operates in tension. This ensures that the load point is always maintained through the central axis of the cell, even when the assembly is subjected to considerable movement or misalignment.
The T95 LA load cell is most suitable for high accuracy applications and where movement or vibration are present, e.g. mixers, catalyst vessels, weighing platforms, axle weighers and weighbridges. The T95 LA load cell is hermetically sealed to IP68 and approved to OIML 3000 C3, optionally to EEx iA II CT6.
|
|
|
|
|
|
-Robust technology and design
-High tolerance of up to 1.000 % overload
-Plug-and-play installation
-High accuracy, High resolution
-Hermetically sealed to IP68
-Interfaces: RS485, Profibus DP, DeviceNet, 4-20 mA, 0-10 V
-Digital filters
-ATEX certified
-3 years warranty
-Patented worldwide
The shockproof digital load cell is based on a capacitive measurement principle where a non-contacting ceramic sensor is mounted inside the load cell body. As the load cell contains no moving parts and the sensor is not in contact with the load cell body, the load cell tolerates shocks, torsion, and very high overloads and sideloads. Therefore, the mechanical installation of the load cell can be done without expensive and complicated mounting kits and overload protection devices.
The electrical installation of the digital load cell is pure plug-and-play as the signal from the non-contacting sensor is directly converted, compensated and calibrated by a microprocessor to a digital load cell output in grams, kilograms, or Newton. Measurements and status codes are transmitted as RS485 data on a single wire coaxial cable (RG-58) which may be up to 100 meters long.
The technology and mechanical design of the Eilersen load cells is covered worldwide by a number of patents.
|
|
|
|
|
|
FUTEK, a leading manufacturer producing a huge selection of Load Cells, utilizes one of the most advanced technologies in the Sensor Industry: Metal foil strain gauge technology.
FUTEK's strain gauge based load cells are widely known in many industries to contain:
-The Highest accuracy which may conform to many standards from the Automotive to Aerospace.
-Robust Construction made of either high strength Stainless steel or Aluminum.
-A guarantee to perform at longest possible work life even at the most rigorous conditions
-A plethora of mounting options for ANY scale ANY-where.
-Competitive pricing that separates Futek Advanced Sensor Technology from the rest.
-A full gamut of selections with capacities ranging from 10 grams to 1 MILLION pounds.
FUTEK's industry listing is as broad as its Sensor selection. Our selection of load cells can be categorized by the following styles:
-AUTOMOTIVE RELATED (i.e. auto test measure devices: pedal, shifting, multi axial)
-BENDING BEAM
-COLUMN/CANISTER
-DONUT
-FOLD BACK BEAM
-FORCE SENSOR
-LOAD/FORCE WASHER
-LOAD BUTTON
-MEDICAL RELATED
-OVERLOAD PROTECTION
-PANCAKE
-S BEAM/ Z BEAM
-THREAD FEMALE MOUNT
-THREAD MALE MOUNT
-THRU HOLE
-CLEVIS PINS
|
|
The Load-Force-Weight Sensor family is a complement to Magtrol's range of load measuring pins. These sensors can be used in different applications where the load measuring pin cannot be mounted. Our various executions and precision classes provide you with great flexibility for your application.
Used with our load monitoring unit or signal conditioners, Magtrol Load-Force-Weight Sensors constitute an ideal load and weighing measurement system which continuously checks for defined loads and overloads.
|
|
|
Sartorius offers bending beam, compression and shear beam load cells as well as tension load cells, among others, for a wide variety of applications.
|
|
|
The LSB200 is now offered with FUTEK’s “No Risk Lifetime Warranty” due to its dynamic functionalities and miniature size. This Miniature S-Beam Jr. Load Cell is one of the signature products in the FUTEK Load Cell Series. This model may be used in Medical Bag Weighing Applications as well as automated feed back control and inline processing applications. The perfect mixture of size, accuracy and the assurance of an overload protection feature make this one of our most sought after models. With a height of only 0.75”, the LSB200 Miniature S Beam Load Cell is a great selection where tight environments or space is a challenge. The Standard LSB200 Miniature S-Beam Load Cell model has female threads, comes in 2024 Aluminum construction (100 gram - 10 lb) or 17-4 Stainless Steel (25 lbs – 100lbs), and a 5 ft 29 AWG 4 conductor shielded silicone cable. It is also available in metric threads.
|
|
DS Europe produces load cells with built-in analog and digital electronics.
Measuring ranges:from 0 to 6Kg up to 500tons max.
Outputs: CANOpen, RS485, RS422, 5V, 10V, 4-20mA, 2mV/V.
Advantages: high resolution (A/D converter 24bit max.), high sampling rate (from 7,5 upt to 960Hz max.), electrical noise protection, compactness, digital alarms, digital filter, zeroing, easy to service (overload memory).
Applications: automation, textile machines, medical machines, machine tools, presses, vehicles, weighing, food machines, quary machines, agricolture machines, research, machines working paper-wood-plastics-rubber etc.
|
|
|
|
|
|
-Robust technology and design
-High tolerance of up to 1.000 % overload
-Plug-and-play installation
-High accuracy, High resolution
-Hermetically sealed to IP68
-Interfaces: RS485, Profibus DP, DeviceNet, 4-20 mA, 0-10 V
-Digital filters
-ATEX certified
-3 years warranty
-Patented worldwide
The shockproof digital load cell is based on a capacitive measurement principle where a non-contacting ceramic sensor is mounted inside the load cell body. As the load cell contains no moving parts and the sensor is not in contact with the load cell body, the load cell tolerates shocks, torsion, and very high overloads and sideloads. Therefore, the mechanical installation of the load cell can be done without expensive and complicated mounting kits and overload protection devices.
The electrical installation of the digital load cell is pure plug-and-play as the signal from the non-contacting sensor is directly converted, compensated and calibrated by a microprocessor to a digital load cell output in grams, kilograms, or Newton. Measurements and status codes are transmitted as RS485 data on a single wire coaxial cable (RG-58) which may be up to 100 meters long.
The technology and mechanical design of the Eilersen load cells is covered worldwide by a number of patents.
|
|
DS Europe manufactures load cells with built-in CE marked electronics with analog or digital outputs.
All load cells with non amplified output 2mV/V have a built in calibration circuitry that electrically simulates a known value of force shown in a certificate ( making It easy and quick to calibrate with the external electronics getting the signal ).
Series 500QD single point load cells Ranges (tension and compression): from 0 up to ±2 ... 2000Kg FS.
Built-in electronics (option): analog or digital outputs.
Environmental protection: IP65.
Compensated against off-center forces.
Series AP7000 compact column load cells Series AP7000 tension and compression load cell.
Ranges: from 0 up to 250-500Kg 1-3-5-10-25-50-100 tons.
Built-in electronics (option): analog or digital outputs.
Environmental protection: IP65.
|
|
DS Europe produces general purpose miniaturised load cells.
Measuring ranges: 0 to 3 up to 2000Kg.
Output: 2mV/V.
Applications: automation, medical machines ( dialisis, radiology, blood transfusion machines, dentist tools, hospital beds, stabilometry platforms etc.), textile machines, machines working paper-rubber-plastics, weighing, machine tools and wherever is required compactness.
|
|
FUTEK’s Bending Beam Load Cell category offer slim designs with an excellent endurance making them ideal for OEM applications. One clear advantage is the models miniature size. Overload Protection is also available on select models.
The standard Bending Beam Load Cell can be modified or customized to meet your requirements and most models are available in our inventory making it available for quick delivery. Similar to our entire Load Cell product line this model is manufactured in US and uses metal foil strain gauge technology.
Ideal for OEM Applications
In both Tension & Compression
Single Point Construction
Low Capacity
Built in Overload Protection (select models)
Strain Gauge Based
|
|
|
|
|
|
BT Series Load Cell
The BT serie bending beam is designed for tension or compression loading applications including bench scales,conveyor weighing and vertical filling machines.The stainless steel bellow contruction makes the complete system impervious to hostile environments and washdown applications.
RT Series Load Cell
This high capacity single point loadcell is designed for direct mounting of large weigh platforms.it is suitable for a wide range of applications,including bench scales,check weighing,counting scales and process weighing.A humidty resistant protective coating assures long-term stability.the rt serie is constructed in special aluminium and sealed to IP 66.
PL Series Load Cell
PL is designed for direct mounting of midsize weigh platforms.It is suitable for a wide range of applications,including bench scals check weighing ,counting scales and process weighing.A humidty resistant protective coating assures long-term stability.the PL serie is constructed in special aluminium and sealed to IP 66.
PS Series Load Cell
Altough the PS-4X is designed for low cost weighing platforms ,it finds application invertical filling machines as well.Its small size special aluminium construction and Ip66 sealing makes PS serie suited for bench and counting scales.
|
|
Load Cells manufactured in US by FUTEK Advanced Sensor Technology (FUTEK), a leading manufacturer producing a huge selection of Load Cells, utilizing one of the most advanced technologies in the Sensor Industry: Metal foil strain gauge technology.
A Load Cell is defined as a transducer that converts an input mechanical force into an electrical output signal. Load Cells are also commonly known as Load Transducers or Load Sensors.
|
|
The LCMGD Series miniature low profile load cells are compression load cells with excellent long term stability. An all stainless steel construction assures reliability in severe industrial environments. These units are designed to operate by mounting on a flat surface, and they have a load button machined as an integral part of the basic load cell.
- 5-Point Calibration Certificate Included
- High Accuracy
- Low Profile
- Miniature Size
- All Stainless Steel Construction
|
|
The Sherborne Sensors UNIWEIGH series load cell has been specifically developed for use electronic scales where the load may be placed at any random position on a loading platform.
Typical applications are in retail shop scales, industrial counting scales, pre-packing scales, batch weighing machines, money checkers, pharmaceuticals, medical and scientific instrumentation. Compression loads from the loading platform are applied directly enabling much simpler constructions without the requirement for levers, flexures or pivots; scale design and maintenance is therefore greatly simplified. The UNIWEIGH series load cell is particularly immune to eccentric loading, the load being commonly applied via a simple X or H frame whose loading points are at the corners of the load platform. The UNIWEIGH series load cells are available in two distinct sensitivities offering the customer considerably lower ranges of this device than were previously possible.
|
|
Application
A high price/performance ratio and robust design characterize the compression load cells even in the high measuring ranges.
Their small dimensions allow these load cells to be used for measuring static and dynamic compressive forces in restricted spaces. These load cells can be integrated easily thanks to their standardized output and threaded holes on bottom.
The model 8526 load cell has a sealed body, allowing it to be used even under dirty and harsh industrial conditions.
These sensors are used as measuring elements mainly in- device manufacture
- production lines
- measurement and control systems
- manufacture of fixtures and special machines
- geological applications.
|
|
Digital load cells on the basis of the strain gage technology provide new impetus for the areas of dynamic weighing, sorting, filling, and dosing. In addition to all relevant functions for standard weighing processes, the intelligent load cells also provide control functions for sorting, filling, and dosing processes. Using a RS 232 or RS 485 4-wire interface, all relevant data can be accepted as a filtered, scaled, and digitized output signal directly into the control system used. And that at a fast measuring rate of up to 600 measurements per second.
|
|
- Weighing range up to max. 2,000 g
- Additive dead load up to max. 2,000 g
- Protection class IP 54
- Housing material aluminium nickel-plated
- Several interfaces available
|
|
- Weighing range up to max. 120 kg
- Additive dead load up to max. 150 kg
- Protection class IP 65
- Housing material stainless steel
- Several interfaces availalbe
|
|
|
|
|
|
-Robust technology and design
-High tolerance of up to 1.000 % overload
-Plug-and-play installation
-High accuracy, High resolution
-Hermetically sealed to IP68
-Interfaces: RS485, Profibus DP, DeviceNet, 4-20 mA, 0-10 V
-Digital filters
-ATEX certified
-3 years warranty
-Patented worldwide
The shockproof digital load cell is based on a capacitive measurement principle where a non-contacting ceramic sensor is mounted inside the load cell body. As the load cell contains no moving parts and the sensor is not in contact with the load cell body, the load cell tolerates shocks, torsion, and very high overloads and sideloads. Therefore, the mechanical installation of the load cell can be done without expensive and complicated mounting kits and overload protection devices.
The electrical installation of the digital load cell is pure plug-and-play as the signal from the non-contacting sensor is directly converted, compensated and calibrated by a microprocessor to a digital load cell output in grams, kilograms, or Newton. Measurements and status codes are transmitted as RS485 data on a single wire coaxial cable (RG-58) which may be up to 100 meters long.
The technology and mechanical design of the Eilersen load cells is covered worldwide by a number of patents.
|
|
High Capacity Load Cell
HT series have more advantages in comparison to column and S type load cells in industral weighing applications like low profile structure and off center loading effects for silo, tank weighing 2.000-50.000 ton capacity.
|
|
Model LLB130 is a Miniature Load Button designed for Press, or Inline compression applications. The LLB130 Miniature Load Button model is made from a robust 17-4 PH Stainless Steel, with a subminiature 0.38 inch outside diameter.
Although Miniature Load Button are traditionally not known for their high accuracy, FUTEK engineers have dispelled this concept by continuously improving the accuracy of this product. These load cells achieve great accuracy and stiffness with a Nonlinearity of ±0.5% and Deflection of 0.002” nominal. You will also find options for external matched output readily available.
The standard LLB130 Miniature Load Button can be modified or customized to meet your requirements and most capacities are in our inventory, making them available for quick delivery. Similar to our entire Load Cell product line this model is manufactured in USA and uses metal foil strain gauge technology.
|
|
Load cells work like calibrated springs.
A force is applied and there is a flexion: there is a Wheatstone bridge with strain gauges that measure this mechanical flexion thence giving a proportional electrical signal.
DS Europe can also manufacture load cells with built-in CE marked electronics with analog or digital outputs.
All load cells with non amplified output 2mV/V have a built in calibration circuitry that electrically simulates a known value of force shown in a certificate ( making It easy and quick to calibrate with the external electronics getting the signal ).
|
|
CM Load cell for compression applications
Range of measurement: from 100 to 50,000 Kg
Accuracy class: 0.1%
All stainless steel construction
Corrosion resistant
Internally generated calibration signal
Grade of protection: IP67 (DIN 40050)
TH Force transducer for tension/compression applications
Range of measurement: from 10 to 100 kN
Accuracy class: 0.1%
All stainless steel construction
Corrosion resistant
Internally generated calibration signal
Grade of protection: IP65 (DIN 40050)
|
|
|
|
|
|
HBM offers a comprehensive range of load cells and force transducers for weighing and force measurement applications, including customized solutions. All sensors are designed to work perfectly with our innovative measuring amplifier systems and our intuitive operating and
analysis software.
Load Cells
HBM weighing technology components can be found in almost all industries where goods are produced, processed or checked:
In the industrial production and scale equipment
In the manufacture of building materials
In the production of food and consumer goods
In the manufacture pharmaceutical products
In medical engineering.
Official PTB-approved certificates (the PTB is the national institute of natural and engineering sciences, and the highest technical authority for metrology and physical safety engineering in Germany) are available for a large number of load cells. Appropriate certificates are also available for worldwide use.
All standard load cells are available in accordance with European directive 94/9/EC (ATEX95).
Force Transducers
HBM force transducers are used today in every sector of industry and for R&D activities:
In the field of stress analysis
In manufacturing automation
In materials testing
In calibration.
|
|
Honeywell manufactures tension and compression load cells to cover a full range of applications. Rugged and fully welded, these stainless steel units provide accuracy up to 0.02% over ranges from 25 grams to 3 million pounds. Available unamplified, amplified or with digital output. Custom engineering and design solutions available.
Contact us for a copy of our Sensors for Test and Measurement catalog.
|
|
|
|
