Joystick transmitter Mercury 500
Mercury 500 takes on very highly sophisticated equipment. It’s primarily used for larger industrial applications and for very complicated cranes. The Mercury 500 comes with three joysticks (standard) that can control up to six movements; four joysticks are possible, and they can control up to eight movements. The Mercury 500 can be ordered with various background-lit displays for showing information from, e.g., scales, position indicators, and PLCs that are mounted on cranes.
Joystick transmitter Mercury 300
The Mercury 300 is our mid-size model that works with everything from off-the-shelf solutions to advanced equipment. It’s primarily used for larger industrial applications and for the most sophisticated cranes. The Mercury 300 has two joysticks that can control up to four maneuvers. It can be ordered with various background-lit displays for showing information from, e.g., scales, position indicators, and PLCs that are mounted on cranes.
Åkerströms’ Remotus Mercury line contains customized products for remote control of cranes and overhead cranes and for other machine control, for example, in manufacturing, steel works, mines, and the processing industry. These products have a modular design and are easily adapted to your operation’s specific requirements. Functions, frequencies, design, and layout are easily tailor made.
|
|
The Sesam 800 has various usage areas like remote control of doors, gates, barriers, fans, floodlights, and more. The system
can also be used for winches and other non-safety relevant automotive applications. It is robust, flexible, straightforward, and uses modern digital technology.
Sesam 800
• Flexible, simple and robust
• Several transmitters and receivers
• Utilizes the 869 MHz (or 926.5) frequency band
• Feedback function indicates active relay
• Based on 16,7 million unique codes
• Protection class IP65
• Checksums ensure error-free message transmission
• Encrypted authentication for extra high security
• Receiver with LCD character display and detachable memory card as an option
• Big range of carrying devices
|
|
|
The Tiger joystick transmitter for remote controlling of cranes and other hoisting equipment has duplex, CANopen and Modbus abilities. Together with your application it can communicate with an external unit, e.g. a weight sensor. It has 2 joysticks with 2 speeds or 2 joysticks with 4 speeds.The transmitters stop function is approved according to SIL3 IEC 61508 and it transmits on 433-434 MHz with 69 available channels. Tiger is certified in accordance with CSA .
|
|
Remotus Mercury 100 is built to handle everything from standard solutions to highly sophisticated machines. It’s primarily used for larger industrial applications and for the most complicated cranes. The Mercury 100 has two joysticks that can control up to four movements. It can also be ordered with indicators for information from the crane. Enormous effort went into making the user-friendly Mercury 100 operate smoothly.
Åkerströms’ Remotus Mercury line contains customized products for remote control of cranes and overhead cranes and for other machine control, for example, in manufacturing, steel works, mines, and the processing industry. These products have a modular design and are easily adapted to your operation’s specific requirements. Functions, frequencies, design, and layout are easily tailor made.
|
|
|
|
|
|
Remotus T-Rx is Åkerströms Björbo’s mobile platform for radio remote control of mobile applications. The Remotus T-Rx receiver line is modular and flexible—so it can be customized for your specific needs. The line consist of three different receiver models and one transmitter model.
The Remotus T-Rx receivers are designed to control all mobile applications with up to 8 analogue functions, PWM (0-2 A) or analogue outputs (0-10V or 0-20 mA). The system can also be used to equip wheel loaders, excavators, mobile cranes etc. with radio remote control. The system is adapted for tolerating tough conditions such as drastic temperature differences, dust, vibrations, oil, and dampness.
Remotus T-Rx 100, is a CANopen based receiver for control via existing PLCs. It is designed to control all mobile applications with up to 8 analogue functions.
The Remotus T-Rx 1000 receiver is designed to control all mobile applications with up to 24 on/off functions.
Remotus T-Rx 1500 is a complete receiver designed to control all mobile applications with up to 8 analogue functions, PWM (0-2 A) or analogue outputs (0-10V or 0-20 mA).
|
|
|
With system T60-Cougar you have many choices. The transmitters are available in versions with 1 to 15 functions. They can be read in to the receiver in two different ways, depending on how many persons that should be able to control the application. T60-Cougar transmits on 433.92 or 869.85 MHz, wideband radio. The receivers are available with 3, 4 or 8 relay outputs.
|
|
|
With system T70-Jaguar there is always an available channel you can transmit from, even if there are other radio remote controls nearby. The system transmits on 433 - 434 MHz, a total of 64 channels and narrow-band radio. The transmitters are available with 2, 3 or 6 functions and the receiver with 3 relay outputs.
|
|
|
System T20 for controlling of door, port and gate applications. The system includes more than 16 million set codes, and each transmitter has its own specific, individual code. System T20 transmits on 433,92 MHz or 869,85 MHz, and despite its small size it is extremely secure.
|
|
Sesam is an industrially-adapted door opening system that can open from one to 999 doors. Sesam is also used in situations such as opening and closing boom gates, switching on and off of fans, floodlights etc. The simple, flexible system is based on modern digital technology.
Transmitters for various needs
Several transmitter models are available, from the simplest with only one function to the most sophisticated, which can control up to 999 doors or other equipment. The most sophisticated transmitters can also be access coded, i.e., only uniquely paired transmitters and receivers work together. They’re also ready for vehicle mounting in their cassettes.
The transmitter is placed in a special holder and draws voltage from the vehicle. When mounted in the cassette, the buttons on these models are illuminated.
Easily placed receivers
The receivers are available in wall-mounted models with one or three relays or plug-in models for mounting on holders in control panels.
|
|
|
|
|
|
Remotus Jupiter is Åkerströms’ standardized remote-control product line. These rugged, reliable products are developed for most of today’s cranes and overhead cranes and for other types of machine control. They’re used, for example, in manufacturing, steel works, mines, and metal and processing industries.
The Jupiter line offers various transmitters and receivers to choose from—depending on usage area. One is a simpler version, which handles three movements at two speeds and contains an extra function. The other, a more sophisticated version, which handles three movements at two speeds, and contains three extra functions. You can order joystick and pushbutton transmitters for both versions.
The Remotus Jupiter product line is built to tolerate tough industrial environments. Environments that are often plagued by drastic temperature differences, dust, vibrations, oil, and humidity. Design and material selection set the stage for making these new Åkerströms’ products more rugged than ever before. Enormous emphasis was put on ergonomically designed transmitters—to facilitate ease of use.
Jupiter enables top security during radiomessage transmissions and runs a cyclic redundancy check on all 16 bits.
The receiver has double microprocessors that monitor each other.
A message is checked before the relay function goes out into the receiver. Command errors don’t occur and security increases. Diagnostic testing is done during operation. The system uses the general frequency band at 433 MHz. Several functions enable operators to automatically connect transmitters and receivers on an available frequency and to share the same frequency band.
|
|
|
|
|
|
The Sesam 6000 series can be used for warehouse storage systems and other applications where display values are transferred from one or several transmitters. The Sesam 6000 consist of one transmitter and two receivers and is based on technology from our Remotus family.
Sesam 6099 transmitter
The transmitter has four main functions (optional 6) and a three-digit, lighted LCD display. The transmitter can be mounted in an optional vehicle cassette which provides external power to the transmitter and illuminates the keypad. The transmitter also has a keypad lock and low battery warning.
Sesam 6000 receiver
The receiver has 13 relay outputs and several user selectable application programs. The display data from the transmitter is outputted on the relays either in BCD or binary form. The receiver has dual processors providing increased safety. All received data is double checked before relays are activated.
Sesam 6000c receiver
The receiver Sesam 6000c is a compact rugged unit for 12-24 V DC. It has one serial port (RS-232) for connection to an external PLC/PC and four short circuit protected solid state relay outputs for less complex applications. The serial port makes is possible to connect the unit to a host system where information from the transmitter can be processed further, such as display value, serial number and function value.
The receiver has an event log and a ban list of lost transmitters.
|
|
RF SETs - basic:RF SETs - basic
Basic sets are design to satisfy most common requests of users. Receivers are equipped by most frequently used function.
According to a chosen type sets contain:
CONTROLLERS:
RFWB-40 | Wall button
RFK-40 | Remote controller (key-chain)
Single-function RECEIVERS:
RFSA-11B | Switching actuator, function: ON/OFF
RFDA-11B | Dimming actuator, program: light scene, OFF
|
|
|
|
|
|
Pushbutton transmitter Mercury 8/10
The Mercury pushbutton transmitter line is developed for indoor and outdoor use. Protective rubber bumpers make them extra shock resistant. Their IP 65 classification guarantees that water and dust can’t get in. The transmitter has 8/10 large, clearly visible, rugged buttons. The buttons are shaped for easy maneuverability when operators wear gloves. LEDs on each button indicate selected function. A separate LED indicates storage battery status and operation. The Mercury 8/10 has 8/10, two-stage buttons that enable double functions for each pushbutton.
Pushbutton Mercury 9RS
A robust transmitter with the same features as Mercury 10. The main difference is that Mercury 9RS has 9, two-stage buttons and a rotary switch that you can program for up to 18 functions/ command in 4 positions.
Pushbutton Mercury 12
Mercury 12 has more buttons and of an other design than the other Mercury pushbutton transmitters. The Mercury 12 is developed for applications, such as those on vehicles, which require another fast-stop function and several direct functions. The Mercury 12 has 12, two-stage buttons that enable double function for each button.
Åkerströms’ Remotus Mercury line contains customized products for remote control of cranes and overhead cranes and for other machine control, for example, in manufacturing, steel works, mines, and the processing industry. These products have a modular design and are easily adapted to your operation’s specific requirements. Functions, frequencies, design, and layout are easily tailor made.
|
|
Lynx - radio remote control with duplex control
Lynx is a radio remote control system with duplex functions. The system is developed for users who require feedback from their application or equipment, e.g. from a machine application or a sensor of some kind. Both the system's hand controlled and stationary unit use duplex, a so-called two-way communication. It operates on the 2.4 GHz band with a total of 16 optional channels, and it is accepted all over the world. Lynx communicates via serial communication (RS232, RS485, modbus) with your PC or PLC. A certain software development is required to ensure the communication between your PC or PLC to work.
|
|
|
With the T80-Leopard system you radio control electric hoists. The transmitter has 10 x 2 functions and can control 2 receivers. The receiver has 6 functional relays and 2 safety relays.
|
|
|
With the 860-Lion system you can radio control cranes, overhead cranes, electric hoists, lift tables, etc. The transmitter is available in 3 different versions with 4 x 2 + 2 x 1, 20 (10 x 2) and 24 (12 x 2) functions. Depending on your needs and what your application requires, you can get the receiver with 10, 15 or 24 functional relays.
|
|
Tiger is a system with duplex for radio remote controlling of cranes and other hoisting applications. Tiger has duplex, CANopen and Modbus abilities. Together with your application it can communicate with an external unit, e.g. a weight sensor. Both the system's stop function and two relays in the receivers are approved in accordance with SIL3 IEC 61508. The Tiger transmits on 433-434 MHz with 69 channels available for selection within the frequencies. Its software can be modified. Tiger is certified in accordance with CSA .
The handheld transmitters are available with 10x2 functions and a display, or 12x2 without a display. The receivers are available with 12 (with or without CANopen) or 28 function relays.
|
|
Locomote is a special product line designed to meet specific safety needs for
remote control of locomotives. It’s based on Remotus and has the same
rugged design and high reliability.
Locomote 100
Switching-yard personnel can operate driverless locomotives with Locomote 100, Åkerströms’ product for remote control for locomotives.
They can easily control the locomotive with a joystick on the Locomote transmitter, which is positioned on the front of their bodies in a comfortable carrier. Using Locomote, they start, run, and stop the locomotive and thus have total control of the train’s movements.
Locomote 100 is approved according to the European standard EN 50239.
|
|
Remotus MB-28 is a totally new, unique transmitter with eight two-stage pushbuttons and two joysticks incorporated into the same model. The transmitter is easy to maneuver with one hand—making it better for certain situations in which functionality of a joystick transmitter would otherwise be needed.
Remotus MB-28 is designed for remote control of various mobile applications such as load changers, salvagers, concrete pumps, and more.
Remotus MB-28
• Hand transmitter with buttons and joysticks in one model
• Well-conceived, ergonomic design
• Can control 4 analog and 8 digital functions in 2 steps
• Opportunity to extend the functions with a selection button
• IP65 classed
• Easy to configure and functional
• Portable configuration via CIM-card
|
|
The Light series pushbutton handsets are distinguished by their low weight (420g including battery) and their small dimensions (185x80x43mm.). Much emphasis has been placed on the operator comfort in high-usage applications - the transmitter's weight distribution, key and clip systems are all ergonomically designed. The system uses light weight Ni-Mh rechargeable batteries, which power the transmitter for up to 12 continuous hours and recharge in 4 hours in an intelligent charger. Each system is supplied complete with 2 batteries and a charger. The system is fail-safe to Category 3 of EN 954-1 for Stop.
|
|
|
a portable TRANSMITTING UNIT which communicates to the receiving unit, the sequence of digital data that is necessary for carrying out the command selected by the operator using the command devices (pushbuttons, selectors, joysticks).
|
|
|
|
|
|
PRO-M
The PRO-M is a fully-proportional controller optimized for use on mobile machines. The receiver is extremely compact to fit into the limited space available on vehicles. The wide-range power supply suits either 12V or 24V vehicles, and copes easily with the harsh electrical conditions encountered. The transmitter may be fitted with up to 3 dual-axis joysticks, or 6 single-axis paddles as well as up to 12 discrete commands. The proportional outputs may directly drive either voltage or current-controlled valves, and are programmed from the transmitter using a sophisticated teach-in mechanism that can be disabled to prevent tampering.
PRO-M + KSI
The PRO-M controller may be retrofitted to machines without electro-valves with the use of the KSI control kit. The kit comprises a small self-contained hydraulic system comprising a pump, tank, filter, and proportional actuators. These small actuators connect to the control shafts of the main machine valves, and allow fully-proportional control without the cost and complexity of upgrading the main hydraulic controls.
|
|
|
The MJ joystick controller allows the operator freedom not possible with pendant cables or fixed control panels. Versions are available with 14 to 20 channels (not including START and STOP). The transmitter may be fitted with 2 or 3 Joysticks plus toggle switches, or toggle switches only. A Data Feedback option is also available.
|
|
|
a portable TRANSMITTING UNIT which communicates to the receiving unit, the sequence of digital data that is necessary for carrying out the command selected by the operator using the command devices (pushbuttons, selectors, joysticks).
|
|
MD multi-step joystick system
The MD controller is highly-configurable, and available with either multi-speed or single-speed joysticks. The multi-speed version allows up to 3 joysticks, each with up to 5 speeds on each axis. When partnered with the 18, 24, or 31-command receiver, the MD is a versatile controller for overhead cranes, tower cranes, or many other applications.
MD single-step joystick system
The MD-P is a variant of the MD controller fitted with up to 3 single-speed joysticks. The ideal partner for concrete pumps with ON/OFF control, the MD-P may also be fitted with a dedicated proportional output for controlling the pump speed. The MD-P offers all the convenience and electrical-isolation advantages of remote control together with a superior safety level.
|
|
1 to 4 keys 1-way and 2-ways radio remote control
* Wireless control for 1 to 10 logical status up to 400m
* 1-way and 2 ways versions
* 433.92 or 868MHz
* Specific marking on demand
* Comply with the European standard RTTE EN 300-220 / EN 301-489
Receivers
* RS232 or USB serial decoder, 4 relays or 4 binary outputs receivers
* 433.92 or 868MHz
* Comply with the European standard RTTE EN 300-220 / EN 301-489
* Available in IP65 box ready for use for some referencesConsumer market,
tertiary and industrial applications
Home remote controls (gate, vehicle, roller shutters…)
Home automation
Access control
Security – alarm
Remote control
Automatics, robotics…
DemoKit - Integration kit including : demoboard, module, remote control, RS232 cable, power supply available for this product
* Evaluate the products
* Perform RF measurements
* Develop a prototype
|
|
|
a portable TRANSMITTING UNIT which communicates to the receiving unit, the sequence of digital data that is necessary for carrying out the command selected by the operator using the command devices (pushbuttons, selectors, joysticks).
|
|
ALPI is the new industrial radio control unit built and developed by ELCA srl, using a new technology, 2/4/6/8 channels plus Start and Stop, made to adapt to the forestry and mobile applications.
The system consists of transmitter, receiver and battery charger and also includes the Listen Before Transmit feature allowing the ALPI to automatically scan, find and lock onto a clear and available frequency upon pressing of start button.
|
|
Pushbutton Handsets with 10 or 12 main pushbuttons (MK 10-22, MK 12-22); 10 to 28 controls are easily configurable by means of various optional actuators: Pushbuttons, Toggle switches, and Key-operated switches.
MK 10DF, featuring Data Feedback, can receive and display data from the controlled machine on a backlit 2-line Liquid Crystal Display or LED lamps. Dedicated pushbuttons control the display's backlighting and data scrolling.
|
|
|
a portable TRANSMITTING UNIT which communicates to the receiving unit, the sequence of digital data that is necessary for carrying out the command selected by the operator using the command devices (pushbuttons, selectors, joysticks).
|
|
|
|
