PHANTOMATIC T3 A
CNC machining centre with three controlled axes, designed for machining operations on bars or workpieces made of aluminium, PVC, light alloys in general and steel up to 3 mm thick. It is provided with a 4-place tool magazine, with provision for containing 2 angle machining heads and a side milling cutter, for machining operations on the 5 faces of the workpiece. It also has a traversing work table which facilitates workpiece loading/unloading as well as considerably increasing the machinable section. |
|
•Full guard, manual door opening
•Console on board LH side machine complete with PC FOMCAM software
•CNC controlled interpolating X, Y, and Z
•Axis sliding X,Y,Z on linear guides with high precision
•X axis movement with DC motor and high pressure reducer
•Y and Z axis movement with DC motors and drive with ground recirculating ball-screw
•Pneumatic rotation of the worktable -90° to 0 to 90°
•Worktable height 850 mm
•Pneumatic vices (n° 4) that translate along the worktable with quick positioning (without use of keys or accessories) (PATENTED)
•Dual working pressure with safety valves for profile stop
•Vices positioning readout on the workable by CN
•Automatic/manual tool change ISO 30 cone with cone tool-holder (6 tools)
•Software automatically corrects tool diameter and length
•Milling capacity: X=3.000, Y=250, Z=120.
•Electrospindle speed: 1000/12000 rpm, 2.2 kW
•Microdrop lubrication
•Set-up for central greasing for recirculating ball-screws and linear guides
•LH and RH profile pneumatic stop
•The profile being machined can be greater than the X milling depth (3.000 mm) alternatively using the pneumatic stops on the left and the right of the machine.
•Air working pressure required 7 bar
•Work cycle air consumption 24 Nl
•Chip bin
|
|
The Univers 4000, at the entry level of the Unisign range of vertical machining centres, is a very flexible and reliable vertical machining centre which offers powerful and accurate machining at a very competitive price. Typical features are the extended Y- and Z-axis of respectively 600 and 500 mm and the upgraded spindle of 26 kW (S1-100%) and 12.000 rpm.
The Univers 6 has gained the reputation of an extremely flexible and reliable machining platform that, due to its flexible design, has found numerous applications throughout the metalworking industry. The vertical clamping front, which has become a trademark for the UNIVERS machines, enables the integration of very specific features such as customer specific fixtures, horizontal and/or vertical rotary tables as A-, B- or C-axis, etc. The right angular head with automatic tool change offers multi-sided machining capabilities.
The Univers 6 C-1 is based on the very successful Univers 6 and is equipped with carousel turning station for components up to approximately Ø 1.000 mm x 400 mm.
The Univers 6 C-2 is similar to the Univers 6 C-1 but with two work zones to enable pendulum machining. Each work zone can be equipped with a carousel turning station. |
|
Chip auger or optional conveyor for chip removal
Huge fully ground machine table with 5 T-Slots
Automatic lubrication
Spindle cartridge cooling system
35HP closed loop spindle motor with two-speed gearbox
AC Yaskawa Digital Servos
110mm O.D. 5 bearing spindle with air-purge seal
Inverted rail design in X axis means table support is always centered under the spindle
1000 IPM rapid traverse
Fully ground double anchored ballscrews
High speed Centurion PC based conversational control
Networking capable |
|
| The structure is made of a machine bed with a sliding carriage in its rear section. Both are in electrowelded steel duly stabilized after each work phase to ensure that there is no interior tension; they are sized to guarantee stability and precision during machining operations. |
|
The Makino Hyper2J ultra-high accuracy micromachining center was created, designed and built to meet the extremely rigorous machining needs in the manufacturing of precise and detailed parts, including: medical instruments, biotechnology products, semiconductor devices, fiber optical communications and optical products, such as liquid crystal displays and spherical lenses. The vertically-oriented machine achieves accuracies and surface finishes that have been previously unattainable. Equipped with an 0.000019 inch (0.5 nanometer) scale feedback and built to exacting alignments, the Makino Hyper2J boasts a positioning accuracy of ±0.3 microns (±0.000012 inch), with a repeatability accuracy of ±0.2 microns (±0.0000078 inch). With an X-, Y- and Z-axis travel of 7.87 x 5.9 x 5.9 inches (200 mm x 150 mm x 150 mm), the Hyper2J can handle up to an 88 pound (40kg) workpiece on a work table size of 11.8 x 7.87 inches (300 x 200 mm).
|
|
| The AZ150L rs a high-accuracy and high-efficiency vertical machining center that machines small-sized-parts wrth nano level accuracy, ft is equipped with counter balance axes to eliminate machine vibration. The AZt 50L can perform excellent and high accuracy machining tor both surface finish and profiles. |
|
» 3-AXIS MILLING MACHINES
Slotted table, high Z travel
» Accurate 3D milling and engraving equipment optimized for the machining of the following materials :
. Aluminium
. Brass and alloy
. Synthetic resins
. Plastics and composites
. Wood and by-products
. Soft stones and marble
» Technology :
. Transmission by ballscrews on all axes with double ballscrew on X axis
» Solid and accurate equipment |
|
Machine specs
- axis travel: 17" x 14" x 8"
- rapid transverse speed: 1,400"/min
- axis acceleration: 1G
- spindle speed: 5,000 - 40,000rpm
Key Featured
- 16 position tool changer
- 40,000 rpm spindle
- glass scale feedback
- linear motor drives
Sodick's linear motor technology provides instantaneous servo time, which maximizes cutting efficiency. Since there are no ball screws or couplings, backlash is totally eliminated. This provides several advantages, including improved positioning and cutting accuracy, while providing smooth and vibration free table movement.
|
|
Chip auger or optional conveyor for chip removal
Huge fully ground machine table with 5 T -Slots
Automatic lubrication
Spindle cartridge cooling system
15HP closed loop WYE/Delta spindle motor with options to 30 HP
Spindle options to 15,000 RPM
AC Yaskawa Digital Servos
110mm O.D. 5 bearing spindle with air-purge seal
Inverted rail design in X axis means table support is always centered under the spindle
1000 IPM X, Y, Z rapid traverse, Optional 1600 IPM
Fully ground double anchored ballscrews
High speed Centurion PC based conversational control
Networking capable |
|
With its ranges WINNER and NORMAPROFIL, MECANUMERIC offers to you various solutions for the applications of machining 5 axes.
Range NORMAPROFIL is intended for the machining of large thermoformées parts, rotomoulées, injected, and the manufacture of moulds and large-sized models.
The range WINNER which uses the architecture of the fixed gantry with a mobile table will be used for the applications of machining 3D of precision.
Many formats useful (X, there, Z) since 1000 X 700 X 600 mm for 3750 X 2250 X 1380 Misters. |
|
| Charlyrobot is the leader in the field with more than 8000 equipment sold in the training centres. These establishments are equipped with digitized axes, of electronic controls, mini-milling machines, numerical milling machines with control or stations of prototyping. You have the formation in line E-Formation. |
|
Thanks to analytical planning studies, SERRTECH develops a "professional" evolution of the M1 model: the M1 PRO model that, thanks to its compact structure and its fixed table characterized from wide workspace it addresses customers who are machining and producing pieces of medium dimensions.
The study of the plan has been focused on factors Like the high-efficiency, the operating ability, the chip evacuation, the ergonomics of the machine, the easy maintenance and the modularity.
The Serrtech models enclose several years of experience in planning and use the best technology available on the market.
STROKE: X-Y-Z- Axis 1650-600-640 mm
TABLE: Working surface 1200x600 mm
Max loading capacity : 3000 kg
ELECTROSPINDLE: 12.000 rpm - Power for 30 min/ cont. 16kW - Max electrospindel torque 102 Nm
RAPID FEEDRATE: 30m/min WORK feedrate: 30 m/min
X-Y-Z axes motor 22-12-40 Nm
POSITIONING PRECISION: +-0,008mm
X-Y-Z Unidirectional repeatability axes +-0,005mm
CAPACITY Tool Changer: 30 - Tool selection: Random
Tool changing time: 1,6 sec
Total power installed: 30kW - Weight 9500 k |
|
| MITSUI SEIKI High Production Machining Center Model VU65A with a 1500 mm by 600 mm Pallet. Numerically controlled with all standard equipment and features including: Automatic Tool Changer, and high production capability for drilling, boring, tapping and reaming. Integrated circuit logic, closed loop, complete electrical equipment for operation on: 3-phases, 50/60Hz, 200/220 Volts AC. |
|
= MV-1003L =
With a highly rigid body and wide machining area, excellent operability is now possible.
The MV-1003 machining center aims for excellent operability. It has a rigid base suitable for large workpieces, as well as a smooth feed, a wide machining area, and high-speed, high-torque spindles. All of these allow effi cient work with no waste.
The MV-1003 produces fi ne, detailed workpiece shapes. This is a heavy-duty machine that combines fl exibility with strength.
* X-axis travel 3,500 mm (137.8 in.)
* Working surface 3,900 mm×1,020 mm (153.5 in.×40.2 in.)
* Table loading capacity 3,500 kg (7,700 lb.)
* Rapid traverse rate X-/Y-/Z-axis: 20 m/min (65.6 fpm)
* Hybrid type external chip conveyor (hinge type + scraper type with drum
filter)
(disposal to left) equipped as standard |
|
= DuraVertical 5060 =
Dura means new value in machine tools
With its "strength through simplicity" and "high flexibility and versatility,"the Dura Series offers the "confidence of stable operation" and "high-precision, high-quality machining," with excellent cost performance.
In order to meet all the requirements demanded of a machine tool, we thoroughly refined the basic functions to create a completely new machine.
This new concept machine, which takes basic performance and reliability to the highest level, will provide powerful support for our customers' machining.
Both the width and depth are smaller than conventional machines, dramatically increasing productivity per unit area.
With a basic design which completely eliminates waste and maximizes travel on all axes, we have secured a large work envelope.
This greater travel makes it suitable for a wide range of workpieces. |
|
| Okuma's powerful ACE Center is the foundation for vertical machining centers that meet the most exacting production needs. Okuma's solid bridge casting, based on our proven Double Column Machining Center Design, results in improved accuracy. Higher spindle speeds, increased thermal stability and improved tolerance control make Okuma Vertical Machining Centers the right choice. Our custom designed linear guideway system and precision-built way system assure optimal performance during high-speed machining or heavy-duty cutting. Our industry leading THINC - OSP Control allows for greater versatility and minimal downtime. |
|
Features :
- Frame design using finite element analysis
- 24-station, swing-arm automatic tool changer
- 8000 rpm belt driven spindle design with coolant ring
- Heavy-duty ball-type linear guideways in all three axes
- Large-size pre-tensioned ball screws
- Servo-driven Z-axis travel for smooth contour machining without mechanical counterweights
- Robust control software and user-friendly, ergonomic control panel
- Dual-linked front doors for easy access
- Rigid tapping
- Artificial intelligence with contour control |
|
The VMC 4020 FX is our most popular VMC. It provides a wide power range for job shop metal cutting flexibility. The VMC 4020 FX is designed with flame hardened integrated box way construction, Steinmeyer ETA+ dual mounted ball screws and spindle speeds ranges 8,000 to 10,000 RPM. This machine is ideal for job shops, mold/die and other mid-range parts producers.
40"x20"x20" Envelope
X/Y/Z axes travel on the VMC 4020 FX is 40" (1,016mm) X 20" (508mm) X 20" (508mm). Rapid Travel rate is 1,000 inch/min (25.4 m/min).
VMC 4020 FX comes with two available control options, Fadal GE Fanuc Oi - MC control or Fadal MP CNC control. With these choices MAG Fadal provides a complete package to meet our customers' ever changing machine requirements.
For detailed specification on VMC 4020 FX with Fadal GE Fanuc Oi- MC control please click here
For detailed specification on VMC 4020 FX with Fadal MP CNC control please click here
For detailed specification on VMC 4020 with GE Fanuc 18i-MB5 CNC control please click here
Advantages of FX Series
Cast iron integrated box way construction for increased vibration dampening
Box way system utilizing integral flame hardened ways for excellent stiffness
ETA Steinmeyer dual mounted ball screws for increased rigidity and reduced friction
Choice of controls; fully digital Fadal GE Fanuc 0i control with a whole host of high-end standard features or intuitive, user friendly proprietary control - Fadal MP CNC
High performance machining and low cycle times
Superior performance in cutting steel and other hard metals |
|
VX Simple and efficient
Machines with vertical spindle suitable for machining work pieces in small and medium series. The VX centres ensure a return on investments very fast !
A simple concept for high performances ! Compact, ergonomic, powerful and precise, the vertical centres HURON VX offer an excellent profitability for operations such as milling, drilling, boring and tapping in the sectors of tooling and production in small and medium series.
VX 10
XYZ 1.020 / 510 / 510 mm
1.200 x 500 mm / 800 kg
8.000 rpm - 16,5 kW
XYZ = 24 m/min |
|
Main Features :
High-Precision Spindle with Low Thermal Distortion
- Stable & high-performance spindle
- Direct-driven spindle
- Jacket cooling
Loading Capacity
- Axis travels(X/Y/Z) : 1,150/550/550mm(45.3¡±/21.7¡±/21.7¡±)
- Table load capacity : 800kgf(1,764lb)
High-Efficiency & High-Productivity
- Rapid traverse : 40/40/30m/min
High-Efficiency Machining Control
- HAI(Hwacheon Artificial Intelligence)
- HECC(Hwacheon Efficient Contour Control)
- Tool overload protector |
|
VMC 430
To match the demand of greater accuracy and total reliability at higher speeds JYOTI has specially developed VMC 430.
VMC 640
To match the demand of greater accuracy and total reliability at higher speeds JYOTI has developed special performance series Vertical Machining Centers.
VMC 850
To match the demand of greater accuracy and total reliability at higher speeds JYOTI has developed special performance series Vertical Machining Centers.
VMC 1050
You can find a range of high technology CNC Lathes that deliver the fastesthmc throughput you need in VMC series manufactured by JYOTI.
VMC 1260
You can find a range of high technology CNC Lathes that deliver the fastesthmc throughput you need in VMC series manufactured by JYOTI.
VMC 640 with APC
Keeping in mind customer's requirement for reducing total production time JYOTI presents vertical maching centers with auto pallet changer for VMC-640.
VMC 1050 with APC
Keeping in mind customer's requirement for reducing total production time JYOTI presents vertical maching centers with auto pallet changer for VMC-1050. |
|
Vertical Machining Center :
Column Traveling Type Compact Machining Center
- Fixed table and column traveling structure are suitable for a factory automation
- Coolant and chips were flushed into the rear of the machine for central chip collection.
- The width of the machine(1,460mm,57.5..) is ideally suited for a factory automation |
|
Recently, the use of aluminium profi les, very popular with the building industry, have become more common for industrial purposes in replacement of other materials.
The transportation, roads, railways, lighting and furniture manufacturing
fields are certainly the more usual users of profi les.
Every week Tekna receives and develops studies for the feasibility and machining times of special parts obtained from extrudates of aluminium, PVC, steel and ABS.
For many of these particulars it is necessary to study and develop special clamping systems, complex tools, differentiated lubrications, software, macro and a lot more.
In some cases, another important element is the “handling”.
Tekna is particularly trained with the solution of these problems.
|
|
| Okuma's powerful ACE Center is the foundation for vertical machining centers that meet the most exacting production needs. Okuma's solid bridge casting, based on our proven Double Column Machining Center Design, results in improved accuracy. Higher spindle speeds, increased thermal stability and improved tolerance control make Okuma Vertical Machining Centers the right choice. Our custom designed linear guideway system and precision-built way system assure optimal performance during high-speed machining or heavy-duty cutting. Our industry leading THINC - OSP Control allows for greater versatility and minimal downtime. |
|
The VMC 3016 FX is a part of the MAG Fadal's FX Series. This compact-designed machine provides customers with unsurpassed performance utilizing heavy-duty box way construction, high speed spindles from 8,000 RPM up to 15,000 RPM, and dual mounted Steinmeyer ETA+ ball screws. With two available control options, MAG Fadal delivers a complete package to meet your ever changing machine requirements.
MAG Fadal VMC 3016FX is designed for versatile metal cutting operations and has a strong focus on rigidity, speed, and controls capability. The machine is especially well suited for die and mold producers and parts manufacturers who need a highly capable machine with low operating costs. MAG Fadal 3016 FX is extremely rigid and delivers fantastic dynamic cutting stability of smaller parts from steel, aluminum or graphite.
30"x16"x20" Envelope
This machine weight is 8,300 lbs (3,765 kg) and the working envelope size is
30" (762mm) x 16" (406mm) x 20" (508mm). The construction type is cast iron Box Way on all three axes.
The VMC 3016 FX has a 21- tool automatic tool changer and standard spindle performance 22.1 HP*/ 77.5 lbf-ft* (17 kW*/ 105 N-m*).
Machine Specification
This machine is available with three choices of controls and whole set of performance enhancing options.
Advantages of FX Series
- Cast iron integrated box way constructions for increased vibration damping
- Box way system utilizing integral flame hardened ways for excellent stiffness
- ETA Steinmeyer dual mounted ball screws for increased rigidity and reduced friction
- Choice of controls; fully digital Fadal GE Fanuc 0i control with a whole host of high end standard features or intuitive, user friendly proprietary control - Fadal MP-CNC
- High performance machining and low cycle times
- Superior Performance in Cutting Steel and other Hard Metals |
|
The development of the latest machining strategies and advancing electronics has produced a new generation of high performance wire EM machines.
The continually changing requirements for finer surfaces and reduced machining times are being fulfilled more and more nowadays. |
|
|
