Liquid flow meter Axial-Turbinen-Durchflussmesser für Flüssigkeiten
magneticvolumeDN25 - 1"

Liquid flow meter - Axial-Turbinen-Durchflussmesser für Flüssigkeiten - Ahlborn Mess- und Regelungstechnik GmbH - magnetic / volume / DN25 - 1"
Liquid flow meter - Axial-Turbinen-Durchflussmesser für Flüssigkeiten - Ahlborn Mess- und Regelungstechnik GmbH - magnetic / volume / DN25 - 1"
Liquid flow meter - Axial-Turbinen-Durchflussmesser für Flüssigkeiten - Ahlborn Mess- und Regelungstechnik GmbH - magnetic / volume / DN25 - 1" - image - 2
Add to favorites
Compare this product
Go to the Ahlborn Mess- und Regelungstechnik GmbH website for more information

Characteristics

Technology
magnetic
Type
volume
Fluid
for liquids
Pipe diameter
DN25 - 1", DN15 - 1/2"
Installation
in-line, threaded
Material
brass
Supply voltage
24VDC, 12VDC, 5VDC, 15VDC, 9VDC, 8VDC, 6VDC, 4.5VDC
Protection level
IP54
Applications
for the food industry, for low flow rates, for high flow rates, laboratory, for the beverage industry, for dosing, for medical applications, for dispensing nozzles
Other characteristics
compact
Volumetric flow rate

Min.: 2 l/min
(0.5283 us gal/min)

Max.: 160 l/min
(42.2675 us gal/min)

Process temperature

Min.: 0 °C
(32 °F)

Max.: 85 °C
(185 °F)

Process pressure

Min.: 0.1 bar
(1.45 psi)

Max.: 2.3 bar
(33.36 psi)

Description

Axial turbine flowmeter for liquids • For measuring the volume flow rate or for dosing tasks with large flow rates. • Compact design. • Wide useful operating range. • Wide variety of applications: Cooling water flow, medical technology, plastics industry, solar systems, baker’s equipment, machine tools, catering equipment, photographic laboratory equipment, dispensers, dosing equipment, cooling equipment, heating applications, calorimetry.
