Thickness tester 547

for tabletsfor productionportable

Overview
A more sophisticated unit than the Tablet Thickness Tester 700, this portable gauge is designed for press operators on the compression floor. It provides straightforward, rapid thickness measurement for in‑line production checks and routine quality control.

Key features

• Portable, easy-to-use design suitable for production environments
• Two measurement modes for flexible use
• Analogue display with optional Digimatic Mini Processor Model 264 for digital data processing

Measurement modes

• Direct measurement: displays actual tablet thickness
• Comparator measurement: indicates ± variance from a pre-set norm on the display for fast production checks

Data output and accessories
Analogue display as standard. Optional Digimatic Mini Processor Model 264 available for digital data capture and extended calculations (control charts, histograms, data displacement charts).

Technical specifications

• Catalogue Number: 4904
• UKAS Calibration Catalogue Number: 4904A
• Max. Tablet Size: 10 mm
• Accuracy: 0.01 mm
• Measurement Unit: mm, inches
• Measurement Modes: Direct (Actual Thickness); Comparator (± Deviation from norm)
• Data Output: Analogue display (Digimatic Mini Processor Model 264 optional)
