Dissolution testing system DTG 400i

for medical devicesfor tabletsfor pharmaceutical applications

The result of decades of innovation and experience in the field of pharmaceutical testing, the DTGi Series of disintegration testers from Copley simplifies testing within R&D and QC environments. Suitable for a wide range of tablet and capsule types (e.g. plain-coated tablets, delayed-release, gelatine etc.), the DTGi tester series is an affordable range of disintegration testers that complies fully with specifications defined in Ph. Eur., USP and associated Pharmacopoeias. Controlled via our intuitive touchscreen interface, the DTGi 400i disintegration tester supports up to four basket rack assemblies. The user-friendly design makes assessing disintegration characteristics a simple touch-of-a-button task. Pharmacopoeial Compliance: Ph. Eur. 2.9.1 USP and Number of Test Stations: 4 Tablet Capacity: 24 Independent Station Control: No Unit Dimensions (w x d x h): 700 x 473 x 657 mm Key DTGi Series Highlights Ph. Eur. and USP and compliant Integrated, precision temperature control and measurement Single-point electronic temperature calibration Intuitive touchscreen control to simplify operation One to four test station unit configurations, plus independent station control unit option Extensive data reporting output options: RS 232, USB A and USB B Adjustable stroke frequency control for accelerated or high sensitivity testing Option to automate and remotely control DTGi systems
