Heavy industry lubrication system SUMO II

oilgreasedual line

The Dropsa electric SUMO II pump is ideal to increase: reliability - thanks to the range of inverters available and safety - maintenance tasks become easier and safer with built-in reducer. DUAL PUMPING MODULE 380 cm3 (2x190 cm3) pump modules installed in tandem configuration provide 400 bar (5880 psi) and redundancy . This allows the system to continue working even if one pump module becomes ineffective. Sumo pump is suitable for large single line or dual line systems. INSTRUMENTATION MODULES Sophisticated add on instrumentation modules and options means even complex requirements can be met with off-the-shelf standard product. QUICK SWAP SYSTEM Both pumping modules can be quickly replaced from the front mounting of the pump. No pipe work needs to be disrupted meaning near-zero downtime during maintenance. DUAL LINE OR SINGLE LINE IS EASY The outlet plate fixing system has both Pressure and Return ports. The outlets are directly compatible with Dropsa's electrical or pneumatic line inverters (including Modular version). Key features: - Dual pump modules as standard for maximum uptime and redundancy - Quick swap pump modules mean zero downtown and disruption to pipe -work during pump maintenance. - High output and pressure make large extended systems possible: - 380 cm3/min (22.8 cu. in), 2x190 cm3/min Modules - 400 Bar (5880 psi) - Electrical dual line inverter integrates directly onto outlet - Minimum level capacitance switch and visual maximum level as standard - Handles Grease NLGI 2
