Electric servo-cylinder FEC80

ball screwwith servo-motorpiston

Product Overview
The cylinder body is manufactured from 6063 high‑strength aluminum alloy (approx. +15% strength) to increase impact resistance and thrust capacity. Cross‑sectional area is increased by 33% to reduce bending under heavy loads. Rod and load‑bearing components are made from 45# high‑strength steel with hard chrome plating for enhanced wear and corrosion resistance. The drive uses an external‑circulation ball screw nut for precise linear transmission. Protection rating IP65. Warranty/support: 2 years or 1000 km operation.

Key Features

• Rated thrust: 1000 kg
• Position accuracy: 0.02 mm
• Stroke length example: 800 mm (custom lengths available)
• Speed range: up to 400 mm/s
• External‑circulation ball screw nut for repeatable linear motion
• Cylinder material: 6063 high‑strength aluminum alloy (+15% strength)
• Rod material/coating: 45# high‑strength steel with hard chrome plating
• Protection class: IP65 (dust and water resistant)

Applications & Additional Details
Designed for heavy‑load linear motion systems that require high thrust and fine positioning, including inline and parallel electric actuator configurations. Typical applications: industrial automation, robotic positioning stages, packaging machinery, and other equipment needing reliable repeatable travel. Product images and documentation include installation modes, dimensional charts and parameter tables for selection and integration.

Technical Specifications

• Thrust: 1000 kg
• Protection rating: IP65
• Position accuracy: 0.02 mm
• Stroke length (example): 800 mm
• Speed range: up to 400 mm/s
• Cylinder body material: 6063 high‑strength aluminum alloy (≈+15% strength)
• Rod / screw material: 45# high‑strength steel with hard chrome plating
• Ball screw type: external‑circulation nut
• Cross‑sectional area increase: +33% (improved rigidity)
• Warranty / Support: 2 years or 1000 km
• Manufacturer: FUYU Technology Co., Ltd.
