Photoelectric sensor with background suppression HRTL 8/66-350-S12

diffuserectangularLED

Operating principle - Diffuse reflection principle with background suppression Operating range - Guaranteed operating range Operating range limit - Typical operating range Beam path - Focused Light source - Laser, Red Laser class - 2, IEC/EN 60825-1:2014 Type of light spot geometry - Oval Focus - Fixed Protective circuit - Polarity reversal protection Short circuit protected Supply voltage UB - 10 ... 30 V, DC Residual ripple - 0 ... 15 %, From UB Open-circuit current - 0 ... 35 mA Number of digital switching outputs - 2 Piece(s) Switching element - Transistor, Push-pull Switching principle - Light switching (PNP)/dark switching (NPN) Switching element - Transistor, Push-pull Switching principle - Dark switching (PNP)/light switching (NPN) Switching frequency - 2,000 Hz Response time - 0.25 ms Readiness delay - 100 ms Function - Signal OUT Voltage supply Type of connection - Connector, Turning, 90° Thread size - M12 Type - Male Material - Metal No. of pins - 5 -pin Encoding - A-coded Dimension (W x H x L) - 15 mm x 48 mm x 38 mm Housing material - Metal Metal housing - Zinc Lens cover material - Glass Net weight - 70 g Housing color - Red Type of fastening - Dovetail grooves Mounting thread Through-hole mounting Via optional mounting device Compatibility of materials - ECOLAB Type of display - LED
