Through-beam photoelectric sensor LS25C/XX-M12

rectangularLEDplastic

Operating principle - Throughbeam principle Device type - Transmitter Operating range - Guaranteed operating range Operating range limit - Typical operating range Light source - LED, Red LED group - Exempt group (in acc. with EN 62471) Protective circuit - Polarity reversal protection Short circuit protected Supply voltage UB - 10 ... 30 V, DC, Incl. residual ripple Residual ripple - 0 ... 15 %, From UB Open-circuit current - 0 ... 20 mA Readiness delay - 300 ms Function - Voltage supply Type of connection - Connector Thread size - M12 Type - Male Material - PUR No. of pins - 4 -pin Encoding - A-coded Dimension (W x H x L) - 15 mm x 42.7 mm x 30 mm Housing material - Plastic Plastic housing - ABS Lens cover material - Plastic Net weight - 22 g Housing color - Red Type of fastening - Through-hole mounting with M4 thread Via optional mounting device Compatibility of materials - ECOLAB Ambient temperature, operation - -40 ... 60 °C Ambient temperature, storage - -40 ... 70 °C Degree of protection - IP 67 IP 69K Protection class - III Approvals - c UL US Standards applied - IEC 60947-5-2
