Polarized retroreflective photoelectric sensor PRK25C.D/4P-M12

rectangular

Operating principle - Reflection principle Application - Detection of stretch-wrapped objects Operating range - Guaranteed operating range Operating range limit - Typical operating range Light source - LED, Red Wavelength - 640 nm LED group - Exempt group (in acc. with EN 62471) Protective circuit - Polarity reversal protection Short circuit protected Supply voltage UB - 10 ... 30 V, DC, Incl. residual ripple Residual ripple - 0 ... 15 %, From UB Open-circuit current - 0 ... 20 mA Number of digital switching outputs - 2 Piece(s) Switching element - Transistor, PNP Switching principle - Light switching Switching element - Transistor, PNP Switching principle - Dark switching Switching frequency - 1,500 Hz Response time - 0.33 ms Readiness delay - 300 ms Function - Signal OUT Voltage supply Type of connection - Connector Thread size - M12 Type - Male Material - PUR No. of pins - 4 -pin Encoding - A-coded
