Battery-operated hydraulic cutter R 320 E4

portable

Overview
The R 320 E4 is a compact, powerful hydraulic rescue ram providing continuous dual‑piston lifting force. Designed for dashboard lifting and confined‑space rescue where controlled extension and reliable on‑tool power are required.

Features

• Dual‑piston continuous extension for smooth force delivery
• LUKAS intuitive dashboard with multi‑sensory alerts
• Integrated high‑intensity lightbar and on‑tool charging

Dual‑piston continuous extension
Delivers uninterrupted, controllable force over the full stroke for precise lifting, pushing and stabilisation during complex rescue operations.

Intuitive dashboard
Provides real‑time status and stroke progression on a clear display, with indicators for saltwater compatibility, power level, roll‑angle alert, temperature, turbo mode, battery capacity and handle direction.

Ergonomic control with Turbo mode
Enables responsive, controlled operation via the star handle to accelerate work when required while maintaining operator precision.

Integrated light bar
Focused illumination at the contact point improves visibility in confined or low‑light conditions and supports accurate positioning.

Multi‑sensory alerts
Combines visual and audible feedback so operators remain aware of tool status even in noisy, high‑pressure environments.

Integrated on‑tool charging
Direct charging to the tool removes the need for battery swaps and ensures the device is mission‑ready.

Technical data
Dimensions: 340 x 207 x 344 mm
Lifting force piston 1: 127 kN
Lifting force piston 2: 60 kN
Piston stroke piston 1: 164 mm
Piston stroke piston 2: 136 mm
Weight: 12.8 kg

Characteristics / technical specifications

• Model: R 320 E4
• Brand: Lukas Hydraulik
• Article number / SKU: SW10216
• Rechargeable battery available: 9 Ah (doubles operating time)
• Saltwater compatible (operation up to 3 m depth for 60 minutes with compatible battery)
• Turbo function activatable via star handle
• Intuitive dashboard indicators: saltwater, power, roll alert, temperature, turbo, capacity, handle direction
• e³ CONNECT compatible (WIFI data transmission)
