Portable hydraulic cutter CR 522 E4 CROSSRAM

Overview
The CR 522 E4 CROSSRAM is a rescue ram designed for extended reach and high lifting capability, suited to cross‑ramming, structural displacement and large‑scale extrication operations.

Key features

• Dual-piston continuous extension
• LUKAS intuitive dashboard with multi-sensory alerts
• Integrated high-intensity lightbar
• Integrated on-tool charging

Dual-piston continuous extension
Delivers smooth, uninterrupted force throughout the full stroke, enabling controlled lifting, pushing and stabilisation in complex rescue scenarios.

Intuitive dashboard
Provides real-time visibility of tool status, power and stroke progression to support precise operator control during critical movements.

Ergonomic control with Turbo mode
Enables responsive, controlled operation when applying force so operators can adapt quickly to changing on-scene conditions.

Integrated light bar
Supplies focused illumination at the contact point to improve visibility and positioning in confined or low-light environments.

Multi-sensory alerts
Combines visual and audible signals to keep operators aware of device status even in noisy, high-pressure situations.

Integrated on-tool charging
Allows direct charging of the tool, eliminating battery swaps and ensuring the unit is mission-ready.

Technical data

• Dimensions: 657 x 153 x 342 mm
• Lifting force piston 1: 127 kN
• Lifting force piston 2: 60 kN
• Weight: 20.7 kg
• Protection class: IP 58
• SKU: SW10217
• Article number: 240
