Industrial vacuum cleaner KAV45TH

dryfor asbestosdust

Summary
Compressed-air vacuum certified ATEX Zone 1 (gases) and Zone 21 (dust) for extraction of hazardous and harmful dust. Capacity: 45 L.

Detailed presentation
The KAV45TH ATEX industrial compressed-air vacuum features a complete 3-stage filtration system. The integrated motor is air-powered, specifically designed for hazardous areas: it does not heat up, avoids any electrical source and contains no electrical components. Earthing and continuity checks are performed on every unit. The KAV45TH ATEX is suited for extraction of carcinogenic and hazardous dusts (examples: asbestos, lead, bacteria, potassium chromate). The tank is stainless steel mounted on a trolley with a tubular protective base and a push handle for easier mobility. Multidirectional wheels, one with brake.

Filtration and safety

• 3-stage filtration: PTFE-treated primary filter (anti-adhesive), absolute filter cartridge, microfiber bag.
• ATEX certified for explosive atmospheres: Zone 1 (gases) and Zone 21 (dust).
• Pneumatic (compressed-air) motor with no electrical components, designed not to generate ignition.
• Earthing and continuity checks carried out on each unit.

Equipment and mobility

• Stainless-steel construction.
• Tubular protective base for the tank.
• Trolley with push handle for easy transport.
• Multidirectional wheels, including one braked wheel.
• Supplied complete with antistatic accessory kit Ø38 mm and 5 m compressed-air hose.

Typical applications
Designed for extraction of hazardous and harmful dusts in industrial environments and ATEX zones (examples: asbestos removal, lead-related works, hospital environments for bacteria extraction, operations requiring capture of carcinogenic dusts).

Characteristics / technical specifications

• Model: KAV45TH
• Capacity: 45 L
• Maximum vacuum: 2700 mmH2O
• Maximum airflow: 130 m3/h
• Sound level: 74 dB
• Motor supply: compressed air (pneumatic), no electrical components
• Filtration: PTFE-treated primary filter + absolute filter cartridge + microfiber bag
• Certifications: ATEX Zone 1 (gases) and Zone 21 (dust)
• Material: stainless steel
• Accessories supplied: antistatic accessory kit Ø38 mm, 5 m compressed-air hose
• Approx. weight: 22 kg
• Vacuum family: Industrial
