Wireless adapter ENW-9720P

PCI interfacereducingprofile

Simple Plug and Play PoE Solution for IPC SystemPLANET ENW-9720P is a 2-port 10/100/1000T 802.3at PoE+ PCI Express server adapter with a maximum of up to 60 watts of power output over Ethernet cables. Incorporated with Intel® I350AM2 server-grade GbE Mac controller, the ENW-9720P provides superb performance to fulfill the requirements of Industrial networks. Compliant with PCIe Express x4 interface (PCIe 2.1), the ENW-9720P can be easily installed into any IPC or server motherboard with a PCIe x4 slot, delivering reliable performance and compliance with industry standards.Each port of the ENW-9720P can deliver 30W of power and 1Gbps bandwidth over a networking cable of up to 100 meters. Its PoE+ capability can power not only PTZ (pan, tilt and zoom) surveillance cameras, but also the latest Wi-Fi 6/6E/7 wireless access points, enabling ultra-high-speed wireless connectivity for modern enterprise networks.Hassle-free Installation for PoE DeploymentPLANET ENW-9720P is backward compatible with both IEEE 802.3af/at PoE standards which allow users to flexibly deploy standard and high-powered devices to transfer data and power simultaneously through one Ethernet cable for up to 100 meters. In addition, the ENW-9720P is powered by the PCIe bus power and via a 12V Mini-Fit 6-Pin power connector, providing greater flexibility in installation.With PoE technology, the ENW-9720P frees IP cameras and wireless APs from power outlet and extra wiring limitations, reducing cabling, simplifying installation, and significantly saving deployment time.Standard 802.1Q VLAN and Jumbo Frame SupportThe ENW-9720P supports IEEE 802.1Q VLAN and 9.5K jumbo frame which allow it to operate in a flexible and secure network environment. With IEEE 802.3 flow control support, it further optimizes throughput and wire-speed packet transfer performance without the risk of packet loss. The high data throughput of the device makes it ideal for most Gigabit Ethernet environments.Multiple OS SupportThe ENW-9720P operates completely well with most of the popular and latest operating systems including Microsoft Windows® 7/8/8.1/10/11(64-bit) Windows Server® 2008 R2/2012 / 2012 R2/2016/2019/2022/2025 and Linux Kernel 2.6.x to 6.x(RHEL / SLES supported, igb driver), enabling simple integration into network designs.Low Profile designThe ENW-9720P supports both full-height and low-profile PCI Express slot. The ENW-9720P provides an accessory of low profile bracket to fulfill IPC with low profile slot. The flexibility of low profile design can help the ENW-9720P meet various applications of industrial networks.Intel® server-grade GbE Mac Controller (Intel I350AM2)PCI Express (PCIe) x4 interface, compliant with PCI Express 2.1 specificationSupports 2 Gigabit Ethernet MAC ControllerFully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3abIEEE 802.3az Energy Efficient Ethernet (EEE)PXE network boot supportIEEE 802.3at compliant with up to 30W power per port, maximum 60W power budgetPCI Express 12V power supply and optional 12V Mini-Fit 6-Pin power connector inputPowered device (PD) auto detection and classificationIEEE 802.1Q VLAN tagging support9.5K jumbo frame sizeDual-profile design (low profile and full-height bracket)Compatible with Microsoft Windows 10/11 Windows Server 2016/2019/2022 and Linux 3.x to 6.xHardware SpecificationsControllerIntel I350AM2Interface2 x RJ45LED IndicatorLink/Act: GreenPoE Link: AmberData Rate10/100/1000 MbpsDimensions (W x D x H)163 x 22 x 120 mmWeight100gPCIe Bus TypePCI Express x4, compliant with PCIe 2.1Power SupplyPCIe 12V bus power and 12V Mini-Fit 6-Pin power connectorTypical Power ConsumptionMax.3 watts/ 10.23BTU (No Loading)Max.63 watts/ 214.83BTU (Full loading)Power over EthernetPoE StandardIEEE 802.3at Power over Ethernet (PSE)PoE Power Supply TypeEnd-spanPoE Power OutputPer port up to 52 VDC, max. 30 wattsPower Pin Assignment1/2(+), 3/6(-)Single PoE Output30 wattsPoE Power Budget60-watt maximumAdvanced FunctionsLayer 2 FeaturesIEEE 802.1Q VLAN support, IEEE 802.3az Energy Efficient Ethernet (EEE), PXE Network BootOperating System SupportWindows® 7/8/8.1/10/11(64-bit)Windows Server® 2008 R2/2012 / 2012 R2/2016/2019/2022/2025Linux Kernel 2.6.x to 6.x(RHEL / SLES supported, igb driver)Standards ConformanceStandards ComplianceIEEE 802.3 10BASE-T EthernetIEEE 802.3u 100BASE-TX Fast EthernetIEEE 802.3ab 1000BASE-T Gigabit EthernetIEEE 802.1Q VLANsIEEE802.3x Flow ControlIEEE802.3af Power over EthernetIEEE802.3at Power over Ethernet PlusIEEE 802.3az Energy Efficient Ethernet (EEE)Regulatory ComplianceFCC Part 15 Class B, CEEnvironmentOperating Temperature-10 ~ 60 degrees CStorage Temperature-40 ~ 70 degrees COperating Humidity5 ~ 90%, relative humidity, non-condensingStorage Humidity5 ~ 90%, relative humidity, non-condensingStandard AccessoriesPackage ContentsENW-9720P Server AdapterLow Profile Bracket6-Pin Mini-Fit Power Cable
