Eccentric screw pump MO-B serieswaterfuel oilfor diesel
Add to favorites
Compare this product
Characteristics
- Technology
- eccentric screw
- Fluid
- water, fuel oil, for diesel
- Operation
- electric
- Mobility
- stationary
- Domain
- industrial, maritime industry
- Applications
- suction
- Material
- bronze
- Fluid specification
- for viscous fluids
- Flow
2.8 m³/h
(98.88107 ft³/h)- Pressure
3.5 bar
(50.763 psi)- Power
Max.: 1.5 kW
(2.04 hp)Min.: 0.37 kW
(0.5 hp)
Description
Offset rotor pumps with bronze pump body
Descriptive
Technical data:
Pump body: bronze
Max. viscosity: 500 cPo
Suction capacity: 3 metres
Orifice Ø: 1’’
Hard particles: 3.2 millimetres
Soft particles: 6.4 millimetres
Specifications and advantages:
Helical screw electric pumps with bronze bodies, mostly used in the maritime industry for transfers on ships: waste tankers, waste water discharges from toilets, heavy liquids with suspended solid particles, viscous and oily liquids such as lubricant oils, waste oils, fuel oil, diesel, etc.
Characteristics
Fluid - Water with low solids contect, Seawater, Fluids with particulates, Diesel, Oil
Technology - DC, Eccentric rotor
ATEX - No
Pump - Bare
Orifice - 1’’
Materials - Bronze
Mechanism - NBR
