Wine pump JEX seriesoilfor chemicalsfor seawater
Add to favorites
Compare this product
Characteristics
- Fluid
- for seawater, for chemicals, for wine, for juice, oil
- Operation
- electric
- Technology
- side-channel
- Mobility
- stationary
- Domain
- industrial, chemical
- Material
- stainless steel, steel
- Voltage
- 24 V, 12 V
- Protection level
- ATEX
- Flow
3.5 m³/h, 7.2 m³/h
(123.60133 ft³/h, 254.2656 ft³/h)- Head
10 m, 22 m
(32'09" , 72'02" )- Power
0.37 kW, 1.12 kW
(0.5 hp, 1.52 hp)
Description
Electric side-channel pumps with DC motor
Descriptive
Technical data:
Pump with low-voltage motor, stainless steel 316 body
Liquid foods, industrial and chemical liquids without solid impurities.
Rotation speed: 2000 rpm, 1400 rpm
Current: 32 A (JEX114C1), 20 A (JEX114C2), 45 A (JEX112C2)
Orifice Ø: 1"1/4 M, 1"1/2 M (JEX112C2)
Specifications and advantages:
Electric side-channel pump with DC motor
Characteristics
More Information
Fluid - Seawater, Fertilizers, Oil, Juice, Milk, Chemical liquids, Wine
Technology - DC, Side channel
ATEX - No
Pump - Bare
Orifice - 1"1/4 M, 1"1/2 M
Materials - Stainless steel 316
Mechanism - Stainless steel 316
