Impeller pump JEP‐NBR
for chemicalsfor food productsbeer

Impeller pump - JEP‐NBR - Pompes Japy - for chemicals / for food products / beer
Impeller pump - JEP‐NBR - Pompes Japy - for chemicals / for food products / beer
Add to favorites
Compare this product
Go to the Pompes Japy website for more information

Characteristics

Technology
impeller
Fluid
for chemicals, for food products, beer, for wine, oil, for diesel
Operation
electric
Mobility
stationary
Domain
industrial, for the chemical industry, for the food and beverage industry, for the wine industry, for the cosmetics industry
Material
stainless steel
Voltage
24 V, 12 V, 380 V
Flow

1 m³/h, 1.62 m³/h
(35.31467 ft³/h, 57.20976 ft³/h)

Head

Max.: 32 m
(104'11" )

Min.: 0 m
(0'00" )

Power

0.3 kW, 0.37 kW, 0.56 kW
(0.41 hp, 0.5 hp, 0.76 hp)

Description

Flexible impeller pumps with stainless steel body Descriptive Technical data: Reversible pumps (2-way) Industrial: diesel, oils, etc. Wine-making: wine, must, etc. Food processing: beer, sugar, fruit pulp, liquid sugar, syrup, glucose, milk, butter, yoghurt, liquid eggs, oil, tomato sauce, brine, etc. Chemicals: starch, glue, water-based adhesives, emulsions, glycerine, wax, detergents, varnishes, inks, industrial waste, etc. Cosmetics and pharmaceuticals: liquid soaps, detergents, shampoos, creams, etc. Orifices: 3/4’’ M Particle size: 3 millimetres Maximum suction lift: 6 metres Current: 30 A (JEP34C1‐1400‐NBR), 16 A (JEP34C2‐1400‐NBR), 3.7 A (JEP34‐900‐NBR), 3.8 A (JEP34‐1400‐NBR) Rotation speed: 1400 rpm, 900 rpm (JEP34‐900‐NBR) Max. viscosity: 500 cPo, 1500 cPo (JEP34‐900‐NBR) Specifications and advantages: Flexible impeller pump with stainless steel body Characteristics Fluid - Water with low solids contect, Fluids with particulates, Diesel, Oil Technology - DC, Flexible impeller ATEX - No Pump - Bare Materials - Stainless steel Mechanism - NBR impeller
