Water pump G30C1-AUTOMINIfor dieselelectricboosted priming
Add to favorites
Compare this product
Characteristics
- Fluid
- water, for diesel
- Operation
- electric
- Priming
- boosted priming
- Technology
- side-channel
- Mobility
- stationary
- Domain
- industrial
- Applications
- booster
- Material
- stainless steel, brass
- Voltage
- 24 V, 12 V
- Protection level
- ATEX
- Other characteristics
- compact
- Flow
1 m³/h, 1.2 m³/h
(35.31467 ft³/h, 42.3776 ft³/h)- Head
11 m, 12 m
(36'01" , 39'04" )- Power
0.22 kW
(0.3 hp)
Description
Compact booster unit
Descriptive
Technical data:
Electric pump with brass body (stainless steel optional)
Equipment: pressure switch, pressure gauge and check valve
Tank: 2 litres
Rotation speed: 2400 rpm
Current: 20 (G30C1-AUTOMINI), 12 (G30C2-AUTOMINI)
Orifice Ø: 3/4" F
Max. TDH: 11 metres (G30C1-AUTOMINI), 12 metres (G30C2-AUTOMINI)
Specifications and advantages:
Compact booster unit
Characteristics
More Information
Fluid - Water with low solids contect
Technology - DC, Side channel
ATEX - No
Pump - Bare
Orifice - 3/4" F
Materials - Brass
Mechanism - Brass
