Plate ultrasonic transducer EI series

direct-contactimmersible

Product overview
Constructed on a 30/10 thick AISI 316 stainless steel support, with multiple vibrating elements bonded using a special epoxy resin. Each sonotrode comprises two dipole element disks, an aluminum diffuser and a steel reflector. Available emitter power ranges: 50/100 W or 100/200 W. Operating frequencies: 24 kHz or 38 kHz. Versions: flanged supports (EF series) and submersible supports (EI series).

Submersible supports
Submersible supports are fabricated in AISI 316 stainless steel and hermetically TIG welded. Standard and custom designs are available. All submersible transducers include a straight rigid tube (h = 300 mm, d = 1/2 inch) with sleeve.

Submersible supports - table
MODEL | USEFUL DIMENSIONS (mm) | MAX HEIGHT (mm) | MAX NUMBER OF EMITTERS (50 or 100 W)
EI 5 | 200×300 | 100 | 5
EI 10 | 400×300 | 100 | 10
EI 15 | 550×300 | 100 | 15
EI 20 | 600×400 | 100 | 20
EI 25 | 600×460 | 100 | 25

Flanged supports
Flanged supports are manufactured in AISI 316 stainless steel with hermetic TIG welds. Standard and custom designs are available.

Flanged supports - table
MODEL | USEFUL DIMENSIONS (mm) | MAX HEIGHT (mm) | MAX NUMBER OF EMITTERS (50 or 100 W)
EF 5 | 200×300 | 100 | 5
EF 10 | 400×300 | 100 | 10
EF 15 | 550×300 | 100 | 15
EF 20 | 600×400 | 100 | 20
EF 25 | 600×460 | 100 | 25

Technical specifications

• Support material: AISI 316 stainless steel (30/10 thickness)
• Vibrating element (sonotrode): two dipole disks + aluminum diffuser + steel reflector
• Emitter power options: 50/100 W or 100/200 W
• Operating frequencies: 24 kHz or 38 kHz
• Available versions: flanged supports (EF series) and submersible supports (EI series)
• Submersible fitting: straight rigid tube, h = 300 mm, d = 1/2 inch, with sleeve
• Available models: EI 5, EI 10, EI 15, EI 20, EI 25 and EF 5, EF 10, EF 15, EF 20, EF 25 (see tables for dimensions and max emitters)
