Stainless steel drying cabinet

Overview
Our solvent dryers operate with any compatible non-flammable solvent. Built entirely in AISI 316 stainless steel, the units comprise multiple tanks arranged in cascade. The first tank holds the drying solvent and extracts water; subsequent tanks remove residual surfactants to deliver parts dry and free of streaks.

Water separation and skimming
The initial treatment stage features a gravitational water separator. A skimming ramp powered by a dedicated centrifugal pump and fitted with a 20-micron filter evacuates all water removed from the treated components.

Treatment cycle

• Loading
• Ultrasonic immersion pre-cleaning
• Immersion washing
• Immersion rinsing
• Steam rinsing
• Condensation drying
• Unloading

Technical specifications

• Compatible with non-flammable solvents
• Construction: 100% AISI 316 stainless steel
• Multi-tank cascade layout (first tank: drying solvent; following tanks: surfactant removal)
• Gravitational water separator in first section
• Skimming ramp with dedicated centrifugal pump
• Skimming system includes 20 µm filtration
• Process flow: ultrasonic pre-clean, immersion wash/rinse, steam rinse, condensation drying
