Spraying part washer LSS series

rotary

Product overview
The LSS series single-stage rotating-table spray washers are constructed entirely in AISI 304 stainless steel and are engineered for industrial parts cleaning. They are supplied complete with:

• insulated and heated tanks
• double-walled stainless steel construction
• automatic hermetic door
• cabin insulation
• gravitational oil separator with baffles
• removable cassette filter for falling liquid
• automatic centering and indexing of basket rotation
• stainless steel inspection ports
• basket support pallet
• fume extraction fan
• electronic PLC programmer

Technical data / Model

• LSS 1000: square basket 750 × 750 mm (rounded corners standard 850 × 850 mm); free height 600 mm; useful capacity 700 kg; washing pressure 5 bar; pump 4 kW, flow 300 L/min; 3 spray ramps; wash tank 750 L; electric heating 18 kW; external dims 1,600 × 2,450 × 2,550 mm (front × depth × height)
• LSS 1400: square basket 1,000 × 1,000 mm (rounded corners standard 1,150 × 1,150 mm); free height 800 mm; useful capacity 1,000 kg; washing pressure 4.5 bar; pump 5.5 kW, flow 350 L/min; 3 spray ramps; wash tank 750 L; electric heating 18 kW; external dims 2,000 × 2,850 × 2,650 mm
• LSS 1800: square basket 1,250 × 1,250 mm (rounded corners standard 1,500 × 1,500 mm); free height 1,000 mm; useful capacity 1,500 kg; washing pressure 4.5 bar; pump 7.5 kW, flow 350 L/min; 3 spray ramps; wash tank 1,000 L; electric heating 27 kW; external dims 2,400 × 3,250 × 2,750 mm

Features / Technical specifications

• Construction material: AISI 304 stainless steel
• Type of wash: spray, basket rotation on vertical axis
• Standard items: insulated heated tanks, hermetic automatic door, gravitational oil separator, removable cassette filter, inspection ports, mechanical filters (filtration grade 500 µm where specified), PLC control
• Standard capacities: LSS 1000 – 700 kg; LSS 1400 – 1,000 kg; LSS 1800 – 1,500 kg
• Pump power & flow: 4 kW / 300 L/min (LSS 1000); 5.5 kW / 350 L/min (LSS 1400); 7.5 kW / 350 L/min (LSS 1800)
• Optional items: movable basket support trolley, gas heating (burner + heat exchanger), warm air drying, wastewater discharge circuit, fog control, double loading station, disk oil separator
