Electric forklift XVB38-QL8-C

ride-onindustrialhandling

The XCMG official 3.8t Electric Balance Forklift XVB38-QL8-C is designed for heavy-duty material handling with a rated lifting capacity of 3.8 tonnes. It integrates a high-voltage electric drive and thermal management for battery, motor and control systems to support continuous industrial operations.

Configuration / Key features

• 160V high-voltage permanent magnet synchronous system
• IPX5 vehicle water protection
• Liquid cooling for the three electric systems (battery, motor, control)
• 2-spool valve
• 2-stage mast, 3 m lifting height
• 1070 mm fork length (standard / configurable item)
• Full pneumatic tires
• Battery heating (standard)
• 1C fast charging support

Specifications / Technical data

• Model: XVB38-QL8-C
• Rated lifting capacity: 3800 kg (3.8 t)
• Load center: 500 mm
• Fork width (overall width): 1450 mm
• Fork length: 3075 mm
• Max lifting height: 3000 mm (3.0 m)
• Maximum travel speed (loaded): 20 km/h
• Maximum travel speed (unloaded): 22 km/h
• Lifting speed (loaded): 480 mm/s
• Lifting speed (unloaded): 520 mm/s
• Lowering speed (loaded): ≤ 600 mm/s
• Gradeability (loaded): ≥ 20%
• Overall length (without fork): 3075 mm
• Turning radius: 2450 mm
• Total weight (including battery): Approx. 5200 kg
• Power source: Electricity (electric drive)
• Type: Balance forklift
• Brand: XCMG
• Place of origin: Xuzhou, Jiangsu, China
• Warranty: One Year
• Minimum order quantity: 1 Unit
• Delivery time: In Stock (Within 7 days); Production (Within 15 to 20 days); Customization (negotiated delivery time)
• Shipping support: Sea freight · Land freight · Air freight
• After-sales service: Engineers available to service machinery overseas
