High-voltage amplifier ATA-2042

signalvoltageinstrumentation

The ATA-2042 is an ideal dual-channel high-voltage amplifier capable of amplifying both AC and DC signals. It delivers a maximum output of 400 Vp-p (±200 Vp), suitable for driving high-voltage loads. The digitally adjustable voltage gain allows precise tuning, with one-click saving of common settings, offering a simple and user-friendly operation. It is compatible with mainstream signal generators for seamless signal amplification. LCD PANEL DISPLAY The LCD panel display dynamically shows the device status and parameters, offering a clear and intuitive interface. Voltage Gain The voltage gain is digitally adjustable from 0~60x, with two modes: coarse adjustment (1 step) and fine adjustment (0.1 step). Combined with the LCD panel display, it enables quick and precise adjustment to the desired voltage value. Input The input uses a BNC interface with selectable impedance of 50Ω or 5kΩ, perfectly matching both high and low impedance signal sources. Output The output uses banana sockets, with a maximum output voltage of 400 Vp-p (±200 Vp) and a maximum output current of 100 mAp. Monitor 10mV/V Monitor: This port voltage is 1/100 of the output port voltage. The monitoring port uses a BNC connector and can be directly connected to an oscilloscope for real-time monitoring of the output voltage. 10V/A Monitor: The monitoring port voltage is 10 times the output current. The monitoring port uses a BNC connector and can be directly connected to an oscilloscope for real-time monitoring of the output current.
