Power amplifier ATA-3090C

currentdigitalultrasonic

The ATA-3090C is an ideal power amplifier capable of amplifying both AC and DC signals. With a maximum output power of 1000 Wp, it can drive high-power loads. The gain is digitally adjustable, with one-click saving of commonly used settings, providing a convenient and user-friendly operation. It is compatible with mainstream signal generators, ensuring seamless signal amplification. The wide-range power supply accommodates different regional power standards worldwide. LCD PANEL DISPLAY The LCD panel display dynamically shows the device status and parameters, offering a clear and intuitive interface. Voltage gain The voltage gain is digitally adjustable from 0~30x, with two modes: coarse adjustment (1 step) and fine adjustment (0.1 step). Combined with the LCD panel display, it enables quick and precise adjustment to the desired voltage value. Input The input interface uses a BNC interface, supporting input waveform amplitudes from 0~10 Vp-p MAX. The input impedance has two selectable options: 50Ω and 100kΩ, perfectly matching both high and low-impedance signal sources. Output Output Interface: Banana socket, with a maximum output voltage of 100 Vp-p (±50 Vp), and a maximum output current of 20 Ap. Applications Ultrasonic Testing Electromagnetic Testing Battery Testing Various Semiconductor Testing
