Manual lathe C6250A/6256C/6266C/6277C

horizontalhigh-performancehigh-productivity

1. The guide rail of the bed is finely ground after ultra-light audio quenching, and has a long service life. The gears are precision ground, and the noise of the whole machine is low. 2. There is no need for change gear. The machine can turn about 90 kind of metric, Inch, Module and D.P. threads. 3. Rapid feed structure is available on apron. Item - Unit - C6250A - C6256C - C6266C - C6277C Processing - 　 - 　 - 　 - 　 - 　 Width of bed - mm - 405 - Effective gap length - mm - 230 - Spindle - 　 - 　 - 　 - 　 - 　 Spindle nose - 　 - D8 - Spindle bore - mm - Ф80 - Ф105 Taper of bore - 　 - M.T.No.7 - Metric Ф113 1:20 - Steps of spindle speed 12 Steps - Thread cutting - 　 - 　 - 　 - 　 - 　 Metric range/No. - 　 - 1~14mm/22 - Inch range/No - 　 - 28-2T.P.I/26 - D.P.Range/No. - 　 - 56~4D.P/24 - Module range/No. - 　 - 0.5~7M.P/18 Feed - 　 - 　 - 　 - 　 - 　 Range of longitudinal feed mm - 0.063~2.52 - Range of cross feed mm - 0.027~1.07 - Travel 　 - 　 - 　 - 　 - 　 Longitudinal - m/min - 4.5 - Cross - m/min - 1.9 - Max.travel of top slide - mm - 145 - Max.travel of cross slide - mm - 340 - 310 - 360 - 430 Max. size of tool shank (W×H) - mm - 25×25 Tailstock - 　 - 　 - 　 - 　 - 　 External Dia. - mm - Ф75 - Ф75 - Ф75 - Ф75 Taper of bore - 　 - M.T.No.5 - M.T.No.5 - M.T.No.5 - M.T.No.5 Max. traverse - mm - 150 - 150 - 150 - 150 Power of main motor(double speeds) - kW - 7.5 - 7.5 - 7.5 - 7.5 Overall dimensions(LxW×H) - mm - 2500/3000/3500/4500× 1280/1070×1380 - 2500/3000/3500/4500× 1280/1070×1350 - 2500/3000/3500/4500× 1280/1070×1450 - 3000/3500/4500×1610×1540 Net weight - kg - 2900/3150/3400/3750 - 2400/2650/2900/3250 - 3000/3200/3400/3900 - 3000/3800/4000
