Track scissor lift YG0 series

wheeledmobileself-propelled

Overview
The YG Machinery mobile hydraulic scissor lift series is an aerial work platform designed for construction, facility maintenance and industrial material handling. Models offer compact footprints for confined spaces, robust manganese-steel scissor arms for structural stability, and a pump-driven hydraulic system for controlled vertical lifting.

How They Work and Unique Design
The system uses a hydraulic pump to pressurize fluid that actuates pistons, moving the scissor arms (or boom) for vertical extension. This architecture provides high load capacity, smooth height regulation, accurate flow control and an integrated emergency descent mechanism. Scissor arms are fabricated from high-strength manganese steel to maximize stability and service life.

Core Advantages

• Stability and Safety: Hydraulic control ensures platform stability; equipment includes emergency descent devices, guardrails and anti-slip decking.
• Low Maintenance and Efficiency: Hydraulic drive reduces mechanical wear and the number of moving parts, lowering maintenance needs and downtime.
• Configuration Flexibility: Available as semi-automatic, self-propelled (wheeled) and tracked models; options include scissor lifts, articulated/telescopic booms and tracked scissor variants for rough or unpaved sites.

Applications

• Construction and Installation: Steel framework erection, curtain wall installation, elevated pipeline routing, electrical and mechanical works.
• Facility Maintenance: Lighting replacement, fire-safety system maintenance, roof and terminal inspections.
• High-Reach Material Handling: High-level stacking, loading/unloading and lifting with telescopic/boom forklift solutions.

Product Table (parameters)
Model | Up (m) | Load (kg) | Platform size (m) | Outline dimensions / guardrail folding (m) | Lifting motor | Weight (kg)
YG0608SP | 5.8 | 230 | 1.67*0.74 | 1.86*0.76*1.84 | 24v/3.3kw | 1580
YG0608 | 6 | 450 | 2.27*1.12 | 2.48*1.19*1.66 | 24v/3.3kw | 2170
YG0810NP | 8 | 230 | 2.27*0.81 | 2.48*0.83*1.99 | 24v/3.3kw | 2260
YG0810 | 8 | 450 | 2.27*1.12 | 2.48*1.19*1.78 | 24v/3.3kw | 2360
YG1012 | 10 | 320 | 2.27*1.12 | 2.48*1.19*1.91 | 24v/3.3kw | 2640
YG1214 | 11.8 | 320 | 2.27*1.12 | 2.48*1.19*2.03 | 24v/4.5kw | 2980
YG1416 | 13.7 | 230 | 2.64*1.12 | 2.85*1.25*2.105 | 24v/4.5kw | 3600

Distinct Core Advantages and Product Line Expansion

• Integrated emergency descent devices and multiple safety features to protect operators during power loss or system faults.
• Hydraulic operation reduces mechanical wear, lowering routine service needs and improving uptime.
• Multiple drive and configuration options (wheeled, tracked, self-propelled, semi-automatic) to suit indoor, paved outdoor and rough-terrain conditions, including tracked scissors for muddy or sloped sites.

Wide Range of Applications
This mobile hydraulic lift series is suitable across sectors: construction, facility maintenance, material handling, indoor/outdoor installations and confined-space operations where a compact footprint and portability are required.

Characteristics / Technical specifications

• Brand: YG Machinery
• Primary types: mobile hydraulic scissor lift, tracked scissor lift, self‑propelled wheeled models, semi‑automatic scissor lifts
• Hydraulic system: pump-driven piston with emergency descent mechanism
• Structure: high-strength manganese steel scissor arms
• Power: lifting motor options typically 24V/3.3kW or 24V/4.5kW depending on model
• Platform sizes: examples from 1.67×0.74 m to 2.27×1.12 m
• Working heights (Up): from ~5.8 m to ~13.7 m
• Rated loads: 230 kg, 320 kg, 450 kg depending on model
• Weights: approximately 1,580 kg to 3,600 kg across models
• Typical uses: indoor maintenance, outdoor construction, high‑reach material handling
