Non-destructive measurement of non-magnetic coatings, e.g. paint, enamel, chrome on steel and insulating coatings, e.g. paint and anodizing coatings on non-ferrous metals.
Universal probe with auto-mode for measurements on steel and non-ferrous metals
With the Universal Probe (MiniTest 600FN only) and "auto-mode" the probe senses the type of substrate the coating is applied over and automatically switches to either the Magnetic Induction or the Eddy Current principle. Eliminates manual adjustments and ensures that the correct principle is always utilized without having to know the actual type of substrate coated.
Wear-resistant probes of practically unlimited lifetime
|
|
Magnetic coating thickness gauge working on the magnetic attraction principle. The sturdy metal housing and a clear glass scale combine to make this gauge a most efficient tool for non-destructive, quick and accurate coating thickness measurement.
Suitable for:
- all non-magnetic coatings, e.g. copper, chrome, paint, enamel, etc. on steel
- electroplated nickel coatings directly applied on steel
Performance features
- Non-wearing permanent magnet
- Measuring without power supply
- No calibration required
- Measurement at any angle
- High accuracy
- Measurement of coatings up to 20 mm
|
|
Non-destructive measurement of non-magnetic coatings (e.g. paint, zinc) on steel, insulating coatings (e.g. paint, anodising coatings) on non-ferrous metals and non-ferrous metal coatings on insulating substrates.
Four basic gauges with different possibilites of processing of readings
Wide variety of wear resistant probes can be connected
High accuracy and reproducibility
Storage and documentation of readings
99 calibration memories available
Large-sized display with backlight
|
|
|
|
|
|
The three models of the MiniTest 700 series offer a flexible solution to all measuring requirements for coating thickness measurements on steel or on non ferrous substrates.
Correct readings with interference free measurement with precise evaluation through SIDSP® (sensor integrated digital signal processing)
Extended field of application through exchangeable sensors to cover different ranges up to 15 mm thickness
High flexibility of use through versatile sensors (MiniTest 740 sensor can be changed from built-in to external sensor on a lead)
Automatic substrate identification with FN sensors accelerates measurements and helps avoiding operating errors
Efficient temperature compensation eliminates errors caused by changes in temperature
High precision characteristic curves achieved during the manufacturing process by calibrating up to 50 calibration points
Large memory capacity for storing up to 100,000 readings in 10 and/or 100 batches
Readings and statistical values can be called-up individually
Large, easy-to read backlit graphics display, with 180° rotatable display orientation
Easy menu-guided operation, 25 menu languages are available
Built-in IrDa port for infrared data transmission to printer or PC
Future-proof through downloadable sensor and gauge software updates
|
|
DELTASCOPE FMP10 and FMP30 - ISOSCOPE FM10 and FMP30 - DUALSCOPE FMP20 and FMP30
The FMP hand-held instruments measure coating thicknesses non-distructively with high precision. Magnetic induction (DELTASCOPE), eddy current (ISOSCOPE) or both methods (DUALSCOPE). They are modern, robust and user-friendly an can be adapted to any measuring application using interchangeable probes.
FMP10 and FMP20 are entry level models for professional evaluation of coatings, ideal for repetitive measuring applications.
FMP30 and FMP40 feature additional strategies for measurement capture, more memory and extensive graphical and statistical evaluation capabilities.
With their USB interface all FMP instruments support data communication to PC. The FMP30 and FMP40 are able to send a measuring report directly to a USB-printer.
|
|
DUALSCOPE and ISOSCOPE MP0/MP0R series
Robust, handy and small - the MP0/MP0R-series. For mobile, precise and non-destructive coating thickness measurements using magnetic inductive or eddy current method.
The professional measurement technology from FISCHER in a compact design. With two rectangular placed displays and bright illumination for an outstanding readability. Perfect suited for quick reliable and precise measurements – also under difficult conditions like hardly accessible areas or bad illumination.
In various versions available:
DUALSCOPE MP0: For measurement of coatings on ferrous or non-ferrous materials.
DUALSCOPE MP0R: With additional radio- and USB-interface for data transmission to a PC
DUALSCOPE MP0R-FP: With fixed cable probe, radio- and USB interface
ISOSCOPE MP0R: For measurements only on non-ferrous materials. With radio- and USB interface.
|
|
The DUALSCOPE FMP100 is the most advanced in the FMP-family. A measurement computer which offers an extremely user-friendly operation, a high resolution color touch screen and a Windows CE operating system. The DUALSCOPE FMP100 is a universal solution, using magnetic induction and the eddy current methods.
The FMP100 is ideal for different measurement applications because settings and calibrations can be stored and recalled right on the display.
In addition to extensive evaluation and statistics functions, the FMP100 offers flexible graphical presentations of the measurement data. An Innovative tool for quality control, the FDD-software (Factory Diagnosis Diagram) is integrated.
For various measurement applications in the field of coating thickness a broad range of probes is available. A robust connector with build in intelligence makes it quick and easy to change a probe.
|
|
|
|
|
|
Coating Thickness measurement made easy at any angle!
Oxford Instruments is pleased to announce the launch of its new CMI153 and CMI 250 Coating Thickness gauges developed for the Paint and Powder Coating Industry.
These robust handheld devices combine Eddy Current and Magnetic Induction technology to automatically recognize the base material and instantly switch to the correct mode for measurement over ferrous and non-ferrous substrates.
Easy-to-use, the menu driven CMI153 is a single button factory pre-calibrated unit that delivers excellent accuracy and precision.
The innovative CMI250 offers factory pre-calibration and user created calibration capability, temperature compensation, data storage options, date and time stamp, statistical analysis, USB to PC connectivity, and the added advantage of a rotating flip display screen enabling coating measurements to be read at any angle!
These versatile instruments are ideal thickness measurement solutions for:
•Industrial Coatings
•Appliance Finishing
•Paint & Powder Coating
•Automotive & Aerospace Finishing
•Coating inspectors
•Electroplating or galvanizing
|
|
|
|
|
|
The Sonacoat P is the new paint thickness gauge from Sonatest Ltd -providing fast, accurate, non-destructive coating thickness measurements on steel and non-ferrous materials.
No surface damage, no grinding required.
Fast and easy to use - by simply placing the Sonacoat P on the surface to be tested, an accurate thickness reading is shown on the large display screen. This gauge also automatically selects the optimum measuring method (magnetic induction or eddy current), providing highly accurate readings, even for the thinnest of coatings. No calibration is required.
Find out more about your bodywork!
Ideal for auto dealers, inspections stations, auto paint and body shops the Sonacoat P can also provide the end user with valuable information regarding the coating structure such as paint topcoats or body fillers. When the measured thickness value clearly exceeds the standard paintwork thickness, this would then indicate the use of filler material or repainting.
The speed, simplicity and accuracy of the Sonacoat P make this gauge an invaluable tool for a wide range of inspection tasks.
Sonatest Ltd celebrates it’s 50th Anniversary in 2008 and is part of the Sonatest NDE Group of Companies; the leading independent manufacturer of Ultrasonic Flaw Detectors, X-Ray Equipment, Scanning Systems, Thickness Gauges, Transducers and NDT accessories. Find out more about Sonatest Ltd and our products by visiting www.sonatest.com
|
|
|
|
|
|
Sonacoat Easy II F/FN
Easy to operate menu structure. No calibration necessary. Infrared interface for cable free data transfer. Online statistics software. Measurement memory & Statistic memory. Choice of languages available.
The Sonacoat is designed for fast, practical and accurate non destructive coating thickness measurement. A dual purpose innovative gauge used for measurement on steel and non-ferrous metals with automatic substrate recognition, activating the appropriate measuring procedure. The Sonacoat II-F can be used for all non-ferrous coatings of varnish, paint, enamel, chrome, copper, zinc etc on steel and and iron. This gauge is also suitable both for the laboratory and harsh field conditions. The built-in IP52 safeguards protection against dust and dripping water.
Sonacoat Easy
Ideal for Paint and powder coatings. Paint shops. Automotive and ship building. Verification of zinc coatings under the paintwork.
Two Models available:
Sonacoat Easy F - for steel, with integrated transducer.
Sonacoat Easy FN - for all metals.
�� User-friendly. Switch on and use instantly!
�� Fast and precise measurements.
�� Wide measuring range up to 3,500 ìm.
�� Highly accurate on flat, rough, and curved surfaces.
|
|
Snap-Cal - 461 Series
Spring-loaded travel
Inch/mm conversion
Wide faced flat jaw for easy positioning
Hardened stainless steel construction
Supplied in rugged holster
|
|
Non-destructive measurement of paint, plastic, enamel and other insulating coatings applied on wood, plastic, glass, ceramic and also on metals according to the ultrasonic principle.
Measurement of a multi-layer system in only one measuring process
High accuray and reproducibility
Storage and documentation of measuring values
Measuring range: 10... 500 µm
Memory capacity: max 10,000 readings
|
|
|
|
|
|
Cygnus 2 - Hands Free
Multiple Echo Ultrasonic Thickness Gauge
The new Cygnus 2 is the smallest, lightest and most durable through coating thickness gauge available. Designed for use in rope access or belt mounted applications where the end-mounted LED display can be easily read whilst taking measurements. The Cygnus 2 is supplied ready to use as a complete kit in a protective carry case.
Features
• Hands free operation: Belt/Harness clip and Neck Strap included
• Light, rugged, small, shock-proof within IP65 sealed aluminum enclosure
• Protective silicone sleeve offers maximum protection and versatility
• Simple keypad operation
• All measurements are error checked using 3 return echoes
• to give repeatable, reliable results
• Gauge senses probe type and automatically adjusts
• settings for optimum performance
• Accepted by all major classification societies
• Single crystal probe to ensure accurate measurements on
• curved and heavily corroded back walls
• Echo strength indicator to aid measurement
• Calibration to a known thickness or a known velocity of sound
• Display brightness automatically adjusts to suit ambient
• light conditions
• Low battery warning
• Metric / Imperial switchable
Applications
• Metal thickness monitoring on cranes, marine structures and conveying systems
• Corrosion checks on ships’ shell plates, bulkheads and structures
• Metal thickness safety checks on steam and pressurised water systems,
• transportable gas containers and compressed air systems
For more information please visit www.cygnus-instruments.com
|
|
|
|
|
|
Cygnus Underwater
Multiple Echo Ultrasonic Thickness Gauge
A tough Ultrasonic Thickness gauge using our Multiple Echo technology, designed for use by divers undertaking subsea surveys. The instrument is rated to a depth of 300 m. The Cygnus 1 Underwater is supplied ready to use as a complete kit in a protective carry case with 2 rechargeable batteries.
Features
• Pressure rated to 300 m depth
• Heavy duty sealed unit with double ‘O’ ring protection
• Remote probe with 0.9 m lead for measuring in awkward locations
• Rugged durable shock proof construction
• Stable calibration - linear accuracy - no zero adjustment
• Various probe options
• Two Rechargeable batteries with charger
• Large Bright LED display for poor visibility
• All probes are protected by a membrane to prevent damage
• Self verification of the measurements to ensure accuracy
• Echo strength indicator to aid measurement
Applications
• Metal thickness and corrosion checks on offshore structures and ships
• Safety corrosion monitoring of pipelines and storage vessels
• Metal thickness / wear checks on anchor chains, jetties, dock gates, piers and pilings
• Ships classification surveys
• Maintenance and safety checks on bridges
For more information, please visit www.cygnus-instruments.com
|
|
•Measuring the thickness of concrete, rock£¬glass and other nonmetallic plate
•Sound alarm ,signal strength bar are used to improve measuring accuracy
•Direct digital read out of the thickness value avoid the inaccuracy of manual comparison
•Real time analysis of the tested data
•RS232 and USB interface to PC
•Test data create and data logging
•Memory: 32000 test data and 4000 component
|
|
●Especially suitable for testing the thin workpieces
●I-E testing mode and E-E testing mode
●Sound velocity testing and single point calibration
●Sound alarm and differential mode are available
●Chinese/English, mm/inch are selectable
●Data store, view and delete
●Result can be print out and transfer to PC
|
|
APPLICATION
Coating Thickness Analyzer is a tool for precise and accurate XRF measurement of various metallic and non-metallic coatings thickness (anticorrosive, insulating, antioxidizing, waterproof, pipe coating, etc.). Base/coating components are elements from Mg to U. System is applicable for control and monitoring of industrial processes.
FEATURES
- Automatic choice of coating thickness evaluation method for optimization of relative error of measurements,
- Remote control of analyzer electronics and software by ETHERNET interface from Workstation Device and communications with OPC server,
very simple and convenient operation and service,
- Possibility to install the measurement block under and above the measured material,
- built-in industrial computer.
For additional information, please contact us: XRF@bruker-baltic.lv
|
|
●Integrated probe FN
●Automatic substrate recognition
●Automatic calculation: Mean/Max/Min/No./S.Dev
●Upper-lower limit setting and sound alarm
●Data output RS232 to printer TA220S or PC
●500 data can be stored
●Measurement modes: continuous/single
●2 shutdown models: Manual/automatic
|
|
|
|
|
|
Coating Thickness Gauge ( TG-900)
Coating Thickness Gauge
TG-900 Features:
Automatically hold reading, when sensor leaves the surface.
Automatically measure thickness, when you place sensor onto the surface.
2-point calibration.
One hand operaiton- Simple and easy to be used.
Back light display
micro mini/mils user-selective.
Autopower off.
CE-approval
Coating Thickness Gauge TG-900
Model: TG-900
Range 0 to 40.0 mils ( 0 to 1000 micro m)
Resolution 0.1 mils/ 1 micro m
Response time 1 second
Accuracy +/- 4 digits on 0 to 7.8 mils
+/-7 digits on 0 to 199 micro m.
+/-(3% + 4 digits) on 7.9 mils to 40mils(200 micro m to 1000 micro m)
specified at 23 ¡æ +/- 5 ¡æ , <75% relative humidity.
General
Display 3 1/2 digit liquid crystal display (LCD) with a maximum reading of 1999.
Low battery indication the " Battery " symbol is displayed when the battery voltage drops below the operating level.
Operating environment 0 to 50 ¡æ (32 ¨H ~ 122 ¨H) ambient at < 75% relative humidity.
Store temperature 0 to 60 ¡æ (32 ¨H ~ 140 ¨H) ambient , 0to 80% R.H. with battery revoved from meter.
Auto power off 10 seconds
Dimensions 148 mm(H) x 105mm(W) x 42 mm(D)
Accessory Soft carrying bag, Standard thickness plate 3.9 mils (100 micron), 9V battery
|
|
|
|
|
|
Years of development and attention to customer needs have made Thermo Scientific Niton alloy analyzers the first choice in XRF technology, bringing lab-quality elemental analysis wherever it is needed in a field-hardened package. Now, in addition to superior positive grade identification and composition analysis of alloy/metal coatings and substrates, the Niton® XL3t offers the benefit of our coating thickness/coating weight measurement technology - providing an "out-of-the-box" nondestructive solution for gauging the effectiveness of coating and plating systems.
Fast and easy-to-use, the Niton XL3t 800 not only performs at line and plating bath solution analysis, but provides more accurate measurements than non-XRF technologies such as eddy current, magnetic induction, and Beta backscatter. You get precise, nondestructive multilayer coating thickness results in seconds. Testing at the plating line both increases productivity and improves process efficiency - no more over-coating or under-coating. What's more, the Niton XL3t is your answer to measuring large or irregularly shaped samples, as well as small-diameter wiring or tubing. Cutting samples for benchtop analysis are a thing of the past.
Typical applications are:
-Galvanized zinc over steel
-Zinc or zinc alloy over steel
-Hard chrome over steel
-Electroless nickel over steel
-Chrome/nickel/copper over steel, Zamak™ or plastic
-DACROMET™ coating over steel
|
|
|
|
|
|
Cygnus Heavy Duty
Multiple Echo Ultrasonic Thickness Gauge
A tough, rugged Ultrasonic Thickness gauge using our Multiple Echo technology, designed for use in demanding environments indoors or outdoors. The Cygnus 1 Heavy Duty is supplied ready to use as a complete kit in a protective carry case.
Features
• Heavy duty sealed unit - highly water / dirt / dust resistant
• Rugged construction - shock proof
• Stable calibration - linear accuracy - no zero adjustment
• Self verification of the measurements to ensure accuracy
• Various probe options
• Displays sound velocity settings
• Echo strength indicator to aid measurement
• Bright LED display with polarised filter
• Probe frequency selectable
• Low battery warning
• Metric / Imperial switchable
Applications
• Metal thickness monitoring on cranes, marine structures and conveying systems
• Corrosion checks on ships’ shell plates, bulkheads and structures
• Metal thickness safety checks on steam and pressurised water systems, transportable gas containers and compressed air systems
• Systematic wall thickness and corrosion monitoring of storage tanks and process vessels
• Quality assurance metal thickness checks
• Maintenance and safety checks on bridges and street lighting columns
For more informaiton please visit www.cygnus-instruments.com
|
|
|
|
|
|
Cygnus 4 - General Purpose
Multiple Echo Ultrasonic Thickness Gauge
A compact general purpose Ultrasonic Thickness gauge using our Multiple Echo technology, suitable for use in most hand-held industrial or shipping applications. The LCD display is easily read outdoors, and has a backlight for use in dark areas. The Cygnus 4 is supplied ready to use as a complete kit in a protective carry case.
Supporting Infomation
See IACS document covering requirements for ultrasonic thickness measurement in Shipping.
See Weathering Steel for Highway Structures - Residual Steel Thickness Measurement Using Ultrasonic Gauges
Features
• Backlit digital display for easy viewing from bright sunlight to
• complete darkness
• Rugged construction - shock proof - protected to IP65
• Stable calibration - linear accuracy - no zero adjustment
• Self verification of the measurements to ensure accuracy
• Various probe options
• Displays sound velocity settings
• Echo strength indicator to aid measurement
• Calibrates to a known thickness or a known velocity of sound
• Probe frequency selectable
• Low battery warning
• Metric / Imperial switchable
Applications
• Metal thickness monitoring on cranes, marine structures and conveying systems.
• Corrosion checks on ships’ shell plates, bulkheads and structures.
• Metal thickness safety checks on steam and pressurised water systems,
• transportable gas containers and compressed air systems.
• Systematic wall thickness and corrosion monitoring of storage tanks, process vessels and road tankers.
• Quality assurance metal thickness checks.
For more information, please visit www.cygnus-instruments.com
|
|
Ultrasonic Thickness Gauges are designed to improve safety and ensure reliability of material subject to corrosion or erosion.
Corrosion gauges with their dual-element transducers are the primary inspection tool used to measure the remaining walls of components such as pipelines, pressure vessels, storage tanks, and numerous other applications..
Precision gauges use single-element transducers to provide the thinnest range and highest degree of accuracy possible. Common applications include metals and a variety of non-metals (i.e. glass, ceramic, plastic, etc.).
We offer a wide variety of instruments and probes to offer the best solution for your specific application.
|
|
- Function of echo-echo (E-E) measurement and auto gain control (AGC)
- Difference mode setting
- Vibration alarm and sound & light alarm settings
- Sound speed calibration and zero calibration
- Adjustable units of measurement
- Easy operating keypad by left/right switch
- Different velocities available
- High frequency scanning technique
- Superior waterproof and dustproof plastic shell
|
|
●Portable size and easy operation
●Suitable for any metallic and non-metallic materials ultrasonic can go through
●Self-compensating of nonlinearity function is supplied for correction of pickup nonlineasity
●10 measuring values can be recorded for TT100,TT110,TT130;100 measuring values can be recorded for TT140
●optional 2.5MHz, 5MHz and 7MHz transducers are available
●Clear 4-Digit LCD display with backlight
●5 pre-set sound velocities for repeating applications
●mm / inch selectable
●TT100,TT130 and TT140 are suitable for thickness testing of various materials with sound speed range 1000-9999m/s
●TT110 and TT120 are easy-operation models with only two keys suitable for thickness testing of steel
●TT120: high-temperature model
●TT140:with backlight display and the memory reach up to 99
|
|
Product info: A scan thickness measuring, easy for users to identify the measuring errors by analyzing the waveform on screen.
Function of echo-echo measurement is available. It is used for measuring the distance between echo to echo, and thus users will get to know the thickness of steel plate even though it is covered by coating, such as inspection of oil tanks.
Min. and Max. mode function is supplied for users to find out the Min. (or Max.) value from a group of measuring results. it is very useful for inspecting the wall thickness of pipes and pressure vessels.
Manual gain adjustment / auto gain selectable
Up and low limits alarm is available
D-value mode function. It comprises normal D-value mode and percentage D-values mode. It will enhance operator's working efficiency greatly. Specially, users working with exact and changeless process requirements will benefit from TT500 immensely.
Large memory up to 100 A-scan images and 10000 thickness values.
|
|
|
|
|
|
PosiTector UTG
All Gages Feature . . .
Simple
Large graphics LCD with multilingual support
Pre-programmed velocities - simply select from a list of common materials or enter your own with ease
Bi-color indicator light - ideal in a noisy environment
RESET feature instantly restores factory settings
Durable
Solvent, acid, oil, water and dust resistant - meets or exceeds IP5X
Scratch/solvent resistant display suitable for harsh environments
Shock-absorbing, protective rubber holster with belt clip
Two (2) year warranty on both gage body and probe
Accurate
Precision transducers provide fast, accurate readings
Certificate of Calibration showing traceability to NIST included with every gage
Conforms to national and international standards including ASTM E797
Versatile
HiLo Alarm - dual-tone alarm and bi-color indicator light audibly and visibly alerts when measurements exceed operator selected limits
Internal memory stores up to 10,000 readings in up to 1000 batches
USB and IR ports for downloading to a PC, printer or data collector
Single or two point adjustment
Select from Two Models
UTG Std model measures the wall thickness of materials such as steel, plastic and more. Ideal for measuring the effects of corrosion or erosion on tanks, pipes or any structure where access is limited to one side.
UTG ME model features Thru-Paint capability to quickly and accurately measure the metal thickness of a painted structure without having to remove the coating. The most accurate method to measure remaining wall thickness of a painted structure because it automatically disregards the coating, lowering inspection time and expense.
|
|
Waveform Thickness Gauges
For more than 31 years, NDT Systems, Inc. has been a leader in bringing high quality, advanced technology ultrasonic testing products to the non-destructive testing marketplace.
Waveform thickness gauges allow users to "see" what the gauge is measuring in order to validate displayed digital thickness reading.
|
|
|
|
|
|
Cygnus 3 - Datalogger
Multiple Echo Ultrasonic Thickness Gauge
The Cygnus 3 Datalogger is versatile and easy to program with simple menu operation. Templates provide solutions to recording various geometries such as tanks, cylinders, pipes and plant.
Single Point for linear Records
Multipoint for N-Readings per point Records
Grid Point for 2-Dimensional X-Y Records
Key Point for specifying ranges of readings with alarms for complex structures
Windows Explorer style menu with measurements logged with one simple key press. The unit interfaces with a PC using our dedicated software which is Windows® compatible. The Cygnus 3 gauge has storage for up to 200,000 measurements.
Features
• Can be carried on the waist belt for ease of climbing
• Highly water / dirt / dust resistant
• Rugged construction - shock proof
• Stable calibration - linear accuracy - no zero adjustment
• Self verification of the measurements to ensure accuracy
• Various probe options
• Echo strength displayed to aid measurement
• Dual display: Bright LED & graphical LCD displays
• Probe protected by a membrane against wear and tear
• Metric / Imperial switchable
Applications
• Metal thickness monitoring on cranes, marine structures and conveying systems
• Corrosion checks on ships’ shell plates, bulkheads and structures
• Metal thickness safety checks on steam and pressurised water systems,
• transportable gas containers and compressed air systems
• Systematic wall thickness and corrosion monitoring of storage tanks, process vessels and road tankers
For more information, please visit www.cygnus-instruments.com
|
|
Dry Film Thickness Gauge acc. to Rossmann, Model 233
The difference in level between substrate and film surface is gauged by the contact point of the dial indicator.
Measuring range 0-1000 ìm in 5 ìm divisions.
|
|
|
|
