Lifting forklift truck attachment FB3-5380

rigid hitch

General
The Telescopic Forklift Boom FB3-5380 is a telescoping three-section rectangular tube steel boom designed for use on 3-tonne forklift trucks and larger. It provides adjustable reach while maximising operator visibility and secure attachment to fork blades.

Features

• Manual telescoping range designed so sections cannot be fully pulled out
• Secures to fork blades with two bolts per fork pocket and locking pins for restraint

Specifications
Metric | Imperial
Manual telescope: 2196 - 5380 mm | 86.5" - 212"
Increment: 796 mm | 31.3"
Slip-on fork pocket dimension: 165 x 65 mm | 6.5" x 2.6"
Fork pocket center distance: 377 mm | 14.8"
Working load limit (retracted): 2400 kg | 5291 lb
Working load limit (extended): 300 kg | 661 lb
Net weight: 163 kg | 359 lb
Gross weight: 173 kg | 381 lb
Packaging dimensions: L.2350 x W.630 x H.580 mm | L.92.5" x W.24.8" x H.22.8"

Technical specifications

• Product code: FB3-5380
• Type: Telescoping three-section rectangular tube steel boom
• Intended use: For 3-tonne forklift trucks and larger
• Manual telescope range: 2196–5380 mm
• Increment (telescoping step): 796 mm
• Slip-on fork pocket dimension: 165 x 65 mm
• Fork pocket center distance: 377 mm
• Working load limit (retracted): 2400 kg
• Working load limit (extended): 300 kg
• Net weight: 163 kg
• Gross weight: 173 kg
• Packaging dimensions: 2350 x 630 x 580 mm
