Manual bending machine HRP-S 220

for PVC profilesfor plastic profiles

Description
Professional floor-standing thermoplastic bending machine for acrylic (PMMA), polycarbonate (PC), polystyrene (PS), PVC and similar plastics. Pneumatically controlled cover, adjustable parallel back stop and clamping bar. Calibrated mm/inch scale and height-adjustable heating profiles. Standard configuration includes 2 digital temperature controllers, 1 bottom heating line and 1 top heating line; operates with double-side heating and time control. Upper frame operated by foot pedal and timer; adjustable pressure bars prevent warping.

Applications

• Signage fabrication: large-format signs and displays for advertising and visual communication.
• Acrylic furniture and decoration: production of large decorative and furniture components.
• Prototypes and industrial models: creation of large-scale prototypes and models for testing and design.
• Industrial components: fabrication of large plastic parts for industrial applications.
• Architectural elements: production of plastic elements for construction and design.

Main features

• Working width up to 220 cm (2,200 mm) to process large sheets.
• Material compatibility: PMMA (acrylic), PC, PS, PVC and other thermoplastics.
• Adjustable temperature control with 2 digital controllers for precise heating.
• Double-side heating (upper and lower) and time control for consistent bends.
• Modular construction: 1–4 bottom heating lines and 1–2 top lines; expandable with additional profiles and controllers.
• Foot-pedal upper frame and adjustable pressure bars to minimize warping.
• Parallel back stop with calibrated mm/inch scale and durable, heat-resistant multi-panel work surface.

Technical characteristics HRP-S 220 (structured extract)

• Model type: Floor
• Bending method: Manual
• Number of bending lines: Several (modular)
• Heating method: Bottom and top (double-side heating)
• Bottom heating lines: 1 - 4 (modular)
• Top heating lines: 1 - 2
• Working length: 2,200 mm
• Working thickness: 1 - 12 mm (max. 15 mm with special profiles; some references note up to 20 mm depending on material)
• Distance between curves: 20 - 1,000 mm (reflectors adjustable centre-to-centre 25 - 1,000 mm)
• Connection voltage: 230 V
• Power consumption: 2 kW - 4 kW
• Dimensions (L x W x H): 2,390 x 1,300 x 1,720 mm
• Weight: 470 kg

Additional technical notes
Heating elements are digitally controlled; profile cables are height-adjustable and heating profiles can be positioned easily. The machine can process very thin sheets (from 0.03 - 1 mm) and thicker sheets up to 15 mm with optional bending profiles or 2-heater reflectors. Modular internal preparation allows adding multiple heating profiles and control units.

Characteristics / technical specifications

• Model: HRP-S 220
• Intended materials: PMMA, PC, PS, PVC and other thermoplastics
• Working length: up to 220 cm
• Working thickness: 1 - 12 mm (max. 15 mm with special profiles)
• Heating control: 2 digital temperature control units
• Operation controls: foot pedal for upper frame and timer
• Electrical supply: 230 V; electrical use 2 kW - 4 kW
